  • Page 1 User Manual Brighten Your Digital View! DMM- Dual Channels H.264 HD IRD and Processor 2200P P/N. 85E19-H0101 Rev: A www.pbi-china.com...
  • Page 2 DMM-2200P Dual Channel H.264 HD IRD and Processor Contents Pro Broadband Inc.

  • Page 3: Warranty

    For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service, or the shop where you purchased the product. COPYRIGHTS Television programs, movies, video tapes, discs, and other materials may be copyrighted. www.pbi-china.com...

  • Page 4: Power Sources

    If the product will not be used for a long period of time, disconnect it from the AC power outlet or wall socket. Before Using the Device Thank you for purchasing the DMM-2200P dual channel H.264 HD IRD and professor. This User Pro Broadband Inc.

  • Page 5: For Your Safety

    Brighten Your Digital View! Manual is written for operators/users of the DMM-2200P to assist in installation and operation. Please read this user manual carefully before installation and use of the device. FOR YOUR SAFETY This equipment is provided with a protective earthing ground incorporated in the power cord. The main plug shall only be inserted in a socket outlet provided with a protective earth contact.

  • Page 6: Technical Specifications

    DVB common interfaces, DMM-2200P could decrypt multiple services in one transport stream or two. DMM-2200P is also a professional IRD that features decoder for MPEG-2 and MPEG-4 AVC/H.264 in both Standard Definition and High Definition formats, and provides digital and analog outputs, including CVBS video, analog Audio, and HDMI.
  • Page 7 UDP/RTP, Multicast/Unicast, IGMPv2, ARP Multicast Channel 32 Max. TS Processing TS Input Management Demu× and Remu× among Tuner1, Tuner2 and TS/IP Inputs TS Output Management Demu× and Remu× for 2 independent ASI outputs Service and PID Management Remu×, filtering and remapping www.pbi-china.com...
  • Page 8 DMM-2200P Dual Channel H.264 HD IRD and Processor PSI/SI PSI/SI table regeneration, PMT and SDT edition Descrambler DVB Common Scrambling Algorithm (CSA) BISS Mode BISS-1, BISS-E Common Interface Double PCMCIA slots, compatible with major CA CAMs in the market ASI Output Connector Type 2 independent BNC female, 75Ω...

  • Page 9: Order Information

    Power Supply DC 3.3V/5V/12V Power Consumption Operating temperature 0 ~ 45℃ Storage temperature -10 ~ 60℃ Operating Humidity 10 ~ 90%, non-condensed 4. Order Information Interface Model DMM-2200P-S2/S DMM-2200P-T2/T/C Input DVB-S2/S （ DVB-T2/T/C （ TS/IP ● ● Output HDMI ●...

  • Page 10: Front Panel And Rear Panel Instructions

    DMM-2200P Dual Channel H.264 HD IRD and Processor 6. Front panel and rear panel instructions 6.1. Front panel Pro Broadband Inc.

  • Page 11: Rear Panel

    B2 Tuner In-1 Tuner input interface 1. B3 ASI Out-2 ASI output interface 2. B4 ASI Out-1 ASI output interface 1. B5 CVBS CVBS output interface (BNC). B6 Audio Analog audio output (DB9 female). B7 HDMI HDMI output interface (HDMI 1.3). www.pbi-china.com...

  • Page 12: Overview Of The Menu

    7. Operation instructions using DMM-1000CU programmer NOTE: The DMM-1000CU Programmer is an universal programmer unit for PBI DMM products family. DMM-1000CU is a standalone product and not included in the package of DMM-2200P, please contact local sales agency for more information.
  • Page 13 Brighten Your Digital View! System: Configure local settings of module. 7.2. Description of menu 7.2.1. Status www.pbi-china.com...
  • Page 14 DMM-2200P Dual Channel H.264 HD IRD and Processor Main Menu Sub Menu Details Status Input TS Tuner1 Tuner1 input valid and total bit rate Tuenr2 Tuner1 input valid and total bit rate IP Input IP input valid and total bit rate...
  • Page 15 Brighten Your Digital View! www.pbi-china.com...
  • Page 16 DMM-2200P Dual Channel H.264 HD IRD and Processor Main Menu Sub Menu Option Config Tuner 1/2 LNB Frequency Manual config Satellite Frequency Manual config Symbol Rate Manual config LNB Voltage OFF/13V/18V LNB 22KHz ON/OFF DiSEqC Port A/B/C/D Decoder Source Tuner1/Tuner2/CI-1/CI-2/IP/Remux/BISS...
  • Page 17 Brighten Your Digital View! Main Menu Sub Menu Details System Version Info Software details Network IP Address Management IP address (Manual config) www.pbi-china.com...

