Current Daintree WSA10 Installation Manual

WSA10
Wireless Sensor Adapter
Installat on Instruct ons
The Daintree Networks WSA10 Wireless Sensor Adapter is a
control component within ControlScope™. The WSA10 enables
open, s
with a variety of sensor devices used in HVAC systems.
The WSA10 provides up to four (4) thermistor temperature
sensor inputs for temperature monitoring and logging, and up to
range of transducers, enabling wireless control and management
of wired end-devices within the ControlScope system.
Ba W
temperature logging in the event of a power failure.
Input voltage 24VAC/VDC (10mA)
Type: AA 3.6V lithium thionyl chloride,
internal, not replaceable
7 years or more
Min. 5,000 hours (@25°C op. temp),
Data logging capacity 14 days; 5 minute sampling intervals,
Thermistor inputs only
Inputs
Resistance: (4) Thermistor, 10K Type 2
Accuracy: +/- 0.5°C @-10°C to 45°C (14°F to 113°F )
+/- 1°C @-30°C to 65°C (-22°F to 149°F)
Voltage: (2) 0-10VDC
Accuracy:
2.4 GHz, +8 dBm, Range dependent on
environment non-condensing
Temperature: 32° to 122°F (0° to 50°C)
Compliance US: FCC Part 15
Canada: IC
Wall, ceiling, enclosure screw mount
Dimensions 1.18" W x 0.98" H x 7.03" L
(30
mm
ControlScope Release version 3.1 or later
W x 25 H x 178.5 L)
mm mm
LED.com
© 2024 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Installation Process
1. Disconnect power to the 24V power supply before
installation. Confirm that power is off before continuing.
2. IMPORTANT: Use the provided Plan label to identify the
wireless-adapted sensor location on the building's floorplan.
3. Mount the WSA10 on a flat surface in the HVAC packaged unit,
or in the facility's electrical/mechanical room. See Mounting.
4. Connect low voltage wiring between the WSA10 and the
power supply and sensors as appropriate. Connect the sensor
cable shield drain wire as appropriate. Improper connection of
the shield drain may cause incorrect or unstable sensor
readings. See Wiring.
5. Check wiring then restore power to the power supply.
6. Ensure the WSA10 green Power
7. Press and hold the Reset button on the WSA10 for 3 seconds
to reset the unit. Release the button when the green Joined
LED and the red Error
IMPORTANT
Fig. 1: LED indicators
Error/Reset—On when the Wireless Adapter is in an error
state. Flashes to indicate unit Reset (red).
Joined—On when
the Wireless
Adapter has joined
a ZigBee® network.
Flashes to
indicate Reset
(green).
Power—On when
power is applied
to the Wireless
Adapter (green).
DT-WSA10
Installation Guide
LED is On.
RESET
x
WSA10 130805
Page 1 of 5
Rev 06/01/24
DT-WSA10-InsallationGuide
