RADIANT LARGE STRAIGHT
INSTALLATION INSTRUCTIONS
W
ARNINGS
• These units should be installed by a certified electrician in accordance with the National Electrical Code (NEC)and the Canadian Electrical Code (CEC).
• The unit requires a 120 volt, 60 Hz power source and should be installed on a GFCI protected circuit.
• Plug-in units should be connected to a grounded outlet with a minimum rating of 10 amps.
• Follow instructions to ensure he learned is securely fix the wall. Unit is designed for drying towels. Under no circumstances should anyone climb on or hang on unit.
• Unit is intended for indoor use only. Do not place units inside a shower, sauna, steam room, or wherever unit would be exposed to water.
CAUTION
• As this is a heating device, the surface temperature can increase depending on the ambient temperature in the room and the number of tiles apply to the unit.
• Overloading the unit can cause the unit to become extremely hot and they result in a burn it touched and or damage the towels.
• The fasteners provided with installation kit are for convenience only are not suitable for all installation conditions.
• It is the ultimate responsibility of the installer to ensure proper mounting hardware is employed in attaching the unit to the wall.
OPERATING INSTRUCTION
• After installation, connect electrical power.
• Remove the protective cover from the switch and turn it to the on position.
• The indicator light will glow red and the towel warmer will start to heat — allow 10–20 minutes to heat up.
• This towel warmer has been designed to run continuously-turn off the switch or unplug the cord in the tower is not in use for long periods of time.
• Never use an extension cord for plug-in models.
INCLUDED COMPONENTS
A
4X
4X
F
M6X10
4X
4X
SKUS
RWHL-SP | RWHL-SB | RWHL-SMB | RWHL-SSB
P - POLISHED
| B - BRUSHED
MB - MATTE BLACK | SB - SATIN BRASS
INTEGRATED SWITCH
• The radiant collection features an
integrated on/off switch.
• Remove plastic cover after installation
• Switch is located on the bottom of the left
vertical bar.
• Press switch to power on unit.
• Switch will illuminate when on.
2022.4
Please read the following information before installing and using your heated towel rack
B
C
4X
4X
G
H
#6-32x3/4-in
1X
2X
! CAUTION —SURFACE OF UNIT IS HOT WHEN ON !
TOOLS REQUIRED
D
E
4X
I
J
1X
CONFOR M S T O UL S T D.499
CER T IFIED T O C S A S T D C22.2 NO.6 4
T OW EL WA R MER | MODEL : R W HL-S
R AT ED V OLTA GE : 120V~
R AT ED FR EQUENC Y: 60H z
R AT ED P O W ER INP U T: 150W
S ER I A L NO :
C AUTION:
HOU S EHOL D U S E ONLY
DO NO T IMMER S E IN WAT ER
HO T S UR FA CE : AV OID CON TA C T
U T IL I S AT ION DU MÉN A GE S EUL EMEN T
NE PA S P L ONGER DA N S L'E AU
S UR FA CE CH AUDE É V I T ER CON TA C T
TEL : 404-350-9738
HEATED TOWEL RACKS
WARRANTY
T H E WA R R A N T Y CO V ER S
DEF EC T S I N W O R K M A N S H I P
Two year limited warranty
with proof of purchase
will apply if all terms and
conditions of sale are met
and installation instructions
are adhered to.
www.ambaproducts.com/warranty
PARAMETER
CONTACT
FA X : 404-355-0166
EM A IL :
cus tomer s er v ice@ambaproduc t s .com
w w w.ambaproduc t s.com
2 YE AR S
A N D M AT E R I A L S
FOR FULL WARRANTY AND
TERMS OF SALE VISIT:
PAGE
