CINCINNATI FAN
Arrangement 8 centrifugal blower
Models PB - PBS - SPB - LM - HP I - HP II -RBE - RTE - HDBC - HDAF - HDBI - HPBC
I N STA L L AT I O N - O P E R AT I O N - M A I N T E N A N C E
CF-03-IOM-24
ISSUED 06/2024
Blower Serial Number
READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING OR SERVICING THIS PRODUCT
RBE Centrifugal Blower
u s e r m a n u a l
Advertisement
Table of Contents
Related Manuals for Cincinnati Fan Arrangement 8 PB
Summary of Contents for Cincinnati Fan Arrangement 8 PB
- Page 1 CINCINNATI FAN u s e r m a n u a l Arrangement 8 centrifugal blower Models PB - PBS - SPB - LM - HP I - HP II -RBE - RTE - HDBC - HDAF - HDBI - HPBC...
- Page 2 Altitude ft Airstream Temperature °F Do Not Exceed this RPM Fan RPM Maximum Safe Fan RPM Motor Data: (This section is completed only if the motor was supplied by Cincinnati Fan) Voltage Phase Frame Size Enclosure Efficiency If Motor is EXP, Class(es) and Group(s) are Manufacturer’s Model Number...
-
Page 3: Table Of Contents
contents This manual contains vital information for the proper installation and Note operation of your blower fan. Carefully read the manual before installa- tion or operation of the blower fan and follow all instructions. Save this manual for future reference. General ................................ -
Page 4: General
general Receiving Unpacking Be careful not to damage or deform any parts of the blower when removing it from the packaging container. All the packaging material should be kept in the event the blower needs to be returned. Handling Handling of the blower should be performed by trained personnel and be consistent with all safe handling practices. - Page 5 general Never operate a blower with a non-ducted inlet and/or discharge. If the Caution blower inlet and/or discharge is non-ducted, it is the users responsibility to install an inlet and/or discharge guard. Temperature Many blowers, blower components and all motors operate at temperatures that could burn someone if they come in contact with them.
-
Page 6: Installation
installation Installation Vibration Before any mounting method is selected, the user should be aware of the ef- fects vibration will have on the blower, motor and other parts. Improper blower installation can cause excessive vibration causing premature wheel and/or motor bearing failure, that is not covered under warranty. Vibration eliminator pads, springs or bases should be properly installed to prevent any blower vibration from transmitting to the foundation, support structure or ducting. -
Page 7: Duct Work Connections
Safety Guards Cincinnati Fan offers guards, as optional, to keep your blower in compliance with OSHA safety regulations. These include inlet or discharge guards. Any blowers built with high temperature construction, a “heat slinger guard” is standard. -
Page 8: Set Screw And Taper-Lock Bushing Torque Values
installation motor. Any airflow control device, with bearings, should be maintained in ac- cordance with the manufacturer’s instructions. Any air flow control device, with an automatic control mechanism, should be adjusted per the manufacturer’s recommendations Set Screw and Taper-Lock Bushing Torque Values All blower wheel set screws are tightened to the proper torque prior to ship- ment. -
Page 9: Electrical
installation factory. The blower shaft/bearing/coupling guard (if included) should only be removed for inspection before start-up and during inspection or maintenance but only after the power to the motor has been turned off and locked out. The blower shaft/bearing/coupling guard must be replaced before the power is turned back on. - Page 10 installation that should be replaced with grease fittings to perform re-lubrication. These motors, or any motor with grease fittings, should be lubricated in accordance with the motor manufacturers recommendations. Lubrication frequency depends on the motor horsepower, speed and service. Be sure you use compatible grease and Do not over grease.
-
Page 11: Maximum Blower Speed And Speed Controllers
Fan or the sales office for your area. You must have the serial number from the blower name plate for us to determine the maximum safe blower speed. Cincinnati Fan will only extend the motor manufacturers warranty, when used with a speed controlling device, if the motor has the words Inverter Duty marked on the motor name plate. -
Page 12: Initial Unit Startup
operation Initial Unit Startup Pre-Startup and Post-Startup Check (Check blocks as each step is completed. Retain for you records) Failure to complete and document all the following Pre-Startup checks, Note Post-Startup checks and Vibration checks, could void all warranties. Pre-Startup Check completed by: Date Eight Hour Post-Startup Check completed by: Date... -
Page 13: Vibration
operation Pre-Startup Check completed by: Date Eight Hour Post-Startup Check completed by: Date Three-Day Post-Startup Check completed by: Date Make sure the blower wheel is stationary prior to startup. Starting a blower with a wheel that is rotat- n n n n n n ing backwards can cause wheel damage. - Page 14 operation The blower Should Not be operated if the vibration velocity of the blower Caution exceeds 0.40 inches per second, filter out, if the blower is rigidly mounted. If the blower is mounted on isolators or on an isolator base, it Should Not be operated if the vibration velocity of the blower exceeds 0.65 inches per second, filter out.
- Page 15 operation A—Pre-Startup Check completed by: Date B—Eight Hour Post-Startup Check completed by: Date C—Three-Day Post-Startup Check completed by: Date Alarm, vibration isolator mount (.65) Alarm, rigid mount (.40) Normal, vibration isolator mount (.35) Normal, rigid mount (.25) Figure 4 Vibration Severity Graph...
