OBILE EADER CHASE READER & BASE GEN. 2 INSTALLATION GUIDE Product Description CHASE CARD READER GEN. 2 All-in-one mobile card reader...
Page 2
READER CHARGING BASE GEN.2 Countertop charging cradle...
Page 3
2 years. Caution: Do NOT attempt to open and disassemble the device to cause device tamper and violet the warranty. ■ CHASE READER Power spec: Input: 5V DC, 1A ■ READER CHARGING BASE Power spec:...
2. DEVICE OVERVIEW 2.1 CHASE READER_TOP & SIDE VIEW Fig. 1 Reader Description Touch Display & NFC area USB Type C Smart Card Reader Power Button...
Page 6
2.2 CHASE READER_BOTTOM VIEW Fig. 2 Bottom of the reader Description Battery Cover Charging Connector Secure Screw Nut Bottom Cover Removal Warning When removing the bottom cover for the purposes of changing battery, please remove the connector gently. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED...
Page 7
BATTERIES ACCORDING TO THE INSTRUCTIONS. Warning for internal battery pack To reduce risk of fire or burns: Do not attempt to open, disassemble, or service the battery pack. Charging the battery periodically to ensure the charge/discharge characteristics.
Fig. 6 Base holder plate USB-C Power Connector Base Holder Slot Secure Screw Power Cable Slot Base Holder Plate 3. HOW TO POWER ON THE READER Press the power key >3 seconds as shown on Figure 6 until hearing the beep sound and the display on.
Page 12
Tap your card onto the EMV contactless logo shown on display to do the transaction. The virtual LED on display shows the payment progress as shown below. Fig. 8 Tap...
4.2 SMART CARD READER Insert your credit card with the ICC chip upward into the card slot and push it to the end as shown below. Fig. 9 Chip 5. HOW TO LOCK READER TO THE BASE After placing the Reader onto the Base, turn over the full set to find the secure screw. Use one cent US dollar coin or screw drive to lock the device as shown below...
Page 14
Fig. 10 Locking Base 6. HOW TO LOCK/REMOVE THE BASE TO THE HOLDER Step#1: Peel off the adhesive tape overlay (shown as the grey area below) from the bottom of Base Holder Plate, and place the mounting kit on a clean table surface where it wanted to be installed.
Page 15
Fig. 11 Anchoring Base holder plate Step#2: Align the Base holder and anchor positioning pin. Then put the Charging Base above the Base Holder Plate as shown below. Note: The FRONT refers to the LED light guide of Charging Base for customer facing. Fig.
Page 16
Step#3: Push the Charging Base from the front side to fix it with the Base Holder. Pull it back to remove the Base from the desktop as shown below. Lock Release Fig. 13 Locking and unlocking Base...
Page 17
Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
