abi BARRE 14239 Installation Instructions

80
1
Front View
Note : Di me n si o n s are n o mi na l m eas urem ent s o nly
SP ECI FICATIONS
RECO M M EN DED USE
M ATE R I AL
P RE SS U RE R ATIN G
T EM PE R ATUR E RAT IN G
mensions are nominal measurements only
SU I TA B L E HOT WAT ER U NI TS
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered trade people. The manufacturer/distributor reserves the right to vary specifications or delete
models from their range without prior notification. Dimensions are nominal measurements only. Dimensions and set-outs listed are correct at time of publication however the manufacturer/distributor
takes no responsibility for printing errors. All ABI Products are designed in Australia. Copyright ABI Interiors Pty Lty 2021.
BAR RE AS S EM BLY TAP S
61
8
24

54
Side View
D o m es tic
So li d B rass
R ec o mm en ded m i ni m um wo rk i ng pres sure 15 0k Pa
R ec o mm en ded m ax im u m wo r k i ng pre ssu re 5 00 k Pa
H o t an d co l d wat er in le t pre ssu re s ho ul d be e qual
M axi m um co nti nu ou s wo r k in g tem pe ratu re 7 5° C
I f the wat er tem perature exc ee ds 7 5° C , an ap prove d t emp e ri ng
v al ve m us t be f i tte d
S to rage ta nk : Ye s
C o nt in uo us F l ow : Ye s
G ravi ty Fe ed: N o t sui tabl e
I NSTALLAT ION GUI DE
No te: This p rod uct must be insta lled by a licensed pl umb er.
Thi s is a general install atio n gui de - there are ma ny f act ors that are invo lved that ca n alte r
the i nstalla tio n method. Thi s pro duct insta ll must co mply w ith AS/NZS 3 50 0.
New Build - Install breach in desired position (please refer to additional install information regarding breach set backs).
Retrofitting Existing - Remove existing tapware & reseat body seats until shiny and smooth.
AS/NZS 3718:2 00 5
WM-02 2 852
1 Remove locking nut from spindle. Screw spindle into breach and hand
6
tighten until rear of spindle meets the body seat, be sure not to over tighten.
If necessary apply more pressure lightly with spanner.
3 Install the handle body onto the locking nut, twisting by hand until
tightened. Slide back plate over handle body until firmly pressed against
finished wall surface.
R e g u l a r l y c l e a n w i t h
m i l d l i q u i d d e t e rg e n t
o r s o a p a n d w a t e r
Fit the fibre washer over the spindle. Screw on the locking nut and tighten
2
with spanner. TEST AND CHECK FOR LEAKS.
4 Install tap handle onto spindle and tighten in place using grub screw and
allen key.
D O N OT u s e c re a m D O N OT u s e c l e a n i n g
c l e a n e r s o r b l e a c h . p a d s w i t h a b ra s i ve
T h e s e s u b s t a n c e s a re s u r f a c e s a s t h i s m a y
a b ra s i ve s c ra t c h t h e m a t e r i a l
