- Page 1 Apollo S Strobe User Manual Please read this user manual carefully before starting to use the product, and use the product properly based on the thorough understanding of this user manual. https://www.marelux.co/...
-
Page 2: Package Contents
Package Contents Battery *2 Apollo S Strobe (Need purchase from Marelux) Dome Diffuser Protective Cover Mounting Ball O-Ring*2... -
Page 3: Product Features
Product Features 1. Support TTL, RC, HSS,wireless triggering 2. With a special designed MTL mode, support continuous flashes 3. With 2 fisheye wireless signal sensor units. Plus one fiber port, sensor coverage 160 °. Wireless trigger supports M, MTL, HSS. (TTL ,RC needs fiber) 4. -
Page 4: Parts Illustration
Parts Illustration Battery Cap Fiber Port Optical Signal Receiver Light Level Control Knob Mode Knob Strobe Indicator Light... -
Page 5: Battery Installation
Battery Installation When changing or installing the battery, make sure the mode knob is in the OFF position! Remove the Battery Cap by slowly rotating counterclockwise. Insert two 18650 lithium batteries with the polarity shown in the battery compartment. (Please note that this strobe requires two 18650 lithium batteries with a discharge current greater than 20A and a voltage of 3.7V. -
Page 6: Operation
Operation Mode Knob OFF Turns the power off. Switch mode knob to [OFF] when you don’t use the strobe. TEST In this mode, you can test the working status of the strobe. Press the mode knob to trigger the strobe. M Switch to M mode to set light amount to Manual. - Page 7 Do not use the MTL mode for continuous shooting when the battery level is at half or below! Wireless Trigger Mode To use the wireless trigger mode, the Lumilink optical transmitter is required as the signal transmitter. When the strobe is turned on, the wireless trigger mode is disabled by default. In modes other than the test mode, press and hold the mode knob for 2 seconds, and after hearing four "beep"...
- Page 8 Remaining Battery Level Emission color 80~100% Blue 60~80% Green 40~60% Yellow 20~40% Purple 0~20% When the strobe indicator light is in a low battery state with a red light, please refrain from using the flash function to avoid damaging the battery. The strobe will preheat for 10 seconds when first turned on, during which the strobe indicator light will remain red.
-
Page 9: Protective Cover Installation
Protective Cover Installation Align the protective cover with the strobe as shown in the diagram. - Page 10 Mounting Ball Installation Install the mounting ball with two screws in the direction shown in the diagram. Dome Diffuser Installation Install the Dome Diffuser in the direction shown in the diagram.
-
Page 11: Maintenance And Storage
Maintenance And Storage 1. After diving, make sure the strobe is locked and sealed, wash the strobe body with fresh water. 2. When immersed with fresh water, push each button few times, thus can help to let salt and sand go out. 3. -
Page 12: Warranty
Warranty 1. Marelux provides 2 years warranty for its housing body, cable (such as fiber cable and HDMI cable), and 1 year warranty for electronic parts and components made of silicon, rubber and plastic. 2. Marelux will keep components and parts for repair and maintenance in storage for 5 years after EOL of each model. - Page 13 ⚫ Products will lose warranty immediately after unauthorized repair or modification. ⚫ The warranty terms above are made for Marelux customers to conduct free warranty service and repair and have no restriction to any legal rights that customers shall possess.
