Axis Q1686-DLE Manual

Radar-video fusion camera
Hide thumbs Also See for Q1686-DLE:

Advertisement

Quick Links

AXIS Q1686-DLE Radar-Video Fusion Camera

Table of Contents

Solution overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radar-video fusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preview mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radar coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation examples and use cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Get started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Find the device on the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Open the device's web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Create an administrator account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Secure passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Web interface overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configure your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjust the image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
View and record video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additional radar settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set up rules for events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Analytics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recordings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Learn more . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Long-distance connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote focus and zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Privacy masks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overlays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Streaming and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cybersecurity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SD card slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clean your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reset to factory default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AXIS OS options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check the current AXIS OS version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Upgrade AXIS OS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical issues, clues, and solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Performance considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contact support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
2
2
3
3
3
4
6
8
10
10
10
10
10
11
11
12
12
15
15
20
21
24
30
32
32
33
45
51
52
53
54
54
75
77
77
77
77
77
77
80
82
82
83
83
84
84
87
88
88
88
88
88
89
90
90

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q1686-DLE and is the answer not in the manual?

Questions and answers

Summary of Contents for Axis Q1686-DLE

  • Page 1: Table Of Contents

    Check the current AXIS OS version ........
  • Page 2: Solution Overview

    Radar-video fusion Each technology in AXIS Q1686-DLE – radar, video, and optional license plate capture software – generates metadata on its own. The metadata includes information like speed, object class, direction, and license plate information. What’s special about this device is that it fuses the metadata, which means it connects the speed and license plate of the same vehicle.
  • Page 3: Installation

    To watch this video, go to the web version of this document. help.axis.com/?&piaId=&section=solution-overview Note: The optical unit of the camera in the video is not identical with the one in AXIS Q1686-DLE. Preview mode Preview mode is ideal for installers when fine tuning the camera view during the installation. No login is required to access the camera view in preview mode.
  • Page 4: Radar Coverage

    Radar coverage The radar in AXIS Q1686-DLE has a horizontal field of detection of 95°. Its detection range depends on factors like the mounting height and tilt angle of the device, and the size and speed of moving vehicles. The detection range also depends on the radar profile.
  • Page 5 AXIS Q1686-DLE Radar-Video Fusion Camera Installation • 50–70 m (164–230 ft) for vehicles moving at 200 km/h (125 mph). Note To minimize the risk of missed detections of vehicles travelling in high speeds, set up a scenario in the radar that triggers on the object types Vehicle and Unknown.
  • Page 6: Installation Examples And Use Cases

    AXIS Q1686-DLE Radar-Video Fusion Camera Installation Mounting 15° tilt 20° tilt 25° tilt 30° tilt 35° tilt 40° tilt 45° tilt height 10–60+ m 9.0–60+ m 7.0–60+ m 6.0–60+ m 6.0–60 m 5.0–55 m 5.0–55 m (19 ft) (32–196+ ft) (29–196+ ft)
  • Page 7 Make sure to zoom in so that the lane, or lanes, where you intend to capture license plates cover the image. Recommendations • For recommendations about how to mount the device when using AXIS License Plate Verifier, see . • For information about license plate capture in general, see the white paper “License plate capture” at axis.com/learning/white-papers.
  • Page 8: Mounting Recommendations

    For an example of how to create a rule that triggers a recording, see . Mounting recommendations AXIS Q1686-DLE has been thoroughly tested with the application AXIS License Plate Verifier. The mounting recommendations in the following tables are based on the combined performance of the camera, radar and application.
  • Page 9 AXIS Q1686-DLE Radar-Video Fusion Camera Installation 18° 8 m (26.2 ft) 25 m (82 ft) Up to 80 km/h (50 mph) 11° 40 m (131 ft) Up to 160 km/h (99 mph) 9° 50 m (164 ft) Up to 104 km/h (65 mph) Definitions of the table parameters are available in .
  • Page 10: Get Started

