BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
A.
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
HOW TO USE THESE INSTRUCTIONS
B.
S Install unit to a level subfloor.
S Provide properly dimensioned framing.
S Baths are designed for a variety of installations,
depending upon the model chosen.
D. PRODUCT INSPECTION
Carefully unpack and inspect the bath for damage. Leave
all materials in the carton during construction to prevent
damage.
Do not remove the clear protective film from the bath
surface until installation is complete.
INSTALLATION REQUIREMENTS
A. TOOLS REQUIRED
S Conventional woodworking tools
S Rule
S Level
S Safety shoes
S Safety glasses
S Square
S Utility knife
BA
114848-2-
(A)
R
C. PLUMBING SPECIFICATIONS
E. CONNECTIONS AND SERVICE ACCESS
B. MATERIALS REQUIRED
1 1
ACRYLIC BATHS
All information in this manual is based upon the latest
product information available at the time of publication.
Kohler Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
These instructions contain important care, cleaning, and
warranty information – please leave instructions for the
consumer.
Confirm adequate mounting and connection space of the
faucet specified for your installation.
Before installation, ensure proper access to the final
connections.
NOTICE: An access panel for drain connections will
simplify future maintenance.
S Plumbers putty
S Wall coverings, as necessary
S Silicone sealant
S Gypsum cement (optional)
S Construction adhesive (optional)
S 2x4's
S Drop cloth
S Nails
E1998 Kohler Co.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kohler Basic 6030 K-1102-S-0
Summary of Contents for Kohler Basic 6030 K-1102-S-0
- Page 1 Kohler Co. reserves the right to make changes in product sequences. Follow the sections that pertain to your characteristics, packaging, or availability at any time particular installation.
-
Page 2: Site Requirements
Use the stud construction appropriate for your particular bath model. Some modifications may be needed for other types of construction, if preferred. Corner Installation: suggested stud construction is illustrated. 1/16” Gap Between Bath Bath Rim and Framing Kohler Co., Kohler, WI 114848-2-... -
Page 3: Plumbing Preparation
Make sure the bath will be supported by the bath base, not the rim. Do not hang the bath by the rim. D. PLUMBING PREPARATION Position the plumbing according to the roughing-in dimensions. Cap the supplies, and check for leaks. Kohler Co., Kohler, WI 114848-2-... -
Page 4: Before Installing Unit
This will help secure, level, and support the unit. Set the bath into position. Insert the drain tailpiece into the trap. Make sure the bath is level and resting flat on the bath base. Kohler Co., Kohler, WI 114848-2-... -
Page 5: Install Plumbing
Tape and mud the water-resistant wall material. Install the finish wall material to the wall material as shown. Seal the joints between the bath rim and the finish wall material with silicone sealant. Water-Resistant Wall Material Kohler Co., Kohler, WI 114848-2-... -
Page 6: Complete Installation
Do not use metal scrapers, wire brushes, or other metal tools. A powder-type detergent may be used on a damp cloth to provide mild abrasive action to the residual plaster. Kohler Co., Kohler, WI 114848-2-... -
Page 7: Important Consumer Information
Kohler Co., Kohler, Wisconsin 53044 C. CLEANING YOUR ACRYLIC BATH One of the joys of owning a Kohler acrylic unit is the ease of cleaning. There are no seams or tight corners for lime or mildew build-up. As with any smooth surface, avoid using abrasive cleansers on your acrylic bath. - Page 8 Kohler Co., Kohler, WI 114848-2-...
