- Page 1 Translated from Dutch to English - www.onlinedoctranslator.com Washing machine WGG246Z5NL [EN] User manual and installation instructions...
-
Page 2: Table Of Contents
Refer to the Digital User Guide for more information. Table of contents 1 Safety........4 8 Keys ........23 1.1 General instructions .... 4 9 Programs ......25 1.2 Destination of the device ..........4 10 Accessories........30 1.3 Restriction of users ..4 11 Laundry......... - Page 3 15 Basic settings ....34 15.1 Overview of the basic settings ........ 34 15.2 Changing basic settings..35 16 Cleaning and maintenance ..35 16.1 Cleaning the drum ....35 16.2 Cleaning the detergent drawer........35 16.3 Cleaning the drain pump..... 36 17 Troubleshooting ....
-
Page 4: Safety
Safety 1 Safety Please observe the following safety precautions. 1.1 General instructions ¡Read these instructions for use carefully. ¡Keep the instructions for use and product information for later for use or for subsequent owners. ¡Do not connect the device in case of transport damage. 1.2 Destination of the device Only use the device: ¡to wash machine-safe textiles and wool for hand washing... -
Page 5: Safe Installation
Safety 1.4 Safe installation WARNING ‒ Risk of electric shock! Improper installations are dangerous. ▶ Only connect and use the device according to the information on the rating plate. ▶ Only connect the device to an alternating current mains via a properly installed earthed socket. - Page 6 Safety ▶ If the power cord is too short and a longer power cord is not available, contact an electrical specialist to adjust the home installation. WARNING ‒ Risk of injury! The high weight of the device can cause injuries when lifting. ▶...
-
Page 7: Safer Use
Safety If the appliance is moved by protruding parts, such as the loading door, the parts may break off. ▶ Do not move the device by protruding parts. CAUTION ‒ Risk of cutting! Sharp edges on the device can cause cuts if touched. ▶... - Page 8 Safety ▶ On discarded appliances, unplug the power cord from the socket, then cut the power cord and damage the appliance door lock in such a way that the appliance door no longer closes. When spinning larger, water-impermeable items of laundry, an imbalance can occur that can lead to injury.
-
Page 9: Safe Cleaning And Maintenance
Safety Reaching into the rotating drum can cause injury to the hands. ▶ Wait until the drum has come to a complete stop before reaching into the drum with your hand. CAUTION ‒ Risk of burns! The soap becomes hot when washing at high temperatures. ▶... - Page 10 Safety WARNING ‒ Risk of injury! Using non-original spare parts and non-original accessories is dangerous. ▶ Use only original spare parts and original accessories from the manufacturer. WARNING ‒ Risk of poisoning! Toxic fumes can be produced when using solvent-based cleaning agents.
-
Page 11: Avoiding Material Damage
Avoid material damage Make sure that the length of the ▶ Material damage avoid material damage thread at the connection to the avoid water tap is at least 10 mm. Too low or too high water pressure can Avoid material damage hinder the device function. -
Page 12: Environmental Protection And Saving
Environmental protection and saving ▶ Immediately remove all detergent Reduce washing temperature for residues, spray residues or residues lightly and normally soiled laundry. upon contact with the device. aAt low temperatures it consumes device uses less energy. For light to normal contamination, lower environmental protection saving... -
Page 13: Setup And Connection
Set up and connect Remark:A function test was carried Set up and connect connect out on the device at the factory. This may cause water stains to form in the connect device, which the first wash will 4.1 Unpacking the device remove. -
Page 14: Protections
Set up and connect Pull the hoses out of the holders. Staging location Requirements Holder The device with locking lips → Page 30 to confirm. Place the device Floor with wooden comb on a wa- beams ter-resistant wooden plate (thick too minimal Loosen and remove all bolts of the 30 mm) which... -
Page 15: Connecting The Device
Set up and connect Remove the 4 sleeves. 4.5 Connecting the device Connect the water supply hose WARNING Risk of electric shock! The device contains live parts. Touching live parts is dangerous. Do not immerse the electric ▶ Aquastop valve in water. Connect the water supply hose to the tap (26.4 mm = 3/4"). -
Page 16: Adjusting The Device
Set up and connect 4.6 Adjusting the device Siphon The connection position tie with a To reduce noise and vibration and to hose clamp avoid walking of the device, place the (24-40 mm) bore device horizontally. gene. Turn the lock nuts clockwise with a wrench with a spanner width of Washbasin The water drainage... -
Page 17: Before First Use
Before first use Tighten the lock nuts hand-tight Approx. Pour 1 liter of tap water into against the housing with a wrench compartment II. with a spanner width of 17. Pour powder detergent with oxygen bleach into dispensing drawer II. Hold the device foot and do not adjust the height. -
Page 18: Getting To Know Your Device
Get to know your device Get to know your device w g et to know device to know your device 6.1 Device Here you will find an overview of the components of your device. Depending on the device type, details in the image may differ, e.g. the color and other details. -
Page 19: Control Panel
Get to know your device maintenance products and the Dosing aid for liquid information in the program detergent → descriptions. "Inserting the dosing aid", page 32 Detergent compartment II: detergent for the main wash Detergent dispenser: fabric softener Detergent compartment I: detergent for the prewash 6.3 Control panel You can use the control panel to set all functions of your device and obtain... -
Page 20: Display
Display Display isplay isplay On the display you will see the current setting values, selection options or instructions. singing lyrics. Example display indication Description Indication 0:40 Expected program duration or remaining time of the program in hours and minutes. 10 / (Ready in) Program end time →... - Page 21 Display Description Indication Program status: washing Program status: rinse Program status: spinning Program status: pause Program status: program end Program status: steaming ¡lights up: the child lock is activated. ¡flashes: the child lock is activated and the device was served. →...