  • Page 18: Web Control

    Upgrade module through USB key (Yes/No) 8. Web Control DMM-2200P has an integrated web server. This web server allows configuration and status requests with a standard web browser. First make sure the IP Control port is well connected in the network and can be pinged by the host PC.
  • Page 19 Brighten Your Digital View! Figure 8-1 Login 8.1. Status Via the status page, user can have an overview of the current working status of DMM-2200P. www.pbi-china.com...
  • Page 20 DMM-2200P Dual Channel H.264 HD IRD and Processor Figure 8-2 Input Status Figure 8-3 Output Status Pro Broadband Inc.
  • Page 21 All configuration for Tuner1, Tuner2, CI1, CI2, BISS, built-in Re-mux, TS/IP, ASI output and Decoder can be found under the Configuration tab on the webpage. Click the button "Apply" to submit your configuration or click the button "cancel" to undo your configuration, as it shown in figure below. 8.2.1. Tuner1 & Tuner2 www.pbi-china.com...
  • Page 22 Dual Channel H.264 HD IRD and Processor There are two independent tuners on one DMM-2200P module. Click on the “Tuner-1” or “Tuner-2” to configure it. Two tuners have the same options. Because of it supports five different types of tuner, DVB-S2/S/C/T/T2.
  • Page 23 Brighten Your Digital View! Figure 8-6 CI 8.2.3. BISS BISS Mode: 3 options, Mode 0(OFF), Mode 1, Mode E. www.pbi-china.com...
  • Page 24 DMM-2200P Dual Channel H.264 HD IRD and Processor Figure 8-7 BISS 8.2.4. Remux Remux Switch: enable or disable re-mux function. Remove CA: remove all of CA descriptor in PMT and ECM/EMM after re-muxing. TS ID: re-mux transport stream ID. EIT Switch: pass through EIT of re-muxed services.
  • Page 25 Stream Netmask: Subnet Mask for TS over IP board. Stream Gateway: Gateway for TS over IP board. Gateway MAC Address: Gateway MAC address for TS over IP. Mode: DVB(Pass through all service in source)/IPTV(Filter useless services in source). Figure 8-9 TS/IP Out www.pbi-china.com...

  • Page 26: Asi Output

    DMM-2200P Dual Channel H.264 HD IRD and Processor 8.2.5.2. TS/IP In Uni/Multicast IP Address: transport stream IP address of receiving. Uni/Multicast UDP Port: transport stream IP port of receiving. Protocol: UDP/RTP. Stream IP Address: local IP address for TS over IP board.
  • Page 27 Source: choose transport stream for using. Current Program: which program are decoded from the transport stream. Program List: program list of transport stream. Mode Selection: Auto ( Automatically play first service )/Manul Selection (Select service manually). Figure 8-12 Program www.pbi-china.com...

  • Page 28: Video Output

    DMM-2200P Dual Channel H.264 HD IRD and Processor 8.2.7.2. Video Output Video Standard: Auto/576I 25/480I 29.97/576P 50/480P 60/720P 50/720P 59.94/720P 60/1080I 25/1080I 29.97/1080I 30. Aspect Ratio: Auto/4:3 Full/4:3 Letterbox/16:9 Full. DVB Subtitle Language: it will show all the DVB subtitle language for the current decoding service, it can be set as off if you do not want to display any subtitle.

  • Page 29: Audio Output

    Note: the IP address of the device is not reset to the factory setting! While press the button IP Reset via the front panel, the IP address is reset to the factory setting (10.10.70.48). Device Reboot:User can reboot this device by clicking the button “Device Reboot”. www.pbi-china.com...
  • Page 30 DMM-2200P Dual Channel H.264 HD IRD and Processor Figure 8-15 Device 8.3.2. Network IP Address: IP Control address. Subnet Mask: IP Control subnet mask. Default Gateway: IP Control gateway. MAC Address: read only. Trap IP Address: alarm information receiving server IP address(SNMP).
  • Page 31 Recall: recall all settings from preset file which selected. Delete: delete the preset file which selected. Download: download all preset files to local PC. Browse: choose local preset file on PC. Upload: upload selected local preset file from PC to DMM2200P. www.pbi-china.com...
  • Page 32 DMM-2200P Dual Channel H.264 HD IRD and Processor Figure 8-18 Preset 8.3.5. Upgrade Browse: choose upgrade file target.tgz. Upgrade: enable upgrade process. Figure 8-19 Upgrade Pro Broadband Inc.

  • Page 33: Installation

    Connect all input output cables and Ethernet cables.  Plug the power cable into DMM-1000MF or DMM-200MF. The POWER Indicator LED (A4) should be green and always light on during working. The DMM-2200P needs 1.5-2 minutes to boot up completely. ...