    Get started Find the device on the network To find Axis devices on the network and assign them IP addresses in Windows®, use AXIS IP Utility or AXIS Device Manager. Both applications are free and can be downloaded from axis.com/support.
  • Page 11: Verify That No One Has Tampered With The Device Software

    Verify that no one has tampered with the device software To make sure that the device has its original AXIS OS, or to take full control of the device after a security attack: 1. Reset to factory default settings. See .
  • Page 12: Configure Your Device

    This procedure requires physical access to the device. 1. If you’re using the device with AXIS License Plate Verifier, check the tables in for tilt angle recommendations based on mounting height of the device, intended capture distance, and vehicle speed.
  • Page 13 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device To validate the position of the device, add two types of augmented overlays in the camera’s live view. The overlays will help you check that the radar detects vehicles correctly at the intended capture distance.
  • Page 14 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device The camera view is illustrated on the left side, and the radar view with two added lanes in yellow on the right. The passing car is shown as a white track in the radar view, followed by a trail.
  • Page 15: Basic Settings

    Set up a license plate capture solution that can process the images provided by the camera. For more information, see . AXIS License Plate Verifier If you’re going to use AXIS Q1686-DLE with AXIS License Plate Verifier, see AXIS License Plate Verifier user manual for information about how to set up the application.
  • Page 16 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device To adjust the focus: 1. Click to show the autofocus area. 2. Adjust the autofocus area to cover the part of the image that you want to be in focus. If you don’t select an autofocus area, the camera focuses on the entire scene. For traffic scenes where you intend to capture license plates, we recommend that you focus on the lines in the centre of the road.
  • Page 17 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device 1. Go to Video > Image > Day-night mode, and make sure that the IR-cut filter is set to Auto. 2. To use the built-in IR light when the camera is in night mode, turn on Allow illumination and Synchronize illumination.
  • Page 18 3. Use the Tone mapping slider to adjust the amount of WDR. 4. If you still have problems, go to Exposure and adjust the Exposure zone to cover the area of interest. Find out more about WDR and how to use it at axis.com/web-articles/wdr. Stabilize a shaky image with image stabilization Image stabilization is suitable in environments where the product is mounted in an exposed location where vibrations can occur, for example, due to wind or passing traffic.
  • Page 19 5. To add a compass, click Add compass and modify the compass to fit the image. Show license plate overlays License plate overlays are available with the optional application AXIS License Plate Verifier. 1. Go to Video > Image. 2. Click in the live view to access the device’s onscreen controls.
  • Page 20: View And Record Video

    AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device 6. To move the overlay, click Move overlay. View and record video This section includes instructions about configuring your device. To learn more about how streaming and storage works, go to .
  • Page 21: Additional Radar Settings

    With signed video, you can make sure that no one has tampered with the video recorded by the camera. 1. Go to Video > Stream > General and turn on Signed video. 2. Use AXIS Camera Station (5.46 or later) or another compatible video management software to record video. For instructions, see the AXIS Camera Station user manual.
  • Page 22 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device Image requirements: • Supported file formats are jpeg and png. • The orientation is not important, since the radar coverage shape will move to adapt to the image during calibration. Upload the reference map and calibrate it so that the actual radar coverage fits the position, direction and scale of the map.
  • Page 23 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device 3. Select the type of zone that should be included in the scenario. Use the mouse to move and shape the zone so that it covers the desired part of the radar image or reference map.
  • Page 24: Set Up Rules For Events

    AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device 7. Add detection settings. 7.1 Set the time limit between crossing the first and the second line under Max time between crossings. 7.2 Select which object type to trigger on under Trigger on object type.
  • Page 25 Note When you turn on power saving mode, the IR illumination range is reduced. Make sure that AXIS Object Analytics is running: 1. Go to Apps > AXIS Object Analytics. 2. Start the application if it is not already running.
  • Page 26 Provide visual indication of an ongoing event You have the option to connect the AXIS I/O Indication LED to your network camera. This LED can be configured to turn on whenever certain events occur in the camera. For example, to let people know that video recording is in progress.
  • Page 27 8. Create a second rule and select the same Condition as in the first rule. 9. In the list of actions, select Toggle I/O while the rule is active, and then select the port the AXIS I/O Indication LED is connected to.
  • Page 28 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device 13. Set the postbuffer time to 50 seconds. 14. Click Save. Trigger an alarm if someone opens the housing This example explains how to trigger an alarm if someone opens the housing.
  • Page 29 MQTT. This example explains how to set up an MQTT client in the device where you have installed AXIS Speed Monitor, and how to create a condition that will publish the radar data collected in AXIS Speed Monitor as a payload to an MQTT broker.
  • Page 30 AXIS Q1686-DLE Radar-Video Fusion Camera Configure your device Before you start: • Make sure you have installed an SD card. Add a scenario in the radar: 1. Go to Radar > Scenarios. 2. Click + Add scenario. 3. Type the name of the scenario.
  • Page 31: Audio

    Connect to a network speaker Network speaker pairing allows you to use a compatible Axis network speaker as if it is connected directly to the camera. Once paired, the speaker acts as an audio out device where you can play audio clips and transmit sound through the camera.
  • Page 32: The Web Interface

    Device info Shows the device information, including AXIS OS version and serial number. Upgrade AXIS OS: Upgrade the software on your device. Takes you to the Maintenance page where you can do the upgrade. Time sync status Shows NTP synchronization information, including if the device is in sync with an NTP server and the time remaining until the next sync.
  • Page 33: Video

    Shows what kind of access to the device that is active, what encryption protocols are in use, and if unsigned apps are allowed. Recommendations to the settings are based on the AXIS OS Hardening Guide. Hardening guide: Link to AXIS OS Hardening guide where you can learn more about cybersecurity on Axis devices and best practices.
  • Page 34 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Starts the wiper. Click and select a preset position to go to that preset position in the live view. Or, click Setup to go to the preset position page. Adds or removes a focus recall area. When you add a focus recall area, the camera saves the focus settings at that specific pan/tilt range.
  • Page 35 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Installation Capture mode : A capture mode is a preset configuration that defines how the camera captures images. When you change the capture mode, it can affect many other settings, such as view areas and privacy masks.
  • Page 36 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Straighten image : Turn on and use the slider to straighten the image horizontally by rotating and cropping it digitally. The functionality is useful when it’s not possible to mount the camera exactly level. Ideally, straighten the image during installation.
  • Page 37 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Scene profile : Select a scene profile that suits your surveillance scenario. A scene profile optimizes image settings, including color level, brightness, sharpness, contrast, and local contrast, for a specific environment or purpose.
  • Page 38 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface : Turn on to make both bright and dark areas of the image visible. Local contrast : Use the slider to adjust the contrast of the image. A higher value makes the contrast higher between dark and light areas.
  • Page 39 • Move the slider towards Dark to increase the threshold for the IR-cut filter. The camera changes to night mode later. IR light If your device doesn’t have built-in illumination, these controls are only available when you connect a supporting Axis accessory. Allow illumination: Turn on to let the camera use the built-in light in night mode.
  • Page 40 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Exposure mode: • Automatic: The camera adjusts the aperture, gain, and shutter automatically. • Automatic aperture : The camera adjusts the aperture and gain automatically. The shutter is fixed. • Automatic shutter : The camera adjusts the shutter and gain automatically.
  • Page 41 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Motion-adaptive exposure : Select to reduce motion blur in low-light conditions. Blur-noise trade-off: Use the slider to adjust the priority between motion blur and noise. If you want to prioritize low bandwidth and have less noise at the expense of details in moving objects, move the slider towards Low noise.
  • Page 42 Zipstream is a bitrate reduction technology, optimized for video surveillance, that reduces the average bitrate in an H.264 or H.265 stream in real time. Axis Zipstream applies a high bitrate in scenes where there are multiple regions of interest, for example, in scenes with moving objects.
  • Page 43 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface • Average: Select to automatically adjust the bitrate over a longer time period and provide the best possible image quality based on the available storage. Click to calculate the target bitrate based on available storage, retention time, and bitrate limit.
  • Page 44 Label: Enter the text label for the x axis. Time window: Enter how long time the data is visualized. Time unit: Enter a time unit for the x axis. Y axis Label: Enter the text label for the y axis.
  • Page 45: Radar

    AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Privacy masks : Click to create a new privacy mask. Privacy masks: Click to change the color of all privacy masks, or to delete all privacy masks permanently. Cell size: If you choose mosaic color, the privacy masks appear as pixilated patterns. Use the slider to change the size of the pixels.
  • Page 46 Zipstream is a bitrate reduction technology, optimized for video surveillance, that reduces the average bitrate in an H.264 or H.265 stream in real time. Axis Zipstream applies a high bitrate in scenes where there are multiple regions of interest, for example, in scenes with moving objects.
  • Page 47 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Select the bitrate reduction Strength: • Off: No bitrate reduction. • Low: No visible quality degradation in most scenes. This is the default option and it can be used in all types of scenes to reduce the bitrate.
  • Page 48 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Map calibration Use map calibration to upload and calibrate a reference map. This will make it easier to see where objects move in the area covered by the radar. Upload map: Select the reference map you want to upload.
  • Page 49 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface • For Movement in area, select one of the shape presets to modify the area. • For Line crossing, drag and drop the line in the scene. To create more points on a line, click and drag anywhere on it.
  • Page 50 Label: Enter the text label for the x axis. Time window: Enter how long time the data is visualized. Time unit: Enter a time unit for the x axis. Y axis Label: Enter the text label for the y axis.
  • Page 51: Analytics

    Analytics AXIS Object Analytics Start: Click to start AXIS Object Analytics. The application will run in the background, and you can create rules for events based on the application’s current settings. Open: Click to open AXIS Object Analytics. The application opens up in a new window where you can configure its settings.
  • Page 52: Audio

    AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Audio Device settings Input: Turn on or off audio input. Shows the type of input. Input type : Select the type of input, for instance, if it’s internal microphone or line. Power type : Select power type for your input.
  • Page 53: Recordings

    AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Audio enhancement Input Ten Band Graphic Audio Equalizer: Turn on to adjust the level of different frequency bands within an audio signal. This feature is for advanced users with audio configuration experience.
  • Page 54: Apps

