- Page 1 ASES Security Pvt. Ltd. FIRE ALARM SYSTEM Model : IRIS 2/4 Zone E.R.T.L., (North) Tested as per IS : 2189/1999 Known for Absolute Reliability... Sold All Over India and Abroad... I N S T R U C T I O N...
- Page 2 e ASES a leading Unit-1 Sahibabad Ind. Area manufacturer of Fire Alarm Systems, Fire Rated Doors, Fire Pump Control Panels, Emergency Lights, PA/VA Systems etc. With a sound infrastructure we manufacture wide range of Control Panels that are used by several institutions.
- Page 3 Hi-Tech superior technologies. ABOUT THE COMPANY We proud to introduce ourselves, as “ASES Security Pvt. Ltd. (Brand name: Agni Suraksha)” a well known name in the field of Fire Alarm System. We are in this field from last 20 years.
-
Page 4: About The Product
ABOUT THE PRODUCT ASES is very proud of to introduce IRIS the completely digital microprocessor based panel in Indian re industry by using the digital technology. IRIS can give you accuracy in its performance. For the ease of user there are 16 x 2 character LCD display in the panel by which situation can be visually identify as well as LED indications are also available. -
Page 5: Mechanical Construction
FEATURES: Fully con rms IS 2189 Operates on 230 V AC, 50 Hz AC supply Battery backup with built in charger Fire / fault status in unambiguous colored LED indications. 16 x 2 line dot matrix LCD display Zone wise re, open, short LED indications. External s/w for Reset, Silence, Lamp test and Evacuate. -
Page 6: Installation And Commissioning
INSTALLATION AND COMMISSIONING: INSTALLATION The installation of the re detection and alarm should comply with: The Institute of Electrical Engineers (IEE) wiring regulation. The Indian Standard of Fire Detection and Alarm for building. The installation cable should not be in the area of proximity of high voltage cable or induce electrical interference. - Page 7 COMMISSIONING Check the all entered wiring is correctly identi ed and also check the cables are free from fault conditions by a multimeter. Connect the external wiring into their respective terminals and ensure the End Of Line (EOL) resistor is placed at the last device of circuit.
-
Page 8: Indicators And Controls
INDICATORS AND CONTROLS INDICATORS Normal: In the Normal Condition, MAINS ON, SYSTEM ON, ZONE ON green LED's will be illuminated along with CHARGING ON AMBER led. There should be no other amber/red LED visual indication or audible tone. Power Fault: When power fault conditions like AC fail occurs the Mains On indication will put off... - Page 9 CONTROLS: RESET Key: This key is used to reset the entire system. While in reset condition, all detector loop voltages are cut off up to 2 seconds for Detector and MCP become reset and then voltages are put ON to the loop. Note: We strongly recommend to avoid to do the RESET unless there is re in the zone.
-
Page 10: Technical Data
TECHNICAL DATA Panel Operating Condition Operating Voltage AC Power : 220V ac, 50Hz ± 10% Standby : 24V dc Operating Temperature : 0°C to 40°C Operating Humidity : 95% (non-condensing) Zone Operating Condition Normal Loop Voltage : 19.5 to 21.5 V dc Open Threshold Current : 4.4 mA Short Threshold Current... -
Page 11: Connection Diagram
CONNECTION DIAGRAM:... - Page 12 Single Line Diagram Zone 1 Detectors Up to 18 Zone 2 Detectors Up to 18 Common Hooter 2-Core Wire Smoke / Multi / Heat Detector and MCP 2-Core for Common Hooter DO’S & DON’T: DO'S: The panel and detectors should be within the temperature range of 0°C to 40°C.
- Page 13 SERVICING / FAULT FINDING If you have any problem read this user manual again & check the center measure for each symptoms listed below: If the problem persists, record down your system number from the warranty card and call us or e-mail asesmail@asesindia.com Symptoms Counter measure 1) System dead...
-
Page 14: Warranty Certificate
WARRANTY CERTIFICATE Dear Customer, Your ASES Security Pvt. Ltd., Fire Alarm System is having Warranty against manufacturing defects of parts and components for a period of 12 months from the date of purchase ......(During this period any items found defective will be repaired at ASES works or through ASES service center). - Page 15 32° to 120° Fahrenheit This is certify that 2/4 Zone IRIS (IR-2/4Z) supplied as per details has been manufactured by ASES Security Pvt. Ltd. tested as per the provision laid down in IS 2189-1988 and the Electronics Regional Test Laboratory (ERTL).
- Page 16 ASES Security is a registered trademark of ASES Security in India and other countries. © Copyright ASES Security, 2015. All rights reserved. Any unauthorized reproduction or use of logos, design elements is strictly prohibited by law. No part of the compilation may be reproduced in any manner or translated without written permission.
