- Page 1 SM2 Series DL Smart Camera User Manual V2.3.11. 2023 www.contrastech.com...
- Page 2 Purpose This Manual is a basic description of SM2 series Smart Cameras, which mainly includes the product description, quick installation guide and Simple introduction of SDK(SM-Datum). This manual may be updated due to product upgrades or other reasons. If you need, please contact the sales engineer for the latest version of this manual.
-
Page 3: Product Description
Product Introduction With built-in positioning and measurement algorithms, the SM2 series vision sensor can detect an object's existence, count patterns, spots, etc. It can be monitored and operated via the SM-Datum client. It can output results via RS-232 and Ethernet, and cooperate with other processes via IO. -
Page 4: Mechanical Dimensions
Mechanical Dimensions The dimensions is in millimeters： 产 Single Line Output Structure 品 The cameras are interfaced to an external circuity via 17-pin connectors located on the housing and contain power, I/O, Ethernet, 简 and serial signals. The interface is threaded. Tightening the interface during use can reduce the loosening of the interface caused by 介... -
Page 5: I/O Interface Definition
The lines of other pins should be wired according to the actual demands. The wire color of this user manual is the color of ContrasTech. If you use other manufacturers' cable color definitions may be different, random connection may cause the camera to burn out, please connect according to the I/O port type and pin definition or contact our technical staff for advise. -
Page 6: Status Led Description
Streaming Status / Project Result NG The wire color of this user manual is the color of ContrasTech. If you use other manufacturers' cable color definitions may be different, random connection may cause the camera to burn out, please connect according to the I/O port type and pin definition or contact our technical staff for advise. -
Page 7: Installation And Setup
Windows 10 (32 bit or 64 bit) Installation Steps 1.You can download the SM-Datum software（Smart Cameras SDK For Windows）from： http://www.contrastech.com/service/005001008.html 2.Double click SM-Datum installation package to install the client. 3.Follow the instructions on the screen. The installer will guide you through the installation process. -
Page 8: Hardware Installation
与 computer. 操 Make sure that the following items are available before starting the installation： 作 ■ SM2 Series Smart camera ■ Applicable switch or network card ■ The computer with a GigE network adapter installed ■ The computer must be equipped with appropriate operating system ■... -
Page 9: Software Operation
Software Operation 安 SM-Datum Operation 装 1、Double-click the SM-Datum shortcut on the desktop to open up the client software. 与 2、The Software refreshes the camera list automatically.To add a remote camera, click type in the IP address. 操 作 Make sure the connection between the remote camera and the PC is established when adding remote cameras. 3、Make sure that the device to be connected is available and selected. -
Page 10: Device Operation
Device Operation 安 After login, the software main interface as below. 装 与 操 作 See the description of each area in the table below. Name Description Related settings can be made for program management, I/O settings, communication settings, ① Menu Bar camera settings,operation management and and camera monitoring. -
Page 11: Input Signal
电 I/O ELECTRICAL FEATURE 气 特 AND WIRING 性 CHAPTER 4 与 接 线 I/O Electrical Feature Single Line Output Structure This section introduces the electrical feature and wirings of the device’s I/O and RS-232 serial port. The device has two input signals (Line 0/1), three output signals (Line 5/6/7), and three bi-directional I/O (Line 2/3/4) signals. - Page 12 I/O Electrical Feature Right Angle Rotation Structure 电 This section introduces the electrical feature and wirings of the device’s I/O and RS-232 serial port. The device has three opto-isolated 气 inputs(Line 0/1/2), three opto-isolated outputs (Line 3/4/5), and one RS-232 serial port. 特...
-
Page 13: Output Signal
I/O Electrical Feature Single Line Output Structure 电 Output Signal 气 特 The device's Line 5/6/7 are output signals, and Line 2/3/4 are bi-directional I/O signals that can be set as output. You can go to I/O settings of the client software to set I/O output type as PNP or NPN according to actual demands, as shown below. 性... - Page 14 I/O Electrical Feature The maximum output current of the output signal is 200 mA. 电 气 特 50 % 50 % 性 Internal Logic 内部逻辑 与 接 Output Level High 输出高电平 90 % 90 % 线 50 % 50 % Output Level Low 10 % 10 %...
- Page 15 I/O Electrical Feature Right Angle Rotation Structure 电 Output Signal 气 特 The device's LINE 3/4/5 are opto-isolated outputs, the output voltage ranges from 5 VDC to 30 VDC, the maximum output current is 45 mA, and their internal circuit is as follows. 性...
-
Page 16: Input Wiring
I/O Wiring The device can receive input signals from external devices and output signals to external devices. This section introduces how 电 to wire the device’s I/O. 气 Single Line Output Structure 特 Input Wiring 性 与 Input signal wiring may differ by external device types. Here we take Line 2 as an example to introduce I/O wiring. ●... -
Page 17: Output Wiring
I/O Wiring ● Switch, it is recommended to use 1 KΩ pull-down resistor. 电 气 Single Pole 单刀双 特 Double Throw Device Power 设备电源 掷开关 Switch 性 Input Signal 输入信号 与 接 Device Power Ground 设备电源地 线 Output Wiring You can set I/O output type as PNP or NPN via the client software. ●... -
Page 18: Input Signal Wiring
I/O Wiring Right Angle Rotation Structure 电 Input Signal Wiring 气 特 Input signal wiring may differ by external device types, here we take LINE 0 as an example to introduce input signal wiring, and take LINE 3 as an example to introduce output signal wiring. 性... -
Page 19: Output Signal Wiring
I/O Wiring Output Signal Wiring 电 Output signal wiring may differ by external device types. 气 ● PNP Device 特 性 与 PNP Device Power Device Power 外部设备电源 设备电源 接 Opto-Isolated Output 线 Signal Line 光耦输出 信号线 Device Output Common Port PNP Power Ground 设备... -
Page 20: Rs-232 Serial Port
RS-232 Serial Port The device supports outputting via the RS-232 serial port.. You can go to the communication settings of the client software to set 电 related parameters. 气 RS-232 Serial Port Introduction 特 The 9-pin male connector and 25-pin male connector are commonly used serial ports, as shown below. You can refer to 性... -
Page 21: Troubleshooting
常 见 问 CHAPTER 5 题 Trouble Shooting Trouble: No device found when running the client Possible Reason1: The device is not powered on Solution1: Check whether the power connection of the device is normal (observe whether the top PWR light is solid green), and ensure that the device is powered on normally. -
Page 22: Technical Support
If you need advice about your camera or if you need assistance troubleshooting a problem with your camera, it’s highly recommended to describe your issue in details and contact us via E-mail at support@contrastech.com It would be helpful if you can fill-in the following table and send to us before you contact our technical support team.
