QUICK GUIDE
2-IN-1 ATTACHABLE KEYBOARD, TAB ACTIVE PRO
A. FEATURES
1. Top Latch Ridge
2. Cover
3. Hinge
4. Pogo Pins
5. Rubber Keys
6. Touchpad
7. Mouse Buttons
8. Built-in Kickstand
9. USB-C Power Port
10. USB 2.0 Input Port
11. Part Number Label
C. HOW TO DOCK & UNDOCK THE TABLET
Open the Cover
Thank you for choosing Gamber-Johnson for your keyboard needs. To learn more visit gamberjohnson.com and search part number 7160-1450.
© Copyright 2022 Gamber-Johnson LLC | INST-984-00
RUGGED. RELIABLE. RESPONSIVE.
Position the tablet in the Rotate the tablet back into
Cover onto the Pogo Pins the Cover, snap the Top Latch
Ridge over the top of the tablet
TO DOCK
| Rev. B
B. IMPORTANT INFORMATION
1
• Compatible with the Samsung Tab Active Pro only
2
• Temperature Range:
3
• Operating -20°C to 60°C
4
• Storage -40°C to 85°C
5
6
• IP54, FCC, CE, RoHS, REACH, C-Tick compliant
7
• This product is NOT designed to be vehicle mounted.
• Connect power cable to USB-C Power Port
8
• Connect a flash drive or other digital data device to the
USB 2.0 port on the side of the keyboard
9
10
• Reference the Part Number Label for product information
regarding any service needs
11
On both sides, push up on Top Latch Ridge &
pull forward on back corner of Tablet
GAMBERJOHNSON.COM
(Feature 9)
(Feature 10)
(Feature 11)
TO REMOVE
5001 Joerns Drive, Stevens Point, WI 54481
1.800.456.6868 | sales@gamberjohnson.com
