INSTALLATION GUIDE AND USER MANUAL OF
SAUNUM AIRCUBE SPACE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirCube Space and is the answer not in the manual?

Questions and answers

Related Manuals for Saunum AirCube Space

Summary of Contents for Saunum AirCube Space

  • Page 1 INSTALLATION GUIDE AND USER MANUAL OF SAUNUM AIRCUBE SPACE...

  • Page 2: Table Of Contents

    Maintenance ..........................17 General upkeep ..........................17 Interior maintanance ........................17 Exterior care ............................17 General notes ............................ 17 WARRANTY CONDITIONS FOR SAUNUM SAUNAS ................ 18 Warranty Period: ..........................18 Coverage: ............................18 Exclusions: ............................19 Claims Process:..........................19 Spare parts ..........................20...

  • Page 3: Installation Requirements

    Thank you for purchasing a Saunum outdoor sauna! Installation requirements The base or foundation for Sauna must be leveled and stable. Sauna must be at least 3 inches higher from the surrounding ground. All base beams must have a support under them.

  • Page 4: Transport

    Transport Sauna is packed into protective OSB box. Do not disassemble the box before the sauna is in the final location. Sauna can be lifted from above with crane: Sauna can be lifted from below with forklift:...

  • Page 5: Protective Osb Box Disassembling

    Protective OSB box disassembling Dismantle the protective OSB box before final assembly. OSB boards are fastened with small screws covered with round stickers. The OSB boards, including the screw cover stickers, are painted black. The stickers prevent paint from getting into the screw heads and the screws are much easier to find. Disassembling steps: 1.
  • Page 6 5. Once all the boards around the sauna have been removed, you can start dismantling the board supports at the top and bottom of the sauna 6. At the top are OSB strips with battens that are attached to the top with screws 7.

  • Page 7: Final Assembly

    Final assembly Final assembly shall be organized by the client. All electrical connections must be made by certified electrician. Final assembly includes installing of the: • Parapet metal; • Decorative base boards; • Rainwater system; • Main power cable; (+ control unit) •...

  • Page 8: Final Assembly Instructions

    Final Assembly Instructions: Sauna cannot be exposed to the weather conditions without parapet metals Parapet metals installation. 1. Unwrap metals carefully, do not scratch paint surface with sharp objects 2. Place the metal on the parapet. The longer piece is for the front and the shorter ones are for the left and right sides.
  • Page 9 Rainwater system installation 1. Begin the assembly process by securing gutter brackets to the wall using 5x70 woodscrews, with 2 screws per bracket. Distribute the gaps equally between the five brackets along the length of the gutter. 2. The brackets should be mounted with a slight downward angle towards the drain outlet 3.
  • Page 10 7. Insert the downpipe into drop outlet and fasten the pipe on the wall with brackets 8. Finally use rivets to attach the pipe ends to the outlets. Base boards installation Purpose of the base boards is decorative. Baseboards have been cut in the correct length and have pre-drilled holes in them.

  • Page 11: Instructions For Adjusting Sauna Door

    Instructions for adjusting sauna door Adjusting the hinge The door hinge N3248-110 TMKSS use allows for vertical and horizontal adjustment. Door leaf adjustment up/down, see Figure 3. Remove the protective cap 1 from one door hinge (using a 5mm Allen key). By turning the Allen bolt 2 below it clockwise (using a 5mm Allen key).

  • Page 12: Sauna Electrical Connections

    Sauna electrical connections Saunas have been prewired. All electrical connections for LED lights, speakers and ventilator are made in factory (Figure 1). All the electrical connections must be made by certified electrician. Electrical connections 1. There are two electrical boxes (120 VAC ja 240 VAC) located behind wooden door on the side of the sauna.
  • Page 13 11. Inside the wall is rigid pipe, which leads to the 120 VAC electrical box. To install temperature sensor, hole needs to be thrilled through heater side of the wall. Thrilled hole must be at least 2 inches deep, but not more than 3 inches. Location of the hole is shown on the drawing below.
  • Page 14 Figure 1. SAUNUM AIRCUBE SPACE CONNECTIONS DONE IN FACTORY LOWER BENCH EX.LIGHTS 1 1 1 1 5 5 5 5 4 4 4 4 5 5 4 4 DOOR SENSOR TOP BENCH XLG-200-12A CONTROL CABINET POWER SR-2501NEA PE L1 L2...
  • Page 15 Figure 2. SAUNUM AIRCUBE SPACE CONNECTIONS AFTER SAUNA INSTALLATION LOWER BENCH EX.LIGHTS 1 1 1 1 5 5 5 5 4 4 4 4 5 5 4 4 DOOR SENSOR TOP BENCH XLG-200-12A CONTROL CABINET POWER SR-2501NEA PE L1 L2...

