- Page 1 Company A1.2 Auto Sentry Petro ® Installation Guide Version 2.0 Defining the World of Car Wash Technology Axis 8, Hawkfield Business Park, Hawkfield Way, Whitchurch, Bristol, BS14 0BY Phone: +44 1275 866 910 | Fax: +44 1275 866 919 | Email: info@psdcodax.com...
-
Page 2: Table Of Contents
Contents Chapter 1: Introduction 4 Purpose 4 Rules for Installation 4 Related Documents 4 Environmental Statement 5... - Page 3 Chapter 4: System Wiring 17 AC Power Terminations 17 Power Wiring Plan 18 Control Box Terminations 19 In-Bay Controller Wire Terminations 20...
-
Page 4: Chapter 1: Introduction
Chapter 1: Introduction This document was written for installation technicians and electricians A thorough understanding of electrical wiring, installation, local regulations, and safety protocols is required No prior experience with the Auto Sentry Petro is required Purpose This guide is provided to assist you during installation of the Auto Sentry Petro To ensure proper installation, this guide should be supplied to the electrician prior to the installation of cable and wiring WARNING: Faulty installations are the major cause of system malfunctions. -
Page 5: Environmental Statement
Environmental Statement PSD strives to create top quality products that minimise the impact on the environment We work with all our partners to produce products that are in compliance with the relevant environmental regulations and legislation We also recognize our responsibility to minimise the quantity of electrical and electronic waste reaching landfill For this reason, we encourage reuse or responsible disposal of waste electronic and electrical equipment (WEEE) All applicable products are marked with the crossed out wheelie bin label to indicate the need for responsible disposal... -
Page 6: Chapter 2: Site Planning
Chapter 2: Site Planning Careful planning for the layout of the site will help eliminate possible problems with the start-up of your system and will ensure continued, reliable system operation Location The Auto Sentry Petro has been designed to operate in an outdoor environment „... -
Page 7: Cable Sizing
Cable Sizing Each installation will vary depending on what type of cable is used, the load (Amps), how long is the cable run, what type of building construction, the environment, and how many other cables are installed Therefore, cable sizing would be decided and calculated to be site and installation specific To determine cable size needed, the electrical contractor will refer to the electrical regulations book and make a decision for the best installation Auto Sentry Petro Wiring Guidelines... -
Page 8: Earthing
IN-BAY LAYOUT *** THIS DRAWING IS ONLY INTENDED TO SHOW THE GENERAL LAYOUT AND DIMENSIONS NOTE: ICS DOES NOT RECOMMEND AN IDEAL DISTANCE BETWEEN THE AUTO SENTRY PETRO AND THE ENTRANCE TO THE IN-BAY TUNNEL, BUT NECESSARY FOR THE PROPER PLACEMENT OF THE AUTO SENTRY PETRO. ANY DEVIATION DOES OFFER THE FOLLOWING INFORMATION TO THE IN-BAY OWNER FOR MAY CAUSE DAMAGE TO THE AUTO SENTRY PETRO. -
Page 9: Placement Of The Auto Sentry Petro
Auto Sentry Petro Placement of the Auto Sentry Petro Placement Front • The face of the Auto Sentry Petro is to be in line with the front edge of the curbing. Rear • The rear wall of the Auto Sentry Petro should be set at 350mm from the front edge of the curbing. -
Page 10: Dimensions Of The Auto Sentry Petro
DIMENSIONS Dimensions of the Auto Sentry Petro 393mm 800mm 406mm 203mm Side View Front View The Auto Sentry Petro is the primary point-of-sale for the car wash It is installed outside near the entrance of the car wash with a canopy placed over it Figure 3. -
