Sealey YAJ18S V2 Series Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
gloves
instructions
1. SAFETY
Use jack only in accordance with this instruction manual.
8
It is necessary that the operator can watch the lifting device and the load during all movements.
9
The operator shall be provided with all the necessary information about training and about pumping and translating forces.
9
Ensure the jack is in sound condition and good working order. Take action for immediate repair or replacement of damaged parts. Use
9
genuine parts only. DO NOT modify the jack. The use of non-genuine parts may be dangerous and will invalidate the warranty. Replace
hoses 'like for like'..
Locate the jack in a suitable, well lit working area. Keep working area clean and tidy and free from unrelated materials. Use jack on level
9
and solid ground, preferably concrete. Avoid tarmacadam as jack may sink in.
Chock wheels of vehicle.
9
Ensure the vehicle handbrake is engaged, engine is switched off and transmission is in gear (or "PARK" if automatic).
9
Ensure minimum distance of 0.5m between vehicle and static objects such as doors, walls, etc. to allow for vehicle tilting.
9
Ensure all non-essential persons keep a safe distance whilst the jack is in use.
9
Ensure there are no passengers in the vehicle.
9
The operator of the jack must watch the jack and the load during all movements.
9
Place jack under only those lifting points recommended by vehicle manufacturer (see vehicle handbook).
9
Check that the lifting point is stable and centred on the jack saddle.
9
▲ DANGER: Use the jack for lifting only, NOT for supporting the lifted load.
WARNING! DO NOT work on, or under, a vehicle which is supported only by a jack (or jacks) - always use axle stands.
‰
Ensure there are no persons or obstructions beneath the vehicle before lowering.
9
Use suitable axle stands under the vehicle before proceeding with any task.
9
Use a qualified person to lubricate and maintain the jack.
9
Ensure that only hydraulic jack oil is used in the jack.
9
DO NOT operate the jack if damaged.
8
DO NOT allow untrained persons to operate the jack.
8
DO NOT operate the jack when tired or under the influence of drugs, alcohol or intoxicating medication.
8
DO NOT exceed the rated capacity of the jack.
8
DO NOT allow the vehicle to move during lifting or lowering, or use the jack to move the vehicle.
8
DO NOT jack vehicle if there is a risk of spillage of fuel, battery acid, or other dangerous substances.
8
DO NOT work under the vehicle until appropriately rated axle stands have been correctly positioned.
8
DO NOT use the jack for purposes other than that for which it is intended.
8
DO NOT use with foodstuffs.
8
DO NOT top up hydraulic system with brake fluid. Use hydraulic jack oil only. (Sealey Part No: HJO500MLS or HJO5LS)
8
In the event of oil spillage ensure an oil spill kit is to hand. Consult Sealey website for Materials Safety Data Sheet for characteristics of
9
fluids included with the product. Fire fighting procedure/equipment should be in accordance with the Materials Safety Data Sheet.
DO NOT adjust the safety overload valve.
8
Lifting of persons is prohibited.
9
DO NOT use in severe weather conditions, risk assess the task. DO NOT use on ships.
8
Beware of static electrical shock from jack when used on some surfaces.
9
In the event of blockage stop using the jack and consult professional advice.
9
When not in use store jack, fully lowered, in a safe, dry, childproof area. Ensure if transported the jack is secured in an upright position.
9
DO NOT snatch the hose from the air supply, and DO NOT direct air from the air hose at yourself or others.
8
WARNING! Turn off air supply and de-pressurise the control nozzle before removing the pump unit from any installation or mobile system.
‰
No modifications shall be carried out which adversely affect the compliance of the jack with the standard.
9
Check the state of the markings and that the markings remain as the initial one.
9
Failure to comply with this instruction may damage the unit and will invalidate your warranty.
9
Lifetime of the jack: Manufactured to a high standard, this product will, if used according to these instructions, and properly
9
maintained, give you years of trouble free performance.
2. INTRODUCTION
Powerful and reliable, ideal for workshop or roadside use. At modest cost, it takes the effort out of lifting heavy plant, tractors and
commercial vehicles. Features dead man's control and sectional pump handle for manual operation.
© Jack Sealey Limited
AIR OPERATED HYDRAULIC BOTTLE JACK
12, 18, 20 TONNE
YAJ12S, YAJ18S.V2, YAJ20SLE
MODEL NO:
Wear safety
footwear
Original Language Version YAJ12S YAJ18S.V2 YAJ20SLE Issue 5 07/03/24