  • Page 16: User Guide

    User guide Using and connecting Bluetooth speakers 1. Make sure that Sauna is connected to external power 2. There is a red light on the speakers if they are not connected to any device 3. Turn on Bluetooth on your phone and search for available devices 4.

  • Page 17: Maintenance

    Maintenance General upkeep ⎯ After each use, ensure that the sauna is properly ventilated. Turn on the ventilation system to help dry out any excessive moisture. ⎯ Gently clean the surfaces of benches and cladding with a damp cloth to remove any sweat or dirt buildup.

  • Page 18: Warranty Conditions For Saunum Saunas

    WARRANTY CONDITIONS FOR SAUNUM SAUNAS Warranty Period: The warranty is valid for a period of 2 years from the date of purchase. Warranty is only valid if the sauna's foundation has been constructed correctly according to the guidelines provided. Improperly constructed foundations will void this warranty.

  • Page 19: Exclusions

    Exclusions: This warranty does not cover any damage or defects resulting from normal wear and tear, lack of maintenance as per instructions, alteration, misuse, or abuse. Man-made injuries or damage caused by accidents, pests, natural disasters or any other external forces and transportation damages are specifically excluded from this warranty.

  • Page 20: Spare Parts

    Spare parts Order Part Name Part Picture number 9050023 Feed-through terminal block 9050025 Feed-through terminal block 9050043 End and partition plate for terminal block 9050059 Feed-through terminal block 9050060 Feed-through terminal block 9050061 End and partition plate for terminal block...
  • Page 21 Order Part Name Part Picture number 9050063 Cross-connector for terminal block 9050075 Feed-through terminal block 9050074 Relay module 9050062 End bracket for terminal block 9050045 AC-DC Single output LED driver 9030010 RF dimmer SR-2501NEA...
  • Page 22 Order Part Name Part Picture number 9030011 RF dimmer switch 2020002 Tangential fan NCA 60-120/23 9040007 LED STRIP LIGHT 9040004 Exterior light Forest 9040008 GU10 spot light bulb...
  • Page 23 Order Part Name Part Picture number 9050005 Speakers 4030065 Parapet metal right 4030066 Parapet metal left 4030067 Parapet metal front 4030068 Roof drip metal 4030069 Rainwater gutter...
  • Page 24 Order Part Name Part Picture number 4030004 Rainwater gutter end cap 4030003 Rainwater gutter bracket 4030002 Rainwater drop outlet 4030005 Rainwater down pipe 4030006 Rainwater down pipe bracket 4030007 Rainwater outlet...
  • Page 25 Order Part Name Part Picture number 4030070 Window metal 7060003 Cladding board (1 pc 2,4m) 7060004 Base board (1 pc 2,8m) 2020004 Air outlet cover 260x190mm 2020011 Air inlet cover 140x190mm...
  • Page 26 Order Part Name Part Picture number 7050005 Cladding board STS3 15x120mm (1 pc 2,7m) 7070053 Bench board 28x120mm (1 pc 2,7m) 7070053 Backrest board 28x90mm (1 pc 2,4m) 7070037 Backrest board 28x65mm (1 pc 2,4m) 7070031 Skirt board 28x42mm (1 pc 2,4m) 7070025 Floor grid board 28x28mm (1 pc 2,4m)
  • Page 27 Order Part Name Part Picture number 2020008 Air inlet cover 2020006 Air outlet cover 2010003 Trap cover 5030018 Door hinge 5030017 CYLINDER ACCESSORY SET 5030016 Lock case...
  • Page 28 Order Part Name Part Picture number 5030015 Lock cylinder 5030014 Concealed door closer 5030013 Door handle...
  • Page 29 PROJECT DRAWING Aicube Space Spare Parts ADDRESS CONTRACT SCALE FORMAT Saunum Sauna Team OÜ DESIGNER DATE M.Ojamaa 26.04.2024 Registrikood: 14769342 www.saunateam.ee; info@saunum.com CODE CHECK PAGE M.Ojamaa...
