SMOKE ALARM USER MANUAL
PHOTOELECTRIC SMOKE ALARM GS526A
GS526A
PRODUCT SPECIFICATIONS:
built-in DC3V(CR-2/3AZ) Lithium ba�ery
Power:
Opera�on Current:
<8uA (standby), <70mA (alarm)
Sensor Type:
Photoelectric
OPERATION
Activation: Press test button and hold it for more than 3 seconds until LED lights, and release it within 2 seconds,
the unit will generate a "beep" indicating that it is activated and ready to detect status.
CAUTION: this unit must activated prior to installation. Failure to perform step will result in a non functioning smoke
alarm!
Testing: Test the unit weekly to ensure proper operation by pressing the test button.This will sound the alarm if the
electronic circuitry, horn, and battery are working properly. If no alarm sounds, the battery may be depleted or
another problem.
DO NOT use an open flame to test your alarm, you could damage the alarm or ignite combustible materials and start
a structure fire.
CAUTION: Due to the loudness (85 decibels) of the alarm, Always stand an arms-length away from the unit when
testing. Test the alarm weekly to ensure proper operation. Erratic or low sound coming from your alarm may indicate
a defective alarm.
LED indicators: This smoke alarm is equipped with red LED indicators.
Standby Condition: The red LED will flash every 40 seconds to indicate that the smoke alarm is operating properly.
Alarm Condition: When the alarm senses products of combustion and goes into alarm, the red LED will flash rapidly
(one flash per second).The rapid flashing LED and pulsating alarm will continue until the air is cleared or the test
button is released.
Silence Condition: The red LED will flash every 8 seconds as long as the alarm is in Hush mode.
Alarm Volume:
Alarm Sensi�vity:
Comply With:
>85dB(A) at 3 meters
1.6-2.74%/� OBS
UL217 &CAN/ULC-S531
Advertisement
Table of Contents
Related Manuals for SITERWELL ELECTRONICS CO.,LIMITED GS526A
Summary of Contents for SITERWELL ELECTRONICS CO.,LIMITED GS526A
- Page 1 SMOKE ALARM USER MANUAL PHOTOELECTRIC SMOKE ALARM GS526A GS526A PRODUCT SPECIFICATIONS: Alarm Volume: built-in DC3V(CR-2/3AZ) Lithium ba�ery >85dB(A) at 3 meters Power: Opera�on Current: Alarm Sensi�vity: <8uA (standby), <70mA (alarm) 1.6-2.74%/� OBS Sensor Type: Photoelectric Comply With: UL217 &CAN/ULC-S531 OPERATION Activation: Press test button and hold it for more than 3 seconds until LED lights, and release it within 2 seconds, the unit will generate a “beep”...
- Page 2 Low battery trouble indication: An intermittent “chirp” accompanied by a red LED flash every 40 seconds indicates a low battery, you may press the test button to silence the trouble indication for 10 hours, but it will reset automati- cally after 10 hours. During this condition the unit will continue to operate normally and detect smoke and sound an alarm.
Need help?
Do you have a question about the GS526A and is the answer not in the manual?
Questions and answers
I just installed smoke alarms wondering why red light flashes continuously or if this normal?
The red LED on the SITERWELL GS526A smoke alarm flashes under different conditions:
- Standby Condition: The red LED flashes every 40 seconds to indicate normal operation.
- Alarm Condition: The red LED flashes rapidly (one flash per second) when smoke is detected.
- Silence Condition: The red LED flashes every 8 seconds in Hush mode.
- Low Battery Trouble Indication: The red LED flashes every 40 seconds along with an intermittent chirp.
If the red light is flashing continuously and rapidly, it indicates an alarm condition. If it flashes at regular intervals, it may be in standby, hush mode, or indicating a low battery.
This answer is automatically generated