    • Activate license with a key: If the app requires a license, you need to activate it. Use this option if your device doesn’t have internet access. If you don’t have a license key, go to axis.com/products/analytics. You need a license code and the Axis product serial number to generate a license key.
  • Page 55 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface The time format depends on the web browser’s language settings. Note We recommend you synchronize the device’s date and time with an NTP server. Synchronization: Select an option for the device’s date and time synchronization.
  • Page 56 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Assign IPv4 automatically: Select to let the network router assign an IP address to the device automatically. We recommend automatic IP (DHCP) for most networks. IP address: Enter a unique IP address for the device. Static IP addresses can be assigned at random within isolated networks, provided that each address is unique.
  • Page 57 One-click cloud connection One-click cloud connection (O3C) together with an O3C service provides easy and secure internet access to live and recorded video from any location. For more information, see axis.com/end-to-end-solutions/hosted-services. Allow O3C: • One-click: This is the default setting. Press and hold the control button on the device to connect to an O3C service over the internet.
  • Page 58 Authentication failed: Sends a trap message when an authentication attempt fails. Note All Axis Video MIB traps are enabled when you turn on SNMP v1 and v2c traps. For more information, see AXIS OS Portal > SNMP. • v3: SNMP v3 is a more secure version, which provides encryption and secure passwords. To use SNMP v3, we recommend you to activate HTTPS, as the password is then sent through HTTPS.
  • Page 59 When configured without a CA certificate, server certificate validation is disabled and the device tries to authenticate itself regardless of what network it is connected to. When using a certificate, in Axis' implementation, the device and the authentication server authenticate themselves with digital certificates using EAP-TLS (Extensible Authentication Protocol - Transport Layer Security).
  • Page 60 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface These settings are only available if you use IEEE 802.1x PEAP-MSCHAPv2 as the authentication method: • Password: Enter the password for your user identity. • Peap version: Select the Peap version that is used in the network switch.
  • Page 61 To install test software or other custom software from Axis on the device, you need a custom signed AXIS OS certificate. The certificate verifies that the software is approved by both the device owner and Axis. The software can only run on a specific device which is identified by its unique serial number and chip ID.
  • Page 62 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Add SSH account: Click to add a new SSH account. • Restrict root access: Turn on to restrict functionality that requires root access. • Enable SSH: Turn on to use SSH service.
  • Page 63 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Add a rule: Create a rule. Name: Enter a name for the rule. Wait between actions: Enter the minimum time (hh:mm:ss) that must pass between rule activations. It is useful if the rule is activated by, for example, day-night mode conditions, to avoid that small light changes during sunrise and sunset activate the rule repeatedly.
  • Page 64 RSA is the preferred method during negotiation, followed by ECDSA, ED25519, and DSA. Make sure to enter the right MD5 host key that is used by your SFTP server. While the Axis device supports both MD5 and SHA-256 hash keys, we recommend using SHA-256 due to stronger security over MD5. For more information on how to configure an SFTP server with an Axis device, go to the AXIS OS Portal.
  • Page 65 IoT integration and is used in a wide variety of industries to connect remote devices with a small code footprint and minimal network bandwidth. The MQTT client in Axis device software can simplify integration of data and events produced in the device to systems which are not video management software (VMS).
  • Page 66 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Connect: Turn on or off the MQTT client. Status: Shows the current status of the MQTT client. Broker Host: Enter the hostname or IP address of the MQTT server. Protocol: Select which protocol to use.
  • Page 67 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Use default: Turn off to enter your own default message. Topic: Enter the topic for the default message. Payload: Enter the content for the default message. Retain: Select to keep the state of client on this Topic QoS: Change the QoS layer for the packet flow.
  • Page 68 DNS. Windows SMB/CIFS names are not supported. • Network share: Enter the name of the shared location on the host server. Several Axis devices can use the same network share since each device gets its own folder.
  • Page 69 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Retention time: Select how long to keep recordings, to limit the amount of old recordings, or to comply with regulations regarding data storage. If the SD card becomes full, old recordings are removed before the selected time period has passed.
  • Page 70 When you create an ONVIF account, you automatically enable ONVIF communication. Use the account name and password for all ONVIF communication with the device. For more information see the Axis Developer Community at axis.com. Add accounts: Click to add a new ONVIF account.
  • Page 71 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Add media profile: Click to add a new ONVIF media profile. Profile name: Add a name for the media profile. Video source: Select the video source for your configuration. • Select configuration: Select a user-defined configuration from the list. The configurations in the drop-down list correspond to the device's video channels, including multiviews, view areas and virtual channels.
  • Page 72 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface Producer: The app that produces the metadata. Below the app is a list of the types of metadata the app streams from the device. Channel: The channel that the app uses. Select to enable the metadata stream. Deselect for compatibility or resource management reasons.
  • Page 73 Edge-to-edge Audio pairing allows you to use a compatible Axis network speaker as if it’s part of the main device. Once paired, the network speaker acts as an audio out device where you can play audio clips and transmit sound.
  • Page 74 AXIS Q1686-DLE Radar-Video Fusion Camera The web interface PTZ pairing Address: Enter host name or IP address of the PTZ camera. Username: Enter the username of the PTZ camera. Password: Enter the password for the PTZ camera. Clear fields: Click to clear all fields.
  • Page 75: Maintenance

    AXIS OS upgrade: Upgrade to a new AXIS OS version. New releases can contain improved functionality, bug fixes, and completely new features. We recommend you to always use the latest AXIS OS release. To download the latest release, go to axis.com/support.
  • Page 76 AXIS OS version after the upgrade. • Autorollback: Upgrade and confirm the upgrade within the set time. If you don’t confirm, the device reverts to the previous AXIS OS version. AXIS OS rollback: Revert to the previously installed AXIS OS version.
  • Page 77: Long-Distance Connections