- Page 22 Display Description Indication ¡No water pressure. → "E:30 / -10 or . ", page 40 ¡The water pressure of the tap is too low. E:35 / -10 Error code, error indication, signal. → "Troubleshooting", page 39 Example...
- Page 23 Tests Tests etching The selection of the program settings depends on the setting etching program. Knob Choice More information Start/Refill ¡start Start, cancel or pause program. ¡Cancel ¡pause ¡activate Speed Perfect Activate or deactivate shortened ¡deactivate program duration. Remark:Energy consumption is increasing.
- Page 24 Tests Knob Choice More information Water & Rinse ¡activate Wash with more water and activate or Plus deactivate an extra rinse cycle. ¡deactivate Recommended for particularly sensitive skin or in areas with very soft water. ¡activate Activate or deactivate washing with less Anti wrinkle crease.
-
Page 25: Programs
Programs 9 Programs programs Programs Comments ¡The care labels of the laundry give you additional instructions for the program selection. ¡For programs with a temperature setting of 80°C or 90°C, the actual temperature may differ from the displayed temperature. However, the washing effect and hygiene expected at the specified temperatures are achieved. - Page 26 Programs Maxi Program Description male bela- thing (kg) Wash textiles made of synthetic and mixed fibres. Wrinkle repair loin Program setting: ¡max. 60 °C ¡max. 1200 rpm Fast mix Wash textiles made of cotton, linen, synthetic materials and mixed fibres. Suitable for lightly soiled laundry.
- Page 27 Programs Maxi Program Description male bela- thing (kg) Hygiene Plus Wash sturdy textiles made of cotton, linen and mixed fibres. Suitable for people with allergies and high hygiene requirements. Remark:When the set temperature has been reached, it remains constant during the entire washing process.
- Page 28 Programs Maxi Program Description male bela- thing (kg) The program is therefore not suitable for outdoor textiles or textiles made of silk and wool, such as pullovers. Jeans/Dark Wash dark and colour-intensive textiles made of cotton and easy-care textiles, e.g. jeans. used to be Wash the laundry inside out.
- Page 29 Programs Maxi Program Description male bela- thing (kg) ¡max. 1200 rpm Speed Perfectactivated Washing not possible...
-
Page 30: Accessories
accessories 0 Accessories accessories e use only original accessories. accessories These are tailored to the device. Remark:Some accessories are available in other colours. Please contact the → "Service", page 46 . Usage Order number Extend cold water or Aquastop WMZ2381 Extension water supply water supply hose (2.50 m). -
Page 31: Agent
Detergent and laundry care products Set the program selector to a ▶ ¡Laundry that has been treated with chlorine bleach agent has been prepared, rinse program. several times before putting it in the drum 13.2 Set program Turn the program selector and set laundry care products... -
Page 32: Installing The Dosing Aid
The Ministry in essence Push the dosing aid forward. 13.5 Install dosing aid Pull out the detergent drawer. Press the insert down and remove the detergent drawer. Fold the dosing aid down and click it into place. Insert the dosing aid. 13.7 Dosing detergent and laundry care products 13.6 Use dosing aid... -
Page 33: Starting The Program
The Ministry in essence Remark:If you want to add laundry, 13.8 Starting the program follow the instructions on the display. → "Display", page 21 Required:A program has been set. Open the door. → "Set program", page 31 Add or remove the laundry. Close the door. -
Page 34: Switching Off The Device
Child lock In order not to cancel the running 13.14 Switch off device program, the program selector Press the program selectorOutto make. must be set to the starting Wipe the rubber sleeve dry and program. remove foreign objects. agoes out in the display 5 Basic settings basic settings... -
Page 35: Changing Basic Settings
Cleaning and maintenance 15.2 Change basic settings inside the device. → "Accessories", page 30 Set the program selector to position 1. → Page 34 16.2 Cleaning the detergent drawer Press and simultaneously turn the program selector to position 2. Pull out the detergent drawer. aThe display shows the current value Press the insert down and remove the on. -
Page 36: Cleaning The Drain Pump
Cleaning and maintenance Clean and dry the detergent drawer 16.3 Cleaning the drain pump and insert with water and a brush. Clean the drain pump regularly, at least once a year and in the event of malfunctions, e.g. blockages or chattering. - Page 37 Cleaning and maintenance Clamp the drain hose in the holder. Remove the drain hose from the holder. CAUTION - Risk of burns!The soap becomes hot when washing at Clean the drain pump high temperatures. Required:The drain pump is empty. → Page 36 ▶...
