- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S...
-
Page 2: Product Overview
CONTENTS PRODUCT OVERVIEW AXON™ SL features a 45-degree angled button face for an ergonomically correct activation angle. Light models fire in both momentary and constant-on modes. The AXON™ SL M-LOK® Mounting Kit increases functionality of the AXON™ SL remote switch by expanding the mounting capabilities to the M-LOK® rail. It replaces the rail clamps with a frame that provides attachment to any M-LOK®... - Page 3 WARNING: ENSURE FIREARM IS UNLOADED OVER-TORQUING FASTENERS CAN DAMAGE YOUR MOUNT WILL NOT BE COVERED BY CAUTION: WARRANTY. INSTALLING ON M1913 RAIL Place the AXON™ SL Control Module on M1913 Rail in desired location. Align the Rail Clamps along the side of the AXON™...
- Page 4 Fully seat the Hex Nuts in the recesses in Rail Clamp B. Thread the Cross Bolts in the circular holes in Rail Clamp A via the pass-through and into the Hex Nuts in Rail Clamp B. Finger tight both before applying torque to either. Using the T10 Torx Key, torque to 5 in-lbs (0.57 Nm).
- Page 5 INSTALLING ON M-LOK® RAIL Ensure the Rail Clamps on your AXON™ SL are uninstalled prior to installing the M-LOK® Mounting Kit. Set the Rail Clamps and associated screws aside for safe keeping. Insert the M-LOK® Screws through the AXON™ SL M-LOK® Mounting Kit Frame and thread partially into the M-LOK®...
- Page 6 10 in-lbs (1.13 Nm). Ensure M-LOK® Nuts are fully perpendicular to M-LOK® slots in rail (fully seated). I N FO @ U N I T Y TACT I CAL .COM ©2024 UNITY Tactical. All Rights Reserved. Specifications subject to change without notice. PAT: UTIP.CO...
