QUICK GUIDE
2-IN-1 ATTACHABLE KEYBOARD, ET5X 10"
A. FEATURES
1. Top Latch Ridge
2. Cover
3. Pogo Pins
4. Rubber Keys
5. Touchpad
6. Mouse Buttons
7. Connector Adapter
8. Built-in Kickstand
9. Carry Handle
10. Hinge
11. USB 2.0 Input Port
12. Part Number Label
C. HOW TO DOCK & REMOVE THE TABLET
Remove the rubber seal on the tablet.
Snap in the Connector Adapter. The
tablet is now IP65 rated.
Thank you for choosing Gamber-Johnson for your keyboard needs. To learn more visit gamberjohnson.com and search part number 7160-1585.
© Copyright 2022 Gamber-Johnson LLC | INST-1020-00
RUGGED. RELIABLE. RESPONSIVE.
Position the tablet in the Rotate the tablet back into the
Cover onto the Pogo Pins. Cover, snap the Top Latch
Ridge over the top of the tablet.
TO DOCK
| Rev. B
B. IMPORTANT INFORMATION
1
• Compatible with the Zebra ET5X 10" tablets only
2
• Includes a Keyboard and Connector Adapter for the tablet
3
• Temperature Range:
4
• Operating -20°C to 50°C
5
6
• Storage -40°C to 85°C
7
• IP54, FCC, CE, RoHS, REACH, C-Tick compliant
8
• This product is NOT designed to be mounted in a vehicle
9
• Use the tablet's USB-C port to charge the tablet
10
11
• Connect a flash drive or other digital data device to the USB
2.0 port on the side of the keyboard
• Reference the Part Number Label for product information
12
regarding any service needs
On both sides, push up on Top Latch
Ridge and pull forward on the back
corner of the tablet.
TO REMOVE
GAMBERJOHNSON.COM
(Feature 11)
(Features 12)
Pull the Connector
Adapter out to use
other accessories.