    AXIS Q1686-DLE Radar-Video Fusion Camera Learn more Learn more Long-distance connections This product supports fiber-optic cable installations through a media converter. Fiber-optic cable installations offer a number of benefits such as: • Long-distance connection • High speed • Long lifetime •...
  • Page 78 H.264 or MPEG-4 Part 10/AVC Note H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. To install additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller. H.264 can, without compromising image quality, reduce the size of a digital video file by more than 80% compared to the Motion JPEG format and by as much as 50% compared to older MPEG formats.
  • Page 79 AXIS Q1686-DLE Radar-Video Fusion Camera Learn more Maximum bitrate (MBR) Maximum bitrate lets you set a target bitrate to handle bitrate limitations in your system. You might see a decline in image quality or frame rate as the instantaneous bitrate is kept below the specified target bitrate. You can choose to prioritize either image quality or frame rate.
  • Page 80: Cybersecurity

    Signed OS Signed OS is implemented by the software vendor signing the AXIS OS image with a private key. When the signature is attached to the operating system, the device will validate the software before installing it. If the device detects that the integrity of the software is compromised, the AXIS OS upgrade will be rejected.
  • Page 81 This ensures no data stored in the file system can be extracted or tampered with when the device is not in use, unauthenticated access to the device is achieved and/or the Axis device is stolen. During the secure boot process, the read-write filesystem is decrypted and can be mounted and used by the Axis device.
  • Page 82: Specifications

    AXIS Q1686-DLE Radar-Video Fusion Camera Specifications Specifications Product overview Weathershield Window Radar Light sensor IR illumination LED Optical unit Cable cover Intrusion alarm sensor Safety wire 10 Intrusion alarm magnet...
  • Page 83: Led Indicators

    AXIS Q1686-DLE Radar-Video Fusion Camera Specifications 11 I/O connector 12 RS485/RS422 connector 13 Power connector 14 Network connector (PoE) 15 microSD card slot 16 Audio out 17 Audio in 18 Status LED 19 Control button 20 Cable gasket M20 2x...
  • Page 84: Buttons

    AXIS Q1686-DLE Radar-Video Fusion Camera Specifications microSD, microSDHC, and microSDXC Logos are trademarks of SD-3C LLC. microSD, microSDHC, microSDXC are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both. Buttons Control button The control button is used for: •...
  • Page 85 AXIS Q1686-DLE Radar-Video Fusion Camera Specifications I/O connector Use the I/O connector with external devices in combination with, for example, motion detection, event triggering, and alarm notifications. In addition to the 0 V DC reference point and power (12 V DC output), the I/O connector provides the interface to: Digital input - For connecting devices that can toggle between an open and closed circuit, for example PIR sensors, door/window contacts, and glass break detectors.
  • Page 86 AXIS Q1686-DLE Radar-Video Fusion Camera Specifications Power connector 2-pin terminal block for DC power input. Use a Safety Extra Low Voltage (SELV) compliant limited power source (LPS) with either a rated output power limited to ≤100 W or a rated output current limited to ≤5 A.
  • Page 87 AXIS Q1686-DLE Radar-Video Fusion Camera Clean your device Clean your device You can clean your device with lukewarm water. NOTICE TICE TICE • Harsh chemicals can damage the device. Don’t use chemicals such as window cleaner or acetone to clean your device.
  • Page 88: Troubleshooting

    Using AXIS OS from the active track is recommended if you want to access the newest features, or if you use Axis end-to-end system offerings. The LTS tracks are recommended if you use third-party integrations, which are not continuously validated against the latest active track.
  • Page 89: Upgrade Axis Os

    Note When you upgrade the device with the latest AXIS OS version in the active track, the product receives the latest functionality available. Always read the upgrade instructions and release notes available with each new release before you upgrade. To find the latest AXIS OS version and the release notes, go to axis.com/support/device-software.
  • Page 90: Performance Considerations

    IP addresses obtained from a DHCP server are dynamic and may change. If the IP address has been changed by DHCP changed, use AXIS IP Utility or AXIS Device Manager to locate the device on the network. Identify the device using its model or serial number, or by the DNS name (if the name has been configured).

Table of Contents
