RW Flame RS-S32005 Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

NAVINE
ASSEMBLY INSTRUCTIONS
OUTDOOR FIREPLACE
Model
No:RS-S32005
Item
:
No
46S33-BLACK
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Keep the screws and parts out of reach of children.
(Made in China)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-S32005 and is the answer not in the manual?

Questions and answers

Related Manuals for RW Flame RS-S32005

Summary of Contents for RW Flame RS-S32005

  • Page 1 NAVINE ASSEMBLY INSTRUCTIONS OUTDOOR FIREPLACE Model No:RS-S32005 Item 46S33-BLACK Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Keep the screws and parts out of reach of children. (Made in China)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Table of Contents..................2 Warning and Cautions................3-5 Tools and Parts..................6-9 Lighting Operation.................10-11 Maintenance and Storage..............12-13 Troubleshooting..................14 Assembly....................15-16 REMINDER BEFORE ASSEMBLY Verify that all parts are included with your gas fire pit BEFORE you begin assembly by checking the Parts and Hardware List.
  • Page 4 You must provide propane gas and a propane cylinder. Use a standard 20 lb. propane cylinder only. Use this only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas， ANSI/NFPA 58. Your local library or fire department should have this book.
  • Page 5 PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Any guard or other protective device removed for servicing the appliance must i l p d i l be replaced prior to operating the appliance. The installation must conform with local codes or， in the absence of local codes， with Installation and repair should be done by...

  • Page 6: Tools And Parts

    Parts list Item Description Table Top Door Front Panel Side Panel Left Back Leg Left Front Leg Right Front Leg Right Back Leg Metal Stand 1 6.6lbs Lava Rocks Control Knob (preassembled) Guard (preassembled) Fire bowl (preassembled) Burner (preassembled) Regulator Hose (preassembled) Screwdriver Protective cover M6 * 12 Screw...
  • Page 7 Assembly instructions 1. Check that the control knob(M) for the gas supply system is turned to the “OFF” position before starting any assembly. 2. Attach legs (F) (G) (H) (I) to the bottom part of the table top (B) AA x8 using screws (AA) .
  • Page 8 Assembly instructions 5. Attach the door (C) to left back leg (I) using screw (AA). AA x1 6. Put the lid (A). 7. Place propane gas tank (not included) into the metal stand (J). Make sure the gas tank sits on the metal stand (J) completely.
  • Page 9 Assembly instructions Pressure Turn the cylinder valve on the tank clockwise to reliefvalve Cylinder valve close the propane tank. Attach the preassembled Black coupling nut Bleed-off regulator from the table top (B) to the cylinder valve turn clockwise to connect valve by turning the regulator coupling nut turn clockwise clockwise.

  • Page 10: Lighting Operation

    OPERATION • Children and adults should be alerted to the hazards of high surface temperatures and should stay away from the appliance to avoid burns or clothing ignition. • Children should be carefully supervised when they are in the area of the appliance. •...
  • Page 11 Lighting Instructions WARNING Press and h e lectronic FOR YOUR SAFETY: Keep your face and body away from igniter butt burner area when lighting. Turn the burner control to the high Ensure burner controls are in the off position. Slowly turn on the position;...

  • Page 12: Maintenance And Storage

    MAINTENANCE AND STORAGE MAINTENANCE ： To enjoy years of outstanding performance from your appliance, make sure you perform the following maintenance activities on a regular basis: • At least once a year, the unit should be inspected for spiders, cobwebs, or other insects.
  • Page 13 STORAGE: Between use • Turn the control knob to the "OFF" position. • Disconnect the LP source. • Store the appliance upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow dust • Cover the appliance to protect exterior surfaces and to help prevent build-up in air passages.

  • Page 14: Troubleshooting

    TROUBLESHOOTING PROBLEM PROBABLE CAUSE SOLUTION Low heat / Low flame Incorrect lighting operation. Ensure e ligh ing procedure is followed carefully. The valve must be in the off position when the tank valve is when valve turned to turned on. Turn the tank on slowly to allow the pressure to high.

  • Page 15: Assembly

    Assembly Assembling the glass □ Unscrew all preassembled screws on the glass clamps. Next, assemble one glass panel to the other glass panel, and repeat this step for the rest of the two glass panels. Then, assemble the two glass panel pieces together with the final glass clamps as shown below. Putting on the glass Put the glass assembly made in step 1 on the top of the fire table body ・...
  • Page 16 Assembly Placing the protective cover. □ When the gas furnace is not used outside, it should be covered with a protective cover (S) to prevent the product from oxidization caused by exposure to sun and rain.
  • Page 17 Thank you for purchasing this product! If you have any questions about the product, such as missing parts, damaged products, product assembling, and operation, please contact us via Amazon Message or customer service number: 213-4467172 or 661-4358826 Please call our customer service department for any consulting: DATED PROOF OF PURCHASE IS REQUIRED FOR WARRANTY SERVICE.
