- Page 1 Indoor Security Microphone User Manual...
- Page 2 Products described in this Document, which may include licenses obtained from third parties. ● Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission.
- Page 3 RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES. ● IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE LATTER PREVAILS. © Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
- Page 4 Indoor Security Microphone • User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected.
- Page 5 Indoor Security Microphone • User Manual If the device supports wall mounting, the mounting surface shall be able to withstand the additional force of three times the weight of the device but not less than 50 N. The device and its associated mounting means shall remain secure during the installation.
- Page 6 Indoor Security Microphone • User Manual + identifies the positive terminal(s) of equipment which is used with, or generates direct current. - identifies the negative terminal(s) of equipment which is used with, or generates direct current. DO NOT touch the heat dissipation component to avoid burns. ...
-
Page 7: Table Of Contents
Indoor Security Microphone • User Manual Contents Chapter 1 Overview ........................1 Product Features............................1 Packing List ..............................1 Appearance and Interfaces..........................2 Connection ..............................3 Chapter 2 Installation and Application ................... 4 Installation ..............................4 Cable Routing..............................4 WEB Configuration ............................5 Chapter 3 FAQ .......................... -
Page 8: Chapter 1 Overview
Indoor Security Microphone • User Manual Chapter 1 Overview Product Features The main features of the device are as follow: With high sensitivity and high fidelity, this microphone can pick up sounds which come from all directions, including a clear sound and high anti-disruption ability. ... -
Page 9: Appearance And Interfaces
Indoor Security Microphone • User Manual Packing List Item Description Amount Microphone Installation Plate User Manual Screws Sticker Appearance and Interfaces Indicator Volume light adjustment knob Bottom of the Device Light on: the device is normal working. Light off: the device is damaged or powered off. -
Page 10: Connection
Indoor Security Microphone • User Manual cable and connector Connection Camera Power Adapter Connection I Camera Connection II... -
Page 11: Chapter 2 Installation And Application
Indoor Security Microphone • User Manual Chapter 2 Installation and Application Installation Before you start The device is suitable for ceiling mounting, and it can also be placed on the desktop for use. Attach the installation sticker to the wall. (Optional) For cement wall, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs before installation. -
Page 12: Web Configuration
Indoor Security Microphone • User Manual WEB Configuration When the camera connects to the network, you can configure the audio parameters of the camera via web browser. Refer to the user manual of the camera for detailed description. Go to ConfigurationVideo&AudioAudio to adjust the following parameters in order to improve the audio quality. - Page 13 Indoor Security Microphone • User Manual Answers Check if the cables are connected correctly. Poor quality of the cable and the cable connector may cause poor sound quality, such as low sound and high noise. Solution: Connect the device shell to the ground by cable, and use the twisted pair cable with good shielding performance.
- Page 14 UD37247B...
