Summary of Contents for KISTERS HydroMet HailSens IoT
- Page 1 User Manual HailSens IoT 06-2024 – 01-03-002...
-
Page 2: Table Of Contents
Maintenance Part V Overall Visual Check ........................19 General Cleaning ........................19 5.2.1 Dos and Don’ts ........................19 Troubleshooting Part VI Repair Part VII Technical Data Part VIII Obligations of the Operator and Disposal Part IX © 2024 | KISTERS... -
Page 3: I Disclaimer
KISTERS has been advised of the © 2024 | KISTERS. Any rights not expressly granted herein possibility of such damages. -
Page 4: Glossary + Abbreviations
Universal Serial Bus, industry standard defining cables, connectors and communication protocols for serial data transmission between computers and devices. Micro-USB is a very small USB port. Volts in direct current. SI unit symbol of the “watt”, a unit of power. © 2024 | KISTERS... -
Page 5: Scope Of Delivery
Hail Sensor IoT (pre-mounted unit) § Pole mounting bracket (pre-mounted) § Power connection cable M12 4-pin (10 m) § Tools: open-ended wrench, Allen key, RJ45 protection cap, SMA antenna cap § FAT document § Quick Installation Guide © 2024 | KISTERS... -
Page 6: Safety Instructions
KISTERS website. § Disposal instructions: After taking the KISTERS HailSens IoT out of service, it must be disposed of in compliance with local waste and environmental regulations. The KISTERS HailSens IoT is never to be disposed in household waste! §... -
Page 7: Specific Safety Instructions
HailSens IoT is equipped with a bird guard exposing metal spikes. Wear gloves and safety glasses while installing the sensor. § Pinch points: Caution when mounting the device! Do not put your fingers between the pole mount bracket and the pole. © 2024 | KISTERS... -
Page 8: Part I Introduction
In typical setups, HailSens IoT will transmit data to the optional KISTERS datasphere, an online data management tool providing functionality ranging from data reception and storage to visualisation and alarming. Please contact your sales representative for details. -
Page 9: Part Ii Installation
Note: To access the configuration menu locally, open the cover of the electronics box and connect your laptop to the processing board using a USB cable. Using the USB connection requires the installation of a USB driver (Part III Configuration 7. The sensor starts working HailSens IoT: Mechanical Dimensions Figure 2 – Dimensions in mm © 2024 | KISTERS... -
Page 10: Pole Mounting
Figure 3 – HailSens IoT Pole Mount Bracket with Bolts and Washers The pole mount bracket is designed for poles of a diameter between 1.5” and 4”. Figure 4 – Pole-Mount Bracket mounted on a Pole © 2024 | KISTERS... -
Page 11: Selecting A Suitable Installation Site
In hilly terrain or in mountainous areas, the sensor plate should be at 2 m above the ground. This is to avoid cluttering in snow during the winter period. Figure 5 - HailSens installation and recommended distance from large obstacles © 2024 | KISTERS... -
Page 12: Electrical Bonding (Earth)
Qualified personnel: Ensure that installations and inspections are carried out by qualified electricians familiar with local codes and standards. Note: Regulations take precedence over manufacturer recommendations. Figure 6 - HailSens Earth stud / grounding Figure 7 - HailSens equipotential bonding © 2024 | KISTERS... -
Page 13: External Cable Connection
It is important to note that a damaged pressure compensation gland will corrupt the protective function of the enclosure. The position of the connectors is illustrated in the following figure: Figure 8 - Connectors at the bottom and right side of the housing © 2024 | KISTERS... -
Page 14: Connecting The Ethernet Cable
SIM card, antenna and antenna cable are optional items that can be purchased from KISTERS (if desired). Note: In some regions, individual network providers may deny access to unregistered devices. Make sure you are on a network operated by a provider that does not require pre-qualification/registration of devices. - Page 15 The parameters that can be edited by the user are listed and briefly explained in the following table. After applying changes in the NETWORK section, a reboot of the device is required to activate the settings. To perform the reboot, disconnect the device from the power-source for at least 5 seconds. © 2024 | KISTERS...
-
Page 16: Lte-M Wireless Data Transmission (Mobile Comms)
Initial settings must be made in order to use the HailSens IoT with the data SIM card installed. Use a SIM card that is either data-only or has data tariffs activated. Phone calls using data communication require an exclusive application. © 2024 | KISTERS... -
Page 17: Ethernet Data Transmission (Static Comms)
The factory setting is set to DHCP which allows to access the unit after connecting to the network providing an according DHCP-Server. In case that this is not available, install the supplied USB-Driver-Package to your computer and connect it to the Mini-USB port of the integrated data logger/modem. © 2024 | KISTERS... -
Page 18: Hailsens Iot: Electronics
JSON is a minimal, readable format for structuring data. § KISTERS datasphere users: API and data formats are of no particular interest for users whose HailSens device(s) is (are) reporting directly to KISTERS datasphere (optional Cloud-based data management). §... -
Page 19: Overall Visual Check
Do not apply cleaners under direct sunlight or at elevated temperatures. § Do not clean the polycarbonate transducer plate with any unapproved cleaners. When in doubt, seek guidance. § Using scrapers, squeegees, razors or other sharp instruments may permanently scratch the polycarbonate transducer plate. © 2024 | KISTERS... -
Page 20: Part Vi Troubleshooting
Note: Although the data is stored in a memory that retains the data in the event of a power loss, it is always advisable to take precautions: § Save all hail data and configuration settings before power cycling the HailSens. © 2024 | KISTERS... - Page 21 Ensure that the device firmware is up-to-date. Follow the manufacturer's instructions for updating the firmware. § Check that any companion software (such as KISTERS datasphere or your own application receiving data from the HailSens) is up-to-date and correctly configured. Network Configuration §...
-
Page 22: Part Vii Repair
§ Please do not ship the goods prior to obtaining the reference number. KISTERS will not reject any equipment that arrives without reference number; however, it may take us longer to process. Custom requirements for items sent to KISTERS for warranty or non-warranty repairs: Check with your national customs/tax authorities for details, processes and paperwork regarding tax exempt return of products. -
Page 23: Part Viii Technical Data
Transducer plate (round): Ø 500 mm (19.685“) Dimensions § Mounting: 2” to 4” pole on a heavy concrete ground plate: (500 x 500 x 50) mm (L x B x H) Height: 300 mm Weight 6 kg net © 2024 | KISTERS... -
Page 24: Part Ix Obligations Of The Operator And Disposal
At the end of its service life, the lithium-ion battery must be disposed of according to legal provisions. EU WEEE Directive As players in the environmental market, KISTERS AG is committed to supporting efforts to avoid and recycle waste. Please consider: §... - Page 25 +64 7 857 0810 sales@kisters.co.nz www.kisters.co.nz Latin America | KISTERS Latin America +57 350 575 4079 sales@kisters-latam.com www.kisters-latam.com North America | KISTERS North America +1 561 459 4876 kna@kisters.net www.kisters.net Spain | KISTERS Ibérica info@kisters.es www.kisters.es © 2024 | KISTERS...
- Page 26 © 2024 | KISTERS 14/06/2024 © 2024 | KISTERS...
