Sys Tec Electronic USB-SPEmodul1 System Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USB-SPEmodul1 (T1L)
System manual
Version 1.00
Edition May 2024
Document No.: L-2862e-04
SYS TEC electronic AG Am Windrad 2 D-08468 Heinsdorfergrund
Phone: +49 (3765) 38600-0 Fax: +49 (3765) 38600-4100
Web: https://www.systec-electronic.com Mail: info@systec-electronic.com
SYS TEC electronic AG - System House for Distributed Automation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB-SPEmodul1 and is the answer not in the manual?

Questions and answers

Related Manuals for Sys Tec Electronic USB-SPEmodul1

Summary of Contents for Sys Tec Electronic USB-SPEmodul1

  • Page 1 System manual Version 1.00 Edition May 2024 Document No.: L-2862e-04 SYS TEC electronic AG Am Windrad 2 D-08468 Heinsdorfergrund Phone: +49 (3765) 38600-0 Fax: +49 (3765) 38600-4100 Web: https://www.systec-electronic.com Mail: info@systec-electronic.com SYS TEC electronic AG - System House for Distributed Automation...
  • Page 2 System manual USB-SPEmodul1 (T1L) Changes Date/Version Section Changes Author/Editor 1.00 created © SYSTEC electronic AG 2024 L-2862e-04 Page 2...
  • Page 3 The information in this manual has been carefully checked and is believed to be accurate. However, it is expressly stated that SYS TEC electronic AG does not assume warranty or legal responsibility or any liability for consequential damages which result from the use or contents of this user manual. The information contained in this manual can be changed without prior notice.

  • Page 4: Table Of Contents

    System manual USB-SPEmodul1 (T1L) Table of Contents Introduction ........................... 6 How to use this manual? ......................6 Definitions ..........................7 1.2.1 Terms ..........................7 1.2.2 Safety instructions and warnings ..................7 Product Description ........................8 Intended use ........................... 8 Product identification ....................... 8 Product overview and interfaces ...................
  • Page 5 System manual USB-SPEmodul1 (T1L) List of Tables Table 1: Overview of relevant manuals for the USB-SPEmodul1 (T1L) ..........6 Table 2: Device Label description ......................8 Table 3: Overview of device variants ...................... 9 Table 4: Technical data ........................12 List of Figures Figure 1: Device label ..........................

  • Page 6: Introduction

    System manual USB-SPEmodul1 (T1L) 1 Introduction Thank you for choosing the SYS TEC USB-SPEmodul1 (T1L). This manual guide you to unlocking the technical capabilities of our Single Pair Ethernet (SPE) adapter. This product provides an innovative interface, bridging USB 2.0 to Single Pair Ethernet networks.

  • Page 7: Definitions

    System manual USB-SPEmodul1 (T1L) 1.2 Definitions 1.2.1 Terms This product may only be operated by personnel qualified for the specific task in accordance with the corresponding documentation for this specific task. This relates to its warning notices and safety instructions. Qualified personnel are those who, when working with these products, can identify risks and avoiding potential hazards 1.2.2 Safety instructions and warnings...

  • Page 8: Product Description

    A detailed explanation for the label information can be found in Table 2. Table 2: Device Label description Label Description Name Name of the specific device, e.g. USB-SPEmodul1 (T1L) Model Item number for ordering and support requests Serial number – this is individual for each device Serial...

  • Page 9: Table 3: Overview Of Device Variants

    System manual USB-SPEmodul1 (T1L) Table 3: Overview of device variants Model Name Channel Main feature 3244000 USB-SPEmodul1 (T1L) 1x SPE - SPE 10BASE-T1L - without PoDL support - Housing: table case 3344000 USB-SPEmodul1 (T1L) 1x SPE - SPE 10BASE-T1L - without PoDL support - open frame variant ©...

  • Page 10: Product Overview And Interfaces

    System manual USB-SPEmodul1 (T1L) 2.3 Product overview and interfaces USB-C connection Figure 4: Top view of device Figure 3: Side view of device (SPE interface connectors) LED description Connector description Name Color State Description Connection Description power-LED green power on...

  • Page 11: Assembly/Disassembly And Installation

    Be certain that the maximum torque does not exceed 1 Nm. 2.4.2 Installation The shielding connection on the USB-SPEmodul1 (T1L) serves the specific purpose of improving electromagnetic compatibility (EMC) mitigation. For optimal performance and protection, it is crucial to externally connect the shield of the SPE cable to a grounding source.

  • Page 12: Technical Data

    System manual USB-SPEmodul1 (T1L) 2.6 Technical data The following sections summarize the technical data that the user must take into account when using the respective device. Table 4: Technical data Parameter Condition Value Power Supply USB bus powered 5V±5% Current consumption 0,075A±5%...

  • Page 13: Getting Started

    1. Open the Windows Device Manager. 2. Connect the USB-SPEmodul1 (T1L) via USB cable to the PC. 3. Under “Other devices” you will find a new entry with the name “USB-SPEmodul1” as shown in Figure 5. Right-click on this device to open the context menu. Then click on “Update driver”.

  • Page 14: Figure 6: Update Drivers - Manually Installation

    System manual USB-SPEmodul1 (T1L) Figure 6: Update Drivers – manually installation Figure 7: Update Drivers – browse location © SYSTEC electronic AG 2024 L-2862e-04 Page 14...

  • Page 15: Installation Under Linux

    System manual USB-SPEmodul1 (T1L) Figure 8: Update Drivers – successful Figure 9: Device Manager – check installation 3.3 Installation under Linux The following Kernel components need to be enabled: CONFIG_NET=[m,y] CONFIG_NETDEVICES=[m,y] CONFIG_PHYLIP=[m,y] CONFIG_USB=[m,y] CONFIG_USB_NET_DRIVERS=[m,y] CONFIG_USB_NET_SMSC95XX=[m,y] CONFIG_USB_PHY=[m,y] CONFIG_USB_USBNET=[m,y] To read out the kernel configuration available at your system you can use [z]grep, e.g.: zgrep NETDEVICES /proc/config.gz (Arch Linux)

  • Page 16: Linux Kernel Version 6.1(Lts)

    System manual USB-SPEmodul1 (T1L) 3.3.1 Linux Kernel Version 6.1(LTS) 3.3.1.1 Requirements • dkms • Linux header files • make • For a Debian based distribution, you can use the following command to install the dependencies: sudo apt install dkms build-essential linux-headers-generic 3.3.1.2 Installation...

  • Page 17: Application Hints

    2.2. 3.5 Tools As the USB-SPEmodul1 (T1L) serves solely as an adapter, additional software is required to send, receive, and analyze valid data. This software must be provided by the corresponding counterpart. Ensure that the software meets the requirements of the USB-SPEmodul1 (T1L) and is compatible with your system.

  • Page 18: Index

    System manual USB-SPEmodul1 (T1L) Index Application hints ........... 17 Linux Kernel Version 6.1(LTS) ...... 16 Assembly instruction........11 Linux Kernel Version 6.6 (LTS) ..... 16 Linux Kernel Version 6.9 and above ..... 16 Configure a static IP address ....... 17 Manuals Overview .............
  • Page 19 System manual USB-SPEmodul1 (T1L) Document: System manual USB-SPEmodul1 (T1L) Document Number: L-2862e-04, Edition May 2024 Do you have any suggestions for improving this manual? Did you find any mistakes in this manual? Page Sent from: Customer number: Name: Company: Address:...
  • Page 20 System manual USB-SPEmodul1 (T1L) © SYSTEC electronic AG 2024 L-2862e-04 Page 20...
