- Page 1 GH2068 15L PORTABLE FRIDGE/FREEZER INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
CONTENTS Warnings & Safety Information ................ 3 Before First Use ....................4 Features ........................ 5 Box Contents ......................5 Product Dimensions ................... 5 Product Diagram ....................6 Operation ......................6 Power Supply and Charging ................8 Battery Usage ....................11 Food Storage ......................11 Troubleshooting ....................12 Smart Control - Fridge App Instructions ............13 Cleaning, Care, Storage &... -
Page 3: Warnings & Safety Information
WARNINGS & SAFETY INFORMATION WARNING: The manufacturer is not responsible for any potential injury from misuse Warnings • Do not operate the appliance if it is visibly damaged. • Do not block the gaps of the fridge with things like pins or wires, etc. •... -
Page 4: Before First Use
Notice • Disconnect the power supply before each cleaning and maintenance and after every use. • Do not use sharp tools to defrost; Do not damage the refrigerant circuit. • Risk of child entrapment. Before you throw away your old refrigerator or freezer: take off the doors: leave the shelves in place so that children may not easily climb inside. -
Page 5: Features
FEATURES • Optional removable 15.6AH, 7.8AH or 5.2AH battery • Solar charging interface • DC power connections • Powered by AC using the optional AC to DC power adapter • High-efficiency DC compressor and conversion module • Dual mode operation (Max & Economy) •... -
Page 6: Product Diagram
PRODUCT DIAGRAM OPERATION • Power Supply: connect to DC 12V/24V or AC 100-240V power (using dedicated adapter). • Display Screen Initialization: connect to the power supply, the buzzer will make a long beep, and the display will be on for 2 seconds then enter the normal operating mode. - Page 7 • Temperature setting range: -20~20°C (-4~68°F) • Cooling Mode: under the running state, press to switch MAX(fast cooling) and ECO (Energy saving Mode). (*Factory setting is MAX.) • Temperature Unit Setting: switch off the fridge, long press for three seconds until E1 displays, keep pressing until E5 displays.
-
Page 8: Power Supply And Charging
POWER SUPPLY AND CHARGING • Power Supply: The refrigerator can be powered by 12V / 24V DC power • 100-240V AC (By optional adapter) • Optional removable Lithium battery if there is no connection of DC/ AC power. DC/ AC power will run the refrigerator, and charge the optional removable battery simultaneously. - Page 9 WARNING: Do not open or disassemble the battery. Only use approved chargers with the fridge battery, incorrect chargers may result in fire, damage, a shortened battery life. Do not disassemble, impact, squeeze, crush, or throw or misuse the fridge battery, do not dispose of in fire, any of which may result in short circuit and fire or explosion.
- Page 10 AC Charging Management If the fridge has not been used for a long time, the battery may be discharged, and the fridge will not power on. Please use the AC adapter to charge the fridge battery and run the fridge. After the fridge battery has charged up to 30%, you can switch to other methods for charging.
-
Page 11: Battery Usage
BATTERY USAGE Optional Removable Battery: The lithium battery is back up power to keep the refrigerator working for short periods while off grid. Notice: When not using the battery power or fridge for a long time, please turn off the battery output. -
Page 12: Troubleshooting
TROUBLESHOOTING ISSUE SUGGESTED REMEDY Refrigerator does not work • Check if the switch is on. • Check if the plug and socket are connected well. • Check if the fuse has been burnt. • Check if the power supply is malfunctioned. •... -
Page 13: Smart Control - Fridge App Instructions
SMART CONTROL - FRIDGE APP INSTRUCTIONS... -
Page 14: Cleaning, Care, Storage & Maintenance
CLEANING, CARE, STORAGE & MAINTENANCE WARNING: Never use hard or sharp tools to remove ice or to loosen objects frozen in place. Cleaning • Unplug the device first to avoid electric shock. • Use wet cloth to clean the device and dry it. •... -
Page 15: Specifications
SPECIFICATIONS Input Voltage 12/24V DC, (To power from mains use the included 240V AC to 12V DC power adapter) Max Power 60W (Compressor running) Power Consumption 0.2kw.h / 24hr Rated Current for DC 5A (12V) / 2.5A (24V) Temperature Range -20 to +20ºC (ambient temp. -
Page 16: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 3 years. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose. This warranty will not cover modified product;...
