READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YFM70RSBJ
YFM70RSXJ
YFM70RSSJ
WARNING
This ATV should not be ridden by anyone under 16 years of age.
LIT-11626-31-16
2LS-F8199-13
