LABEL DISPENSER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VEVOR LDW-20-V1
Summary of Contents for VEVOR LDW-20-V1
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support LABEL DISPENSER USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
-
Page 2: Label Dispenser
This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product. -
Page 3: General Safety Rules
1. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. 2. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. GENERAL SAFETY RULES Important reminder 1.Before use, please carefully read the product manual and ensure that you understand and comply with all safety warnings and usage precautions. - Page 4 mismatched devices to avoid risks such as electric shock and fire. 3. When foreign objects are found on the surface of the product, please immediately stop using and remove the foreign objects before continuing to use. 4. When using this product continuously for a long time, please rest in good time to avoid excessive fatigue.
- Page 5 MODEL AND PARAMETERS Model LDW-20-V1 LDW-20-V2 LDW-20-V3 Label Width 10~115mm 10~115mm 10~115mm ＞5mm ＞5mm ＞5mm Label Length Label Roll I.D 25-75mm 25-75mm 25-75mm ＜200mm ＜200mm ＜200mm Label Roll O.D Speed 0~730cm/min 0~730cm/min 0~730cm/min Input AC100~240V 50/60Hz Power(Max.) 21.6W 21.6W 21.6W...
-
Page 6: Structure Diagram
STRUCTURE DIAGRAM 1. Baffle 2.Nut 3.Fixed Axis 4. Pressing Plate 5. Panel 6.Scroll 7. Paper Bail 8. Base 9.Limiter 10.Switch 11. Speed Knob - 5 -... - Page 7 COMPONENTS LDW-20-V LDW-20-V LDW-20-V Model Parts Power Cord(Adapter ×1 ×1 ×1 included) Baffle ×1 ×1 ×1 ×1 ×1 ×1 Paper Bail ×1 ×1 ×1 Large Label Holder ×2 ×2 ×2 Small Label Holder ×2 ×2 ×2 Cross Screw(M4*8mm) ×2 ×2 ×2 ×1 ×1...
- Page 8 OPERATING INSTRUCTIONS 1.Remove the screws,install the label bracket and lock the screws as shown. Screw 2.Select a suitable label holders and insert them into the inner hole of the label roll,then insert them together on the fixed axis,buckle the baffle and lock the nut as shown.
- Page 9 4.Wrap the label backing paper tightly around the scroll.Press the label backing paper in the slot of the scroll with the paper bail, and then insert the paper bail into the hole of the scroll as shown. Note： The installed labels should be aligned smoothly from the fixed axis to the scroll.(from beginning to end) Otherwise, the label will be easily torn.
-
Page 10: Maintenance
The operating instructions 1. Adjust the limiter to the stripper plate spacing according to the label size. Note:The limiter can be rotated forward or backward; The limiter can also be stretched out and drawn back either leftward or rightward. 2.In case of any deviation during peeling of labels,it may be corrected by adjusting the extension distance of the stripping plate. -
Page 11: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Possible Solution Plug in the power and The power supply is not make sure the switch is plugged in. The label roll is not Label roll reloaded. installed properly. Product not working 1. Label backing paper is not tightly wound to Label backing paper is the scroll. - Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
