Installing M.2 SSDs (Optional)
What does installing an M.2 SSD do?
M.2 SSDs can be used as a normal storage drive or as a read/write cache to improve
reading and writing performance of random data.
1. After powering off, pull the tray out to reveal the M.2 slot, located on the inner left side of the device.
Pull back to release the buckle.
Release buckle
9
2. Insert M.2 SSD into the slot in the direction shown by the image below.
3. Gently press lifted end and fasten the buckle after SSD is firmly inserted.
Please peel off the film
of the silicone pad
Note: To ensure proper fit, the notch
should be aligned with the
corresponding ridge in the slot.
Fasten buckle