Page 11: Base Placement With A Riser
AUTO SENTRY PETRO Base Placement with a Riser BASE PLACEMENT WITH RISER - TOP VIEW BACK EDGE OF CURB CONCRETE CONCRETE ISLAND ISLAND OPEN SPACE IN BASE OF RISER FOR PLACEMENT OF CONDUITS IN THE AUTO SENTRY PETRO 165mm Square 50mm 615mm 228mm... -
Page 12: Base Placement Without A Riser
AUTO SENTRY PETRO Base Placement without a Riser BASE PLACEMENT WITHOUT RISER - TOP VIEW BACK EDGE OF CURB CONCRETE CONCRETE ISLAND ISLAND OPEN SPACE IN BASE OF AUTO SENTRY FOR PLACEMENT OF CONDUITS 154mm Square 406mm 355mm 203mm C L C L FRONT EDGE OF PETRO OF CURB... -
Page 13: Door Swing Clearance
Door Swing Clearance IMPORTANT: Door Clearance Area AUTO SENTRY PETRO DOOR SWING CLEARANCE Top View AUTO SENTRY PETRO C L C L Drawing is not to scale. FRONT OF AUTO SENTRY PETRO 800mm FRONT EDGE OF ISLAND KERB BASE 406mm IMPORTANT: Do NOT install canopy posts or other obstructions in this door swing area 660mm... -
Page 14: Chapter 3: Molded Plastic Installation 10
Attaching the Auto Sentry® Petro to the J Bolts in the Concrete *IMPORTANT: If your site does not have a raised kerb, contact ICS to order a 150mm metal riser The riser is required to give the proper height necessary to deliver to your customers, the most optimal... -
Page 15: Hardware For Roto Molded And Plastic Installation
(20) Rubber Washer Plastic and Roto Mold Parts Identification NOTE: The front and rear covers and doors are † available in either blue or gray ICS Part Number Description AS4PLAS3 Foot Step Roto Mold for AS4ENC AS4PLAS2 Foot Insert Roto Mold for... -
Page 16: Plastic And Roto Molded Installation
Plastic and Roto Molded Installation 1 Locate the plastic front door #6 in Figure 9 2 Place the rubber washers (bag N) on the plastic front door’s mounting studs 3 Carefully align the plastic front door to the metal face housing, insuring all rubber washers stay in place, and then secure with Keps nuts (bag K) DO NOT over tighten 4 Locate plastic rear door #7 in Figure 9 5 Place the rubber washers (bag N) on the plastic rear door’s mounting studs... - Page 17 DO NOT OVER TIGHTEN. Two pound-foot torque is recommended. Over torquing could cause shearing or cracking. 6 Locate the gray full-size Auto Sentry Petro roto mold #3 See Figure 9 Figure 12. Center Plastic (#3 in Figure 8) 7 On the Auto Sentry Petro, open the front door to perform the next step 8 Remove the plastic keeper on the sonic sensor You will need to put this back on after the plastics are completely installed 9 Place the Roto Molded Plastic (#3 in Figure 9) over the Auto Sentry Petro metal core...
- Page 18 11 On the back of the Auto Sentry Petro, line up the three metal tabs at the top to the holes in the gray roto mold #3 See Figure 14 Figure 14. Metal tabs on the rear of the Auto Sentry Petro 12 Install (3) of the #8 -11 x 1 1/4”...
- Page 19 The (4) silver screw holes across the top of roto mold #3 are for optional sign attachment † Contact ICS Marketing for custom toppers (additional fees apply) Figure 16. Attach Blue Roto Mold #4 with (3) screws to gray Roto Mold #3 16 Install and tighten (3) #10 x 1 1/2”...
- Page 20 18 Attach the metal mounting plate with the ribs facing out to the back of the Auto Sentry Petro pedestal with (8) 1/4” x 20 × 3/8” bolts (Bag E) See Figure 17 Metal ribs facing out Figure 18. Attach Metal Mounting Plate with Ribs Facing Out and Hardware Bag E 19 Install and tighten (14) #8 x 11 x 1- 1/4”...
