Cincinnati Fan CPF Installation, Safety, Operation & Maintenance Manual Amd Parts List

Advertisement

Quick Links

Installation, Safety, Operation & Maintenance Instructions And Parts List
READ ENTIRE MANUAL, INCLUDING "SECTION IV. INITIAL UNIT STARTUP" BEFORE
BLOWER SERIAL NUMBER: ________________________
NOTE:
The serial number above is a required reference for any assistance. It is stamped on the blower nameplate.
BLOWER SPECIFICATIONS:
Model: ________
Wheel Size and Type: ___________________
BLOWER PERFORMANCE DATA: (If entered on order)
CFM: ________
Density: ________
Fan RPM: ________
MOTOR DATA: (This section is completed only if the motor was supplied by Cincinnati Fan)
HP: __________ RPM: ____________ Voltage: ______________________________ Phase:________
Hz: ___________
IF Motor is EXP, Class(es) & Group(s) are:_________________________
Manufacturers Model Number: ___________________________ CFV Part Number: ___________
DRIVE DATA:
Fan Sheave: ______________
No. of Grooves: ___________ Fixed Speed:
All Cincinnati Fan products are packaged to minimize any damage during shipment. The freight carrier is responsible
for delivering all items in their original condition as received from Cincinnati Fan. The individual receiving this equipment
is responsible for inspecting this unit for any obvious or concealed damage. If any damage is found, it should be noted
on the bill of lading before the freight is accepted and the receiver must file a claim with the freight carrier.
If this blower will NOT be installed and put into operation within 30 days, refer to the "Long Term Storage
Instructions" on page 15. Failure to follow all applicable long term storage instructions, will void your warranty.
This blower should be stored indoors in a clean, dry location.
For Models CPF and CPAF
Arrangement 9 Blowers.
ATTEMPTING TO INSTALL AND OPERATE THIS EQUIPMENT.
BLOWER SPECIFICATIONS
Arrangement: ________
SP: ________ (Inches of Water Gauge)
Altitude: ________ (Ft. above S.L.)
Maximum Safe Fan RPM: ____________
Frame Size: ___________ Enclosure: ____________
Motor Sheave: _______________ Belts: ______________
ATTENTION: RECEIVING DEPARTMENT
LONG TERM STORAGE NOTICE
NOTE
MFG. DATE: ____________________
Rotation: ________
Motor BHP: ________
Airstream Temperature: ________°F.
I I
Adjustable Speed:
Form: OMM-11-0211
Effective: 2/21/11
Supersedes: OMM-11-0509
Part No.: 01226
DO NOT EXCEED THIS RPM
Efficiency: ____________
I I
OMM-11-0211-page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPF and is the answer not in the manual?

Questions and answers

Summary of Contents for Cincinnati Fan CPF

  • Page 1 All Cincinnati Fan products are packaged to minimize any damage during shipment. The freight carrier is responsible for delivering all items in their original condition as received from Cincinnati Fan. The individual receiving this equipment is responsible for inspecting this unit for any obvious or concealed damage. If any damage is found, it should be noted on the bill of lading before the freight is accepted and the receiver must file a claim with the freight carrier.
  • Page 2: Table Of Contents

    All installers, operators and maintenance personnel should read AMCA Publication 410-96, “Recommended Safety Practices for Users and Installers of Industrial and Commercial Fans”. This manual is included with the blower. Additional copies can be requested by writing us at Cincinnati Fan, 7697 Snider Rd., Mason, OH 45040-9135 2. Sound: Some blowers can generate sound that could be hazardous to personnel.
  • Page 3: Safety Instructions & Accessories

    The blower wheel for this model blower was dynamically balanced before assembly. The completed blower was also tested at the operating speed to make sure it conformed to Cincinnati Fan vibration limits. However, proper mounting is necessary to make sure the blower will operate smoothly. The vibration levels this blower will acturally operate at will depend on how rigidly the blower is mounted.
  • Page 4: Safety Guards

    Arrangement 9 blowers come with belt guards as standard.The base design on Models CPF and CPAF also acts as a shaft and bearing guard as long as the access holes are closed. With any blowers built with high temperature construction, a heat slinger guard is standard. It is the responsibility of the user to make sure this blower meets all local, state and OSHA safety regulations.
  • Page 5: Set Screw And Taper-Lock Bushing Torque Values

    If you do not know the maximum safe speed or hub load for this blower, DO NOT make any drive selection without first consulting Cincinnati Fan or our sales office for your area. “Timing” belts should never be used on blow- ers.
  • Page 6: Electrical

