NAVINE
ASSEMBLY INSTRUCTIONS
OUTDOOR FIREPLACES
Model No: RS-SW2228
Item No: 46S22-BLACK/46S22-GREY
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Keep the screws and parts out of reach of children.
(Made in China)
Advertisement
Table of Contents
Related Manuals for RW Flame RS-SW2228
Summary of Contents for RW Flame RS-SW2228
- Page 1 NAVINE ASSEMBLY INSTRUCTIONS OUTDOOR FIREPLACES Model No: RS-SW2228 Item No: 46S22-BLACK/46S22-GREY Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Keep the screws and parts out of reach of children.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents..................2 Warning and Cautions................3-5 Tools and Parts..................6-10 Lighting Operation.................11-12 Maintenance and Storage..............13-14 Troubleshooting..................15 Assembly....................15 REMINDER BEFORE ASSEMBLY Verify that all parts are included with your gas fire pit BEFORE you begin assembly by checking the Parts and Hardware List. -
Page 3: Warning And Cautions
WARNINGS AND CAUTIONS Read the instructions before use. This appliance must be installed in accordance with enforced regulations and the following instructions. �CAUTION � WARNING Installer: Leave the manual with Do not try to light this appliance the user for future use. without reading the "LIGHTING"... - Page 4 You must provide propane gas and a propane cylinder. Use a standard 20 lb. propane cylinder only. Use this appliance only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas， ANSI/NFPA 58. Your local library or fire department should have this book.
- Page 5 PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Any guard or other protective device removed for servicing the appliance must i l p d i l be replaced prior to operating the appliance. The installation must conform with local codes or， in the absence of local codes， with Installation and repair should be done by...
-
Page 6: Tools And Parts
Parts list Item Description Table top Door Side Panel Side Panel Back plate Metal stand Lava rocks Protective cover Burner (preassembled) Guard (preassembled) Glass clamps(*8) Windshield(*4) M6 * 12 Screw M6 * 16 Screw M6 * 25 Screw screwdriver Wrench Control Knob Foot pad... - Page 7 Assembly instructions 1.Attach the side panel (C, D) to the table top (A) using 6 pcs M6*25 screws (CC). Note:Do not tighten screws completely at this step. CC*6 2.Attach the rear panel (E) to the side panel (C, D) and table top (A) using 6 pcs M6*12 screws (AA). Note:Do not tighten screws completely at this step.
- Page 8 Assembly instructions 4.Attach the door (B) to the Side Panel(C). 5. Check that the control knob (FF) for the gas supply system is turned to the “OFF” position before starting any assembly. 6.Place the propane tank (not included) in the metal bracket (F), ensuring that the tank is fully secured to the metal bracket (F).
- Page 9 Assembly instructions 7.Turn the cylinder valve on the tank clockwise to close the propane tank. Attach the preassembled regulator from the table Pressure reliefvalve top (A) to the cylinder valve by turning the Cylinder valve Black coupling nut Bleed-off regulator coupling nut clockwise Make sure valve turn clockwise to connect it is fastened securely and tighten...
- Page 10 Assembly Assembling the glass Unscrew all preassembled screws on the glass clamps. Then, assemble one glass panel to the other glass panel . Repeat it for the rest two glass panels. Then, assemble the two glass panel pieces together with the final glass clamps as shown below. Inserting the glass Insert the glass assembly made in step 1 into the ridge on the top of the fire table body .
-
Page 11: Lighting Operation
OPERATION WARNING: This appliance should not be used for any purpose other than the intended use. Do not use this appliance to cook food. Initial Lighting: When lit for the first time, the appliance emits a slight odor. This is a normal, temporary condition caused by the "burn-in"... - Page 12 Lighting Instructions WARNING Press and hold electronic FOR YOUR SAFETY: Keep your face and body away from igniter button. burner area when lighting. Turn the burner control to the high Ensure burner controls are in the off position. Slowly turn on the position;...
-
Page 13: Maintenance And Storage
MAINTENANCE AND STORAGE MAINTENANCE ： To enjoy years of outstanding performance from your appliance, make sure you perform the following maintenance activities on a regular basis: • At least once a year, the unit should be inspected for spiders, cobwebs, or other insects. - Page 14 STORAGE: During use • Turn the control knob to the "OFF" position. • Disconnect the LP source. • Store the appliance upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow dust • Cover the appliance to protect exterior surfaces and to help prevent build-up in air passages.
-
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE SOLUTION Low heat / Low flame Incorrect lighting operation. Ensure the lighting procedure is followed carefully. The valve must be in the off position when the tank valve is when valve turned to turned on. Turn the tank on slowly to allow the pressure to high. - Page 16 Thank you for purchasing this product! If you have any questions about the product, such as missing parts, damaged products, product assembling, and operation, please contact us via Amazon Message or customer service number: 213-4467172 or 661-4358826 IMPORTANT Please call our customer service department for any consulting: 213-4467172 661-4358826 (8:30am - 5:30pm P.S.T.)
