1 Appearance
Quick Play
Button
UD36755B
Intercom Panel
Interface(Reserved)
Gooseneck Debug
Microphone Interface
Interface
186.7 mm
Screen
Emergency
Broadcast
Button
Microphone
Intercom/Broadcast
Button (Reserved)
Network Interface
3.5 mm Audio Power Input
Interface Interface
Speaker
TF Card Slot
144.7 mm
Quick play button: F1 to F6 quick setting button, you can set paly
parameters.
Emergency broadcast button: support quick emergency broadcast,
you can set according to your needs.
Gooseneck microphone interface: it can be connected to the
gooseneck microphone supplied in the package.
3.5 mm audio interface: support 3.5 mm audio source input/output.
3.5 mm input should be used together with the non-standard 3.5 mm
to RCA cable supplied in the package. Otherwise, there will be no
sound or the sound will be low.
Power input interface: support 12 VDC/2 A power input.
TF card slot: It has a 4 GB TF card by default. It is not recommended
for replacement.