-
Page 16: Routine Inspection And Maintenance
If the operating conditions of the blower are to be changed (speed, pressure, temperature, etc.) consult Cincinnati Fan or our sales office in your territory to determine if the unit will operate safely at the new conditions. -
Page 17: Wheel Balance
maintenance Do not over grease the blower bearings. Generally, 1-2 shots should be enough. Use a hand-operated grease gun at no more than 40 psi. If possible, carefully lubricate the blower bearings while the blower is running. Lubrication frequencies are based on the fan bearings operating in a clean and dry environment from -20°F (-29°C) up to 120°F (49°C). -
Page 18: Vibration
Make sure you reinstall the wheel so the proper wheel-to-inlet clearance is maintained. Failure to do this will affect the blower’s airflow (CFM), and/or static pressure (SP) capabilities and ef- ficiency. Consult Cincinnati Fan or our local sales office for your area for assistance if necessary. Vibration As mentioned previously in this manual, excessive vibration can cause prema- ture motor failure that could lead to catastrophic failure of the blower. -
Page 19: Blower Shaft Or Bearing Replacement
Blower Shaft and Bearing Replacement: The blower shaft and bearings for Cincinnati Fan blowers are carefully selected to match the maximum load and operating conditions for each specific blower model. If the instructions in this manual and those provided by the bearing manufacturer are followed, you should not need to replace the bearings for many years. - Page 20 maintenance 15. When replacing the bearings, we strongly recommend that the blower shaft and blower/motor coupling also be replaced. However, if you intend to use the same blower shaft, file down all the setscrew marks on the shaft. 16. Install new bearings onto the new blower shaft or onto the original shaft. Be sure the bearing locking collars are facing each other and the set screws are in line with each other.
- Page 21 maintenance 32. While rotating the blower shaft, lubricate blower bearings with fresh grease per Blower Bearing Lubrication instruction in this manual. 33. Install new set screws into the wheel, or taper-lock hub bolts into the hub. Do not use old screws or bolts. 34.
-
Page 22: Dampers And Valves
Replacement Parts Under normal conditions, you should not need any spare or replacement parts for at least 24 months after shipment from Cincinnati Fan. That does not include any wear due to abrasion, corrosion, excessive temperatures, abuse, misuse, accident or any severe conditions the fan was not designed for. -
Page 23: Troubleshooting
maintenance Troubleshooting Potential problems and causes listed below are in no order of importance or priority. The causes are only a list of the most common items to check to correct a problem. If you find the cause of a problem, do not assume it is the only cause of that problem. -
Page 24: Long Term Storage
maintenance Wheel rubbing inside of housing Worn or corroded blower wheel Accumulation of foreign material on blower wheel Loose mounting bolts, set screws or taper-lock hub bolts, bearings or couplings Misalignment of blower bearings or coupling Bent motor or blower shaft Excessive Noise Worn motor and/or blower bearings Motor out of balance... - Page 25 information A periodic inspection and maintenance log, by date and action taken, Note must be developed and maintained for each blower. See example below. Each item must be checked monthly. Storage/Maintenance Schedule Log Example Action Date Checked Reinspect units to insure any protective devices used are functioning properly.
-
Page 26: Warranty, Limits Of Liability, Responsibility And Returns
Limited Warranty Cincinnati Fan and Ventilator Company (Seller) warrants products of its own manufacture, against defects of material and workman-ship under normal use and service for a period of eighteen (18) months from date of shipment or twelve (12) months from date of installation, whichever occurs first. This warranty does not apply to any of Seller’s products or any part thereof which has been... - Page 27 Purchaser’s and/or User’s compliance with any Federal, State and local regulations. Returns Cincinnati Fan & Ventilator Company assumes no responsibility for any mate- rial returned to our plant without our permission. An RMA (Return Material Authorization) number must be obtained and clearly shown on the outside of the carton or crate and on a packing slip.
- Page 28 Centrifugal Blower U S E R M A N UA L SPX ENGINEERED AIR MOVEMENT CF-03-IOM-24 ISSUED 06/2024 ©2024 SPX ENGINEERED AIR MOVEMENT ALL RIGHTS RESERVED 7697 SNIDER ROAD In the interest of technological progress, all products are subject to design T E C H N O L O G I E S MASON, OH 45040 USA and/or material change without notice.
- Page 29 Sure-Flex Plus Coupling ® Flange Types J, S, SC, B, C Installation Instructions P-7888-TBW...
- Page 30 Lock out / tag out the power source 3. Slide one flange onto each shaft using keys before proceeding to avoid unexpected starts. where required. (When using Type B flanges, Failure to observe these precautions could result in follow the instructions furnished with the Sure bodily injury.
- Page 31 8. Tighten motor and driven equipment fasteners 10. If the coupling uses a two-piece sleeve with the to manufacturer specifications; recheck parallel wire ring, move the ring into its groove in the and angular alignment. center of the sleeve. If necessary, use soapy water and lever the ring with a wrench or blunt 9.
- Page 32 TB Wood’s Facilities TB Wood’s Facilities North America Europe Canada Merchant Drive, Hertford 440 North Fifth Avenue 12759 149 Street NW Hertfordshire SG13 7BL - England Chambersburg, PA 17201 - USA Edmonton, AB T5L 4M9 - Canada +44(0)1992 501900 888-829-6637 • 717-264-7161 1-800-829-6631 Elastomeric Couplings Belted Drives and Elastomeric...
