- Page 1 重要度 产品名称 冷藏冷冻箱 产品型号 BCD-622WP3BF1/HC1(H) 出口型号 RB-81W1EZS/S-001-001 立项单编号 RBXLXC2100934 借（通） 用件登记 冰箱开 发中心 旧底图总号 底图总号 使用 版本 更改单编号 签字 日期 重量 比例 说明书 何川 设计 出图审查 标准化 共 页 第 页 BSSJ00006308 日期 批准...
- Page 2 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference. RB-81W1EZS/S-001-001 English For questions about features, operation/performance, parts or service,call: 1-855-344-7367...
-
Page 3: Table Of Contents
Contents Thank you for choosing Hisense. We are sure you will find your new refrigerator a pleasure to use. However, before you use the appliance, we recommend that you carefully read the instructions, which provide details about installing and using the product. -
Page 4: Safety And Warning Information
Safety and warning information For your safety and correct usage before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with it operation and safety features. - Page 5 Safety and warning information General safety and daily use It is important to use your appliance safely. We recommend that you follow the guidelines below. Store any food in accordance with the storage instructions from the manufacturer. This appliance is intended to be used in household and similar applications such as 1.
- Page 6 Safety and warning information Safety for children and others who are vulnerable people This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 7 Safety and warning information Electrical Safety This appliance must be grounded. This appliance is fitted with a plug, in accordance with local standard. The plug should be suitable for use in all houses fitted with sockets in accordance with current specifications. If the fitted plug is not suitable for your socket outlets, it should be cut off and carefully disposed of.
- Page 8 Safety and warning information Electrical Safety To avoid eye injury, do not look directly into the LED light located in the refrigerator compartment. If it is not functioning correctly, consult a qualified, registered electrician or replace it in accordance with the “Cleaning and Care”...
-
Page 9: Installing Your New Appliance
Installing your new appliance Before using the appliance for the first time, you should be aware of the 1/2" following tips. Ventilation of appliance 1/2" 1/2" In order to improve efficiency of the cooling system and save Relevant information (inch) energy, it is necessary to maintain good ventilation around the 31.3"... - Page 10 Installing your new appliance Stand your appliance in a dry place to avoid high moisture damage. Keep the appliance out of direct sunlight, rain or frost. Stand the appliance away from heat sources such as stoves, fires or heaters. adjustable bottom feet Leveling of appliance For sufficient leveling and air Warning...
- Page 11 Installing your new appliance Reversing the door Warning The side at which the door opens can be changed, from the right side (as supplied) to the left side if required. When reversing the door, the appliance must not be Tools you will need: connected to the Power, Ensure Not provided that the plug is removed from...
- Page 12 Installing your new appliance Caution Please slightly squeeze the door rack from two sides toward center and inside of door rack, and then move it upward when taking out the upper rack and lower rack. 3. Remove the upper hinge-right (please hold upper door by hand when 2.
- Page 13 Installing your new appliance 4. Remove the upper door from the 6. Open the freezer door u se the Allen middle hinge by carefully lifting the wrench (provided in the plastic door straight up. Then place the upper accessory bag) to unscrew the door on a smooth surface with its panel screws used to fix the middle hinge- upwards.
- Page 14 Installing your new appliance 9. Install the screw hole cover-right 11 12. Assemble the upper hinge cover-left (provided in the plastic accessory bag) to the to match the hinge. Install the door right-top corner of cabinet. Remove screw racks to original position. Keep the hole cover-left 12 from the left-top corner of upper hinge cover-right with the cabinet with the thin-blade screwdriver and...
- Page 15 Installing your new appliance 2. Remove the 2 screws(2) fixed on the 5. Remove the 2 screws(4) holding the upper drawer with cross screwdriver. support with Cross screwdriver. 3. Take out the upper drawer by lifting it up from the rail system. 7.
-
Page 16: Description Of The Appliance
Description of the appliance View of the appliance 01. Cabinet 08. Lower freezer drawer 02. Wind channel 09. Adjustable bottom feet 03. Glass shelf 10. Fridge door 04. Control panel 11. Small rack 05. Crisper cover 12. Fridge gasket 06. Fruit Vegetable Crisper 13. -
Page 17: Display Controls
Display controls Use your appliance according to the following control regulations, your appliance has the corresponding functions and modes as the display panels showed in the pictures below. 01. Temperature Area 07. Eco Icon 02. Celsius/Fahrenheit Indicator 08. Alarm Icon 03. - Page 18 Display controls Note Note: Once the appliance is powered on, all icons on the display panel will be lit for 3 seconds with a buzzer sound. All the icons will go off on the condition of all keys untouched and all doors closed for one minute. The control panel will light up when the door is open or you touch any button. Setting the refrigerator will accelerate food running at high temperature ...
- Page 19 Display controls If you have set temperature type to "Super Cool " Fahrenheit, the temperature settings will be cycle from 46°F to 36°F. The Super Cool feature helps to keep 46°F - 45°F - 44°F -43°F - 42°F-41°F 36°F - 37°F -38°F - 39°F-40°F food stored in the refrigerator at the Note: Each press of the button, the setting temperature during periods of temperature drops one degree. high usage, large grocery loads, or temporarily warm room temperatures, The Super Cool feature lowers the "Freezer ...
- Page 20 Display controls " or " " repeatedly until the 1.Press" " blinks. Super Freeze icon " "Door Open Alarm" 2. Press the Confirm Control " " to turn the Super Freeze function on or off. is opened for the fridge door longer When the Super Freeze function is than 2 minutes, the control panel will turned on, the " " icon lights. display "dr ", the " " icon will blink and 3. When setting freezer temperature, the the buzzer will sound 3 times every ...
-
Page 21: Using Your Appliance
Using your appliance This section tells you how to use most of the useful features. We recommend that you read through them carefully before using the appliance. Door rack It is suitable for the storage of canned liquid, bottled drinks and packed food, etc. -
Page 22: Cleaning And Care
Cleaning and care For hygienic reasons the appliance Warning (including exterior and interior accessories) should be cleaned Do not use sharp objects as they regularly (at least every two are likely to scratch the surface. Do not use Thinner, Car Warning detergent Clorox, ethereal oil, abrasive... - Page 23 Cleaning and care Door seals cleaning Although this appliance automatically defrosts, a layer of Take care to keep door seals clean. frost may occur on the freezer Sticky food and drinks can cause compartment's interior walls if the seals to stick to the cabinet and tear freezer door is opened frequently or when you open the door.
-
Page 24: Helpful Hints And Tips
Helpful hints and tips Energy saving tips Hints for refrigeration We recommend that you follow the Meat (AIl Types) Wrap in polythene tips to save energy. food: wrap and place on the glass Try to avoid keeping the door open shelf above the vegetable drawer. -
Page 25: Troubleshooting
Helpful hints and tips Switching off your appliance It is recommended to label and date each frozen package in order to keep If the appliance needs to be switched track of the storage time. off for an extended period, the following steps should be taken to Hints for fresh food refrigeration prevent mould on the appliance. - Page 26 Troubleshooting It is normal that the freezer is not operating during the defrost cycle or for a short time after the appliance is switched on to protect the compressor .
- Page 27 Troubleshooting...
- Page 28 Troubleshooting...
-
Page 29: Disposal Of The Appliance
Disposal of the appliance...