-
Page 21: Ac Power Terminations
AC Power Terminations WARNING: The terminals and power supplies contained in the Auto Sentry Petro enclosure are for the ICS Equipment Only! Connecting external components and wiring to the Auto Sentry Petro power circuits can damage the circuit boards and components and WILL VOID THE WARRANTY. -
Page 22: Power Wiring Plan
*** THIS DRAWING IS ONLY INTENDED TO SHOW THE TYPES OF WIRING THAT MUST BE ELECTRICAL PANEL RUN BETWEEN PIECES OF ICS EQUIPMENT. THE INDIVIDUAL RUNNING THE WIRING MUST ENSURE THAT AMPLE WIRE IS AVAILABLE AT EITHER END TO FACILITATE TERMINATION. -
Page 23: Control Box Terminations
AUTO SENTRY PETRO Control Box Terminations CONTROL BOX The WashConnect software has the ability to toggle the Auto Sentry Petro Wash Open on the server / POS computer screen, and this feature is optional Override switches for the gates are still necessary ALL ITEMS CIRCLED TO BE PROVIDED BY CAR WASH SPST SWITCH... -
Page 24: In-Bay Controller Wire Terminations
In-Bay Controller Wire Terminations AUTO SENTRY TO GENERIC IN-BAY AUTOMATIC NOTE: Some of the wiring shown may not be needed for all in-bays. TERMINATION POINTS ON AN IN-BAY AUTOMATIC CONTROLLER WASH ENABLE WASH ENABLE WASH IN USE WASH IN USE SERVICE #1 SERVICE #2 SERVICE #3... -
Page 25: In-Bay Wiring Layouts
In-Bay Wiring Layouts Figure 26 is one example of a possible wiring layout for an In-Bay Car Wash See the PSD Codax System Installation Drawings that were prepared for your specific car wash site and given to you by your PSD Codax salesperson or technician HIGH SPEED HIGH SPEED DSL / Cable Modem... -
Page 26: Communications Wiring
Communications Wiring This section describes wiring for RS-422 and RS-485 communications Requirements All peripheral equipment connected to the RS-232 ports must be Listed, have an Electronics Industrial „ Association (EIA) standard RS-232 comm communications protocol and not be installed over a hazardous location RS-232 communication must not exceed 30 m „... -
Page 27: System Network Cables
System Network Cables 1 Plug a network cable into the Network Router, and then pull that network cable up through the center of the Auto Sentry Petro unit Plug in the other end of this network cable to the Network Switch port located inside the Auto Sentry Petro See the yellow cable in Figure 28 (It does not matter which port you use) 2 The black network cable in Figure 28 is plugged into the Network switch port and runs to the UX300 card reader A network coupling is located on the inside of the Petro to connect the network cable... -
Page 28: Chapter 5: Parts Identification 24
Chapter 5: Parts Identification This section provides details on exterior and interior component locations The Auto Sentry Petro also includes roto molds and plastic panels to fit the exterior of the unit Panels may be purchased separately NOTE: If you cannot find the part in the following pages, contact PSD Codax sales for more information: †... -
Page 29: Plastic And Roto Mold Parts
Table 1. Exterior Components (Front View) ICS Part Number Description AS2TOUCH15Z2 15" touch screen with AR coating CAMERAASSM Camera assembly, with Chip & Pin equipment Camera assembly, WITHOUT Chip and Pin CAMERAASSM1 equipment AS2INTERCOMSP 2 Speakers SCN-000002-00 Bar code Reader... -
Page 30: Interior Front Door Components
Interior Front Door Components Figure 31. Interior Front Door Components Table 3. Interior Front Door Components ICS Part Number Description PIN Pad per site specifics AS2TOUCH15ZCNCD Touch Controller Card Card reader assembly per site specifics ASPRHEC USB Receipt Printer Gift Card Chute (Discontinued) -
Page 31: Interior Rear Left-Side Of Auto Sentry Petro
Interior Rear Left-Side of Auto Sentry Petro Figure 32. Interior Rear Left-side of Auto Sentry Petro Table 4. Interior Rear Left-side of Auto Sentry Petro ICS Part Number Description SURGEPROTECT 120 VAC Surge Protector (Not Shown) SURGEPROTECT1 240 VAC PWRPULSUPS... -
Page 32: Interior Of Rear Door Components
Door switch (2 pieces) ASDRLATCH Complete latch assembly AS4DRKEY Key for AS4DRLOCK “ICS MEDECO KEYS” AS4DRLOCK Door Lock for AS4, 64W0550T-26-M7-ICS-2 “ICS MEDECO KEYS” H/CCONTROLBD1 Heater/cooler control board AS3CBL21A 24 Volt (Low Voltage) power cable for the heat exchangers AS3HEATCOOL-1... -
Page 33: Interior Rear Right-Side
Interior Rear Right-side Figure 34. Interior Rear Right-side Table 6. Interior Rear Right-side ICS Part Number Description AS3DRSW Door Switch (2 pieces) ASPUSHBUT Service Screen button AS4-TB-1-A RFID Terminal Block Assembly Motherboard per site specifics NETRJ45CO Network Coupler COMCONVEXPWR1 Standard Fuel Converter (Optional) - Page 34 Company A1.2 Environmental Statement PSD Codax strives to create top quality products that minimize impact on the environment. We work with all our partners to produce products that are in compliance with the relevant environmental regulations and legislation. We also recognize our responsibility to minimize the quantity of electrical and electronic waste reaching landfill. For this reason we encourage reuse or responsible disposal of waste electronic and electrical equipment (WEEE).
