V2.2.VISION.12.06.23
H A L O V I S I O N
U S E R M A N U A L
Need Help? +44 (0)330 320 3030
RoadAngelGroup.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HALO VISION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Road Angel HALO VISION

  • Page 1 V2.2.VISION.12.06.23 H A L O V I S I O N U S E R M A N U A L Need Help? +44 (0)330 320 3030 RoadAngelGroup.com...
  • Page 2 What’s in the box Rear Cam Dash Cam USB Power Adapter Power Cable Trim Tool Mounting Bands Front to Rear Cable Quick Start Guide...
  • Page 3 Configeration & Button Instructions SD Card Power Port Buckle Rear Camera Port Lens Power Button Microphone Reset It is of paramount importance that the Type C USB Power cable is inserted into the Halo Pro the correct way around. Failure to do so will result in damage to the unit which is not covered by the manufacturers warranty.
  • Page 4: Download The App

    Download the app https://l.ead.me/bcpE4P Download the Road Angel App from the Google Playstore or Apple Appstore using the above QR code. Alternatively navigate to your preferred Appstore and search for Road Angel Halo. You need to download the Road Angel App to use the Dash Camera.
  • Page 5: Getting Started

    Getting Started Buckles 1. Attach the Dash Cam onto the original rearview mirror using the rubber buckles provided. 2. Once the Dash Cam is firmly fitted, adjust the camera angle to the required position. 3. Connect the Dash Cam to the vehicles 12V power socket and feed the cable as shown using the Trim Tool provided.
  • Page 6 Getting Started 4. Connect the rear camera link cable to the Dash Cam as shown using the Trim Tool provided. 5. Turn on the engine after installation to ensure the Dash Cam powers up and starts recording. After power up, tap the screen to access the main menu. Album Page Swipe right to access playback video, emergency files &...
  • Page 7 Wi-Fi Setup Launch the App. Press the ‘+’ icon in the top right corner. Then follow the instructions that will be shown in the App on how to connect the device via Wi-Fi. Once connected successfully you may return to the Halo App.
  • Page 8: Live Preview

    Live Preview To preview the dash camera currently recording footage, select the ‘Camera’ tab at the bottom of the screen and press the play icon. This will display a real time view of the live dash camera footage. Below the live footage preview is an area that will show you come basic GPS informartion relating to your speed and mileage;...
  • Page 9 Live Preview This shows data such as; ‘Current speed’, ‘Average speed’, ‘Max speed’, ‘Current elevation’, Compass/ Direction and ‘Driving mileage’. Pressing the tab on the right of the You can switch back to the live map map display will open the live data display at any time by pressing the display.
  • Page 10 Live Preview Enter the albums tab to view images, downloaded videos and events. Events are moments stored when the camera detects an impact from its G-Axis Sensors. Select the image or video to view the file. Here you can save, delete or edit the file, saving the file saves it into your phone’s media gallery outside of the app.
  • Page 11: Photo Editing

    Photo Editing After you have selected the photo from the Album page you have several options. Top right button saves photos to the phone’s photo album. Bottom left magic wand opens the photo editing mode. Middle trash can deletes the photo and bottom right allows you to share the photo.
  • Page 12 Photo Editing The photo editing screen allows you to add text captions, video frames, contrast settings and choose from 17 photo filters. When you are finished simply save your file.
  • Page 13: Video Editing

    Video Editing After you have selected a video from the Album page you have several options. The bottom controls change playback options. The top right buttons allow you to share the video and open the side menu. From the side menu you can delete the video, ‘Save’...
  • Page 14 Video Editing The video editing screen lets you crop the length of the selected video and choose video quality. Once done press the ‘Next’ button at the bottom to continue. Telematic data is shown on compatible models only...
  • Page 15: Video Playback

    Video Playback To playback footage, slide the scroll bar which will show you a thumbnail of the moment about to be viewed along with the date and time.
  • Page 16 Video Playback You can rotate your phone to enhace the experince and see more options. You will also be able to download footage. You can also view Live preview, photo viewing or video viewing here.
  • Page 17 Download Footage When in the Landscape video playback mode, select the download icon on the right of the screen which will take you to the download screen. To create a clip of what has been recorded, slide the viewing bar to the left to scroll backwards in time and to the left to go forwards.
  • Page 18 Download Footage When you are happy with the length of the video clip, press ‘complete download’. While downloading, you may not have connection to the internet. The screen will now show you a thumbnail of the downloaded video clip, giving you the option to ‘share’...
  • Page 19: Camera Settings

    Camera Settings When connected to the camera, press the Settings icon (’Me’) in the bottom right to access the general settings of the dash cam.
  • Page 20: Advanced Camera Settings

    Advanced Camera Settings...
  • Page 21: Parking Mode

    Parking Mode The Halo Pro’s parking mode records video footage even when your vehicle is parked. The parking mode feature has several settings that can be changed. these will be different depending on the vehicles ignition state. Dormant - This turns the Time-lapse –...
  • Page 22 (2) increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. Road Angel Group, DB House, Rani Drive, Nottingham NG5 1RF roadangelgroup.co.uk...
  • Page 23: Need Help

    Need Help? Support page Youtube channel https://www.roadangelgroup.com/pages/support https://www.roadangelgroup.com/pages/support...
  • Page 24 UK’s Most Trusted Road Safety Assistant RoadAngelGroup.com...
