SITERWELL ELECTRONICS CO.,LIMITED GS521C User Manual

Smoke Alarm User Manual
Model number: GS521C
Thank you for purchasing our smoke alarm. Please take a
few minutes to read the user's manual thoroughly and
familiarize yourself and your family with its operation. And
save it for future reference.
Diagram 1
Product Specifications:
POWER: built-in DC3V(Panasonic CR-2/3AZ) Lithium

battery (battery not replaceable)
OPERATION CURRENT:<8uA (standby), <70mA

(alarm)
ALARM VOLUME: >85 dB (A) at 3 meters.

ALARM SENSITIVITY: 1.52-2.61%/ft OBS

SILENCE TIME: approx. 8 minutes

SMOKE ALARM SOUND PATTERN: Temporal 3

BI 0.5s - pause 0.5s – BI 0.5s – pause 0.5s – BI 0.5s –
pause 1.5s, with the red LED flash, repeat this alarm
pattern.
COMPLY WITH: UL217 &CAN/ ULC-S531

Description:
This unit is a photoelectric smoke alarm. The photoelectric
technology, it is more sensitive in detecting slow smoldering
fires which generate light smoke, little heat and may smolder
for hours before bursting into flames. This smoke alarm does
not contain any radioactive material. Smoke alarms should be
installed in every room (except the bathroom and kitchen),
finished attics and basements, making sure the people in the
home will be able to hear and respond to the alarm sound.
For minimum protection, you should install an alarm on
every level of the home particularly outside sleeping rooms.
Each alarm should be placed in the middle of the ceiling of
each room to be protected. Typical single storey dwelling
installation recommendations: Install a smoke alarm on the
ceiling or wall inside each bedroom and in the hallway
Ref：ST521C
- 1 -
outside each separate sleeping area. If a bedroom area
hallway is more than 30 feet long, install a smoke alarm at
each end. If there is a basement: install a smoke alarm on the
basement ceiling at the bottom of the stairwell. Typical
multi-storey dwelling installation recommendations: Install a
minimum of one smoke alarm on each occupiable level of the
home. Install a smoke alarm on the ceiling or wall inside
each bedroom and in the hallway outside each separate
sleeping area. If a bedroom area hallway is more than 30 feet
long, install a smoke alarm at each end install a smoke alarm
at the top of a first – to- second floor stairwell.
Important Safety Information:
1. The test button accurately tests smoke alarm functions. Do
not use any other test method. Test smoke alarm weekly to
ensure proper operation.
2. If you're sure it isn't a really alarm, open windows or fan
the air around smoke alarm to test and silence it.
3. THIS EQUIPMENT SHOULD BE INSTALLED IN
ACCORDANCE WITH
PROTECTION ASSOCIATION'S
(National Fire Protection Association, Batterymarch
Park,Quincy, MA 02269).
4. This smoke alarm is designed to be used inside a single
family home only. In multifamily buildings, each
individual living unit should have its own smoke alarms.
Do not install in non-residential buildings as this smoke
alarm is not a substitute for a complete alarm system.
5. Install a smoke alarm in every room and on every level of
the home. Smoke may not reach the smoke alarm for many
reasons. For example, if a fire starts in a remote part of the
home, on another level, in a chimney, wall, roof, or on the
other side of a closed door, smoke may not reach the smoke
alarm in time to alert household members. A smoke alarm
will not promptly detect a fire except in the area or room in
which it is installed.
6. Smoke alarm may not alert every household member every
time. The alarm horn is loud in order to alert individuals to
a potential danger. However, there may be some
circumstances where a household member may not hear the
alarm (i.e. outdoor or indoor noise, sound sleepers, drug or
alcohol usage, the hard of hearing, etc.). If you suspect that
this smoke alarm may not alert a household member, install
and maintain specialty smoke alarms. Household member
must hear the alarm's warning sound and quickly respond
to it to reduce the risk of injury, or death that may result
from fire, if a household member is hard of hearing, install
special smoke alarms with lights or vibrating devices to
Document NO.:RD-521C-39-001
THE NATIONAL FIRE
STANDARD72
Version: F Date: 20170802