    ASSEMBLY STEPS: (Below are general instructions. Obtain specific instructions from your drives dealer) 1. Remove belt guard and open shaft access holes. Remove the protective coating from the blower and motor shafts. 2. Loosen (don't remove) the four bolts in the side of the motor adjustment base. Now you can adjust the centerline height of the base by turning the four bolts in the top of the adjustment base, next to the motor feet.
  • Page 7: Motors

    B. Motors: DANGER ALL WIRING CONNECTIONS, INSPECTION AND MAINTENANCE OF ANY MOTOR MUST BE PERFORMED BY A LICENSED ELECTRICIAN IN ACCORDANCE WITH THE MOTOR MANUFACTURERS RECOMMENDATIONS, ALL ELECTRICAL CODES AND OSHA REGULATIONS. FAILURE TO PROPERLY INSTALL, MAKE WIRING CONNECTIONS, INSPECT OR PERFORM ANY MAINTENANCE TO A MOTOR CAN RESULT IN MOTOR FAILURE, PROPERTY DAMAGE, EXPLOSION, ELECTRICAL SHOCK AND DEATH.
  • Page 8: Maximum Speed & Speed Controllers

    The maximum safe blower speed is shown on the data sheet shipped with the blower. If you have lost the data sheet, contact Cincinnati Fan or our sales office for your area. You must have the serial number from the blower name plate for us to determine the maximum safe blower speed.
  • Page 9: Vibration

    I I I I I I Apply power to the motor and let it come up to full speed. Turn off the power. Look and listen for any unusual noise or mechanical abnormality while the blower wheel is still spinning. If any are noticed, lock out the power, wait for the blower wheel to come to a complete stop, locate the cause and correct it.
  • Page 10: Routine Inspection & Maintenance

    LOCKED OUT AND THE BLOWER WHEEL HAS BEEN CAREFULLY SECURED TO PREVENT WIND MILLING. IF THE OPERATING CONDITIONS OF THE BLOWER ARE TO BE CHANGED (SPEED, PRESSURE, TEMPERATURE, ETC.) CONSULT CINCINNATI FAN OR OUR SALES OFFICE FOR YOUR TERRITORY TO DETERMINE IF THE UNIT WILL OPERATE SAFELY AT THE NEW CONDITIONS.
  • Page 11: Hardware

    A. Hardware: All blower and foundation hardware should be checked to make sure it is tight. All set screws or taper-lock bushing bolts should be tightened to the torque values shown in Tables 2 and 3 on page 5. NOTE: If any set screws have become loose, they must be thrown away and replaced. NEVER use set screws more than once.
  • Page 12: Vibration

    E. Blower Shaft & Bearing Replacement: The blower shaft and bearings for Cincinnati Fan blowers are carefully selected to match the maximum load and operating conditions for each specific blower model. If the instructions in this manual and those provided by the bearing manufacturer are followed, you should not need to replace the bearings for many years.
  • Page 13: Safety Equipment Or Accessories

    Under normal conditions, you should not need any spare or replacement parts for at least 24 months after shipment from Cincinnati Fan. That does not include any wear due to abrasion, corrosion, excessive temperatures, abuse, misuse, accident or any severe conditions the fan was not designed for.
  • Page 14: Troubleshooting

    VII. TROUBLESHOOTING Potential problems and causes listed below are in no order of importance or priority. The causes are only a list of the most common items to check to correct a problem. If you find the cause of a problem, DO NOT assume it is the ONLY cause of that problem.
  • Page 15: Long Term Storage

    VIII. LONG TERM STORAGE INSTRUCTIONS: (Storage exceeding 30 days after receipt of equipment) NOTE: Failure to adhere to these instructions voids all warranties in their entirety. 1. Storage site selection: (a) Level, well-drained, firm surface, in clean, dry and warm location. Minimum temperature of 50°F (10°C). (b) Isolated from possibility of physical damage from construction vehicles, erection equipment, etc.
  • Page 16: Warranty, Limits Of Liability, Responsibility & Returns

    RETURNS: Cincinnati Fan & Ventilator Company assumes no responsibility for any material returned to our plant without our permission. An RMA (Return Material Authorization) number must be obtained and clearly shown on the outside of the carton or crate and on a packing slip.
  • Page 17: Parts Drawing

    X. PARTS DRAWING: PLEASE NOTE Cincinnati Fan manufactures many models and arrangements with special variations. For that reason, the maintenance manuals contained on our website do not include a parts drawing nor the completed blower or fan specifications on page 1. For the parts drawing of all the standard components and specifications for the specific blower or fan that you have, please contact our local Cincinnati Fan sales office for your area.
