Kenwood GE-90 Instruction Manual

STEREO GRAPHIC EQUALIZER
GE-I0
@KENWOOD
INSTRUCTION MANUAL
DEAR AUDIO FAN
The purpose of this manual is to acquaint you with the
operating features of your new equalizer. You will notice that
in every detail of planing, engineering, styling, operating con-
venience. and adaptability, w e have sought t o anticipate your
needs and desires.
We suggest that you read this manual carefully. Knowing
h o w to set up your equalizer to the best advantage will
enhance your listening pleasure right from the start. You will
also become aware of the ease with which you can adjust
your equalizer to meet your special requirements.
FOR YOUR RECORDS
Record the serial number, found on the back of the unit, in
the spaces designated on the warranty card, and in the space
provided below. Refer to the model and serial numbers
whenever you call upon your Kenwood dealer for information
or service on this product.
Model GE-90 Serial number
AFTER UNPACKING
After unpacking, we recommend that you inspect the unit
for any possible shipping damage. If your unit is damaged or
fails to operate, notify your dealer immediately. If your unit
was shipped t o you directly, notify the shipping company
without delay. Only the consignee (the person or company
receiving the unit1 can file a claim against the carrier for ship-
ping damage.
We recommend that you retain the original carton and
packing materials to prevent any damage should you
transport or ship your unit in the future.
INSTALLATION PRECAUTIONS
a1 Avoid locations subject t o direct sunlight.
b) Avoid high or low temperature extremes.
c ) Keep the unit away from heat radiating sources.
d l Choose a location that is relatively free of vibration or ex-
e )
Make sure power is aff before making any system ccnnec-
t
cessive dust.
tions.
SAFETY PRECAUTIONS
CLEANING
Do not use volatile solvents such as alcohol, paint thinner.
gasoline, benzine. etc t o clean the cabinet Use a silicone
cloth or a clean dry cloth
SERVICE OR MODIFICATIONS
Do not remove the cabinet or touch internal parts Refer
all service to qualified service personnel Unauthorized
+
modifications can result in a dangerous shock hazard and can
void the warranty
IMPORTANT!
U.S.A. AND CANADA
Units shipped to the U
S
A and Canada are design
ed for operation on 1 2 0 volts AC only These units are
not equipped with an AC Voltage Selector switch and
the discussion of such a switch that follows should be
disregarded
ALL OTHER COUNTRIES
Units shipped to countries other than the U
S
A and
Canada are equipped with an AC Voltage Selector
switch on the rear panel
Refer to the following paragraph for the proper setting
of this switch
AC VOLTAGE SELECTION
This unit operates on 1
10
1 2 0 volts or 2 2 0 - 2 4 0 volts
AC The AC Voltage Selector Switch on the rear panel is set to
the voltage that prevails in the area to which the unit
IS
ship-
ped Before connecting the power cord to your AC outlet,
make sure that the setting position of this switch matches
your line voltage If not, it must be set to your voltage in ac-
cordance with the following direction
Note:
~
Our
warranty does not cover damage caused
by
excesslve
line
voltage due to improper
setting of
the
AC
Voltage Selector Switch
1 lO-l20V%4b220-24OV% 1 1 0 - 1 2 0 V % 4 b 220-24OV-
I
Switch lever
This shows switch
lever is locked in
1 1 0 - 1 ZOV%position.
This shows switch
lever is locked
in
220-240V%position.
Move switch lever to match your line
voltage with a small screw driver or other
pointed tool,
I
AC VOLTAGE SELECTOR SWITCH
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
PRINTED IN JAPAN 6 5 0 - 3 3 5 4 - 0 0 (KPUMHUEXI (TI