- Page 38 Cleaning and maintenance Clean the interior, threads of the Tighten the pump cover as far as pump cover and pump housing. it will go. The handle of the pump cover must be vertical. Verify that the pump impeller rotates easily. Install and close the service flap.
-
Page 39: Troubleshooting
Troubleshooting 7 Troubleshooting resolve disruptions You can resolve minor faults with the device yourself. Please consult before you resolve disruptions contact customer service for information on troubleshooting. This way you avoid unnecessary costs. WARNING Risk of electric shock! Improper repairs are dangerous. - Page 40 Troubleshooting Cause and troubleshooting Malfunction "E:30 / -10" or Water tap is closed. Open the water tap. ▶ Water supply hose is kinked or trapped. Check the installation of the water supply hose. ▶ → Page 13 Sieve in the water supply is clogged. ▶...
- Page 41 Troubleshooting Cause and troubleshooting Malfunction flashes and the Device has detected fluctuations in the supply program pauses. voltage. No action required. Once the supply voltage has stabilized, the program will continue normally. Strong foaming Detergent dosage is too high. ming. ▶...
- Page 42 Troubleshooting Cause and troubleshooting Malfunction Door is locked. Door cannot be opened in the Open the door with the emergency release. ▶ event of a power failure → Page 45 den opened. Drum shakes No malfunction. Internal engine test has started. program start.
- Page 43 Troubleshooting Cause and troubleshooting Malfunction Drops of water from the drum or door have dampened have formed on the the textiles. The drops come either from condensed textiles after the end of vapor or from residual moisture from the previous the programmeIron Assist moist...
- Page 44 Troubleshooting Cause and troubleshooting Malfunction There is too much detergent or fabric softener in the detergent Detergent or laundry detergent softer drips from drawer. the cuff and collects on ▶ When dosing, pay attention to the marking in the detergent the door or in the cuff drawer.
-
Page 45: Emergency Release
Transport, store and dispose of Dismantle the hoses. 17.1 Emergency release Unlock door 18.2 Installing transport protections Required:The drain pump is empty. → Page 36 To avoid transport damage, secure 1. PLEASE NOTE!Running water can the device with transport locks before lead to property damage. -
Page 46: Disposal Of Your Old Device
Service department 18.4 Disposal of your old sche equipment (waste electrical and electronic device equipment - WEEE). Valuable raw materials can be reused The directive sets the through environmentally friendly framework for take-back disposal. valid in the EU and processing of old equipment. -
Page 47: Aqua-Stop Warranty
Service department ¡on the inside of the bottom When you go on holiday for a few weeks, the tap needs to be turned holding valve. ¡at the back of the device off. comb. To quickly find your device information and service telephone numbers, you can write down the information. -
Page 48: Consumption Values
Consumption values usability values 0 Consumption values usability values The following information is provided in accordance with the EU Ecodesign Regulation. The specified values for other programs asEco 40-60are only guideline values and were determined in accordance with the applicable standard EN60456. Pro- Maxi Program... - Page 49 Technical data Maximum load 9.0kg thing 220-240V, Mains voltage 50-60Hz 10 A Minimum input storage fuse Rated power 2300W gene Recorded ver- ¡Off state: 0.10W to be allowed to ¡Non-disabled applauded- setting: 0.50 W ¡At least: Water pressure 100 kPa (1 bar) ¡Maximum: 1000 kPa...
- Page 52 Contact data of all countries are listed in the attached service directory. BSH Hausgeräte GmbH Carl-Wery-Strasse 34 81739 Munich, GERMANY www.bosch-home.com A Bosch Company *9001857100* 9001857100(040312)
