- Page 1 ICE MAKER INSTRUCTION MANUAL Model: IM2200D-UL Read this manual thoroughly before using and save it for future reference Guangdong Xinbao Electrical Appliances Holdings Co., LTD ADDRESS: ZHENGHE SOUTH ROAD, LELIU TOWN, SHUNDE DISTRICT,FOSHAN CITY, GUANGDONG PROVINCE, CHINA 第 0 页 共 12 页...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, explosion, electric shock, or injury when using your ice maker, follow these important safety instructions: 1. Before using check that the voltage power corresponds to the one shown on the appliance nameplate. 2. - Page 3 suffer from frostbite. 14. Do not immerse any part of the product in water. 15. To disconnect, turn any control to “OFF”, then remove plug from wall outlet. 16. Do not plug or unplug product with wet hands. 17. Unplug the product before cleaning,maintaining and when not in use. 18.
- Page 4 35. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. 36. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. 37. WARNING: Do not damage the refrigerant circuit. 38.
-
Page 5: Control Panel
KNOW YOUR ICE MAKER CONTROL PANEL Key (with indicator) Function The indicator lights in green when select large ice. The indicator lights in green when select small ice. “CLEAN” indicator lights up when the appliance is cleaned Start or stop the appliance Select the ice size 第... -
Page 6: Before First Use
The indicator lights in green when making ice. The indicator lights in red when the water reservoir is lack of water. The indicator lights in red when the ice basket is full. BEFORE FIRST USE 1. Unpack the appliance, then check and make sure that all the accessories including ice basket and ice scoop etc. - Page 7 NOTE: Please make the ice maker be rested for 30 minutes before plug if it has been moved. 3. Open the top lid and remove the ice basket. 4. WARNING: Fill the water reservoir with potable water only. NOTE: Do not fill above the MAX water level mark. 5.Replace the ice basket and close the top lid.
-
Page 8: Cleaning And Maintenance
the “ ” key and unplug the unit from the wall outlet. 13. Open the top lid and transfer the ice to a freezer. NOTE: The ice will last in the ice maker for up to a 18 hour period, depending on the ambient temperature. -
Page 9: Troubleshooting
NOTE: Do not use organic solvent, boiled water, detergent, strong acid and strong alkali etc. for cleaning. 9. Please empty the water reservoir and dry it for storage if the ice maker is not used for a long time. Fig.1 Drain plug Drain plug Fig.2... - Page 10 of water reservoir is blocked. ice-making cycle. 3. Pump malfunction. 2. Do cleaning. 4.The water inlet of Ice Maker is 3. Send it to the authorized not connected with external department for repair. water source, or the external 4. Check and make sure the water source is closed.
- Page 11 work after restart. The ice basket is full The “ice full” condition can not Unplug the appliance and be detected as the infrared light move it to a place which is but the “ ” module is interfered by the not exposed to the sunlight, indicator does not sunlight.
-
Page 12: Technical Parameters
10℃ and 32℃. TECHNICAL PARAMETERS Model: IM2200D-UL Applicable climate: ST/SN/N/T Class: Electrical Rating : AMP 1.8A 120V AC 60HZ Rated power: 130W Refrigerant/Refrigerant amount: R600a/0.0605LBS Design Pressure: Upper limit: 290Psig Lower limit:138Psig Foaming agent:...
