- Page 1 ASES Security Pvt. Ltd. FIRE ALARM SYSTEM Model : SI-Fire Scan SI-FS-2Z/4Z E.R.T.L., (North) Tested as per IS : 2189/1999 Known for Absolute Reliability... Sold All Over India and Abroad... I N S T R U C T I O N...
- Page 2 e ASES a leading Unit-1 Sahibabad Ind. Area manufacturer of Fire Alarm Systems, Fire Rated Doors, Fire Pump Control Panels, Emergency Lights, PA/VA Systems etc. With a sound infrastructure we manufacture wide range of Control Panels that are used by several institutions.
-
Page 3: About The Product
Hi-Tech superior technologies. ABOUT THE COMPANY We proud to introduce ourselves, as “ASES Security Pvt. Ltd. (Brand name: Agni Suraksha)” a well known name in the field of Fire Alarm System. We are in this field from last 20 years. We have reached the remarkable height because of our professionalism and best qualities of our products. -
Page 4: Mechanical Construction
FEATURES: Fully con rms IS 2189 Operates on 230 V AC, 50 Hz AC supply Battery backup with built in charger TCP/IP compatibility for BMS/CMS Fire / fault status in unambiguous colored LED indications. 16 x 2 line dot matrix LCD display External s/w for Reset, Silence, Lamp test, Evacuate. -
Page 5: Installation And Commissioning
Note: Apart from the above green LED's if any other amber or red LED is ON, it is indicating respective re or faults. Rectify the re or faults before proceeding to any other operation. In normal condition LCD will show the following lines : ASES Security P. Ltd. All Zones Normal... -
Page 6: System Operation
SYSTEM OPERATION Green Power LED : A green LED shall normally be on indicating that the system if receiving AC electrical power. A failure of control panel shall cause the LED to off. Yellow Trouble LED : A yellow “Trouble LED shall be in on condition along with audible sounder (Buzzer) sound when any trouble is detected in the system. -
Page 7: Single Line Diagram
Single Line Diagram Zone 1 Detectors Up to 18 Zone 2 Detectors Up to 18 Common Hooter 2-Core Wire Smoke / Multi / Heat Detector and MCP 2-Core for Common Hooter 2-Core each Zone wise Hooter... -
Page 8: Connection Diagram
CONNECTION DIAGRAM: Z 1 + H 1 + Z 2 + H 2 + Z 3 + H 3 + Z 4 + BAT + H 4 + BAT - Z 5 + H 5 + Z 6 + H 6 + Z 7 + H 7 + Z 8 +... - Page 9 SERVICING I FAULT FINDING If you have any problem read this user manual again & check the center measure for each symptoms listed below: If the problem persists, record down your system number from the warranty card and call us or e-mail asesmail@asesindia.com Symptoms Counter measure...
-
Page 10: Warranty Certificate
WARRANTY CERTIFICATE Dear Customer, Your ASES Security Pvt. Ltd., Fire Alarm System is guaranteed against manufacturing defects of parts and components for a period of 12 months from the date of purchase ......(During this period any items found defective will be repaired at works or through service center. - Page 11 32° to 120° Fahrenheit This is certify that 2/4 Zone IRIS (IR-2/4Z) supplied as per details has been manufactured by ASES Security Pvt. Ltd. tested as per the provision laid down in IS 2189-1988 and the Electronics Regional Test Laboratory (ERTL).
