EVBOLT ASTEROPE 12 User Manual

Electric vehicle dc charger
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electric Vehicle DC Charger
ASTEROPE 12 – User Manual
EVB-DC-PS120
ASTEROPE
12
Intellectual property of EVBOLT, Inc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASTEROPE 12 and is the answer not in the manual?

Questions and answers

Related Manuals for EVBOLT ASTEROPE 12

Summary of Contents for EVBOLT ASTEROPE 12

  • Page 1 Electric Vehicle DC Charger ASTEROPE 12 – User Manual EVB-DC-PS120 ASTEROPE Intellectual property of EVBOLT, Inc...

  • Page 2: Table Of Contents

    EVSE Check – Emergency stop check ......................21 6.6.6 Operation Process ................................. 22 Operating Sequence .............................. 22 Operating Procedure (ONLINE) ........................... 22 EVBOLT iOS/Android Application ......................22 7.2.1 EVBOLT WebApp ............................22 7.2.2 Operating Procedure (OFFLINE) ......................... 23 Intellectual property of EVBOLT, Inc...
  • Page 3 7.3.6 Status Message .............................. 27 7.3.7 Troubleshooting ..............................28 Status Codes ................................28 Maintenance .................................. 49 General Maintenance ............................49 Replacement Kits and Accessories ........................52 Limited Product Warranty ............................53 Packing List ................................54 Intellectual property of EVBOLT, Inc...

  • Page 4: Introduction

    Applications • Public and Private Parking Areas • Community Parking Areas • Parking Areas of Hotels, Supermarkets and shopping malls • Workplace Parking Areas • Charging Stations • Highway Rest Areas Intellectual property of EVBOLT, Inc Page 1 of 54...

  • Page 5: User Interface

    Antenna for Wi-Fi & 3G/4G LED Indication 7" Information Screen Charging Status • Alarm information • User Authorization • Right Button & Left Button RFID Card Reader Emergency Stop Left DC Connector Right DC Connector Intellectual property of EVBOLT, Inc Page 2 of 54...

  • Page 6: Specifications

    Ethernet, Wi-Fi and 3G or 4G LAN: support 10/10, 100/100 base Wi-Fi: support 2.4G DLWPH-8M: 4G Frequency Band: LTE FDD: B2/B4/B5/B12/B13/B14/B66/B71 3G Frequency Band: WCDMA: B2/B4/B5 Internal CAN Bus / RS485 Intellectual property of EVBOLT, Inc Page 3 of 54...
  • Page 7 < 1124 lbs. (510 kg), includes two charging guns DC Charging Connector CCS1 Mechanical Specifications Cooling Fan cooling Ingression Protection IP55 NEMA 3R Anti-vandalism IK10, not include LCD & RFID cover Intellectual property of EVBOLT, Inc Page 4 of 54...

  • Page 8: Led Indication And Operation Status

    LED Indication and Operation Status *Left LED for Left Connector, Right LED for Right Connector Standby Fault Charging LED Status Left Indicator Right Indicator Standby Green Green Fault Charging Blue Blue Intellectual property of EVBOLT, Inc Page 5 of 54...

  • Page 9: Dimensions

    Dimensions 32" 26" Direction of cooling Airflow Air In Air Out Intellectual property of EVBOLT, Inc Page 6 of 54...

  • Page 10: Installation Instructions

    • The product should be installed in free air area and keep at least 30cm (12 inches) clearance distance to all air vent of the product. • Recommend to keep not less than 107cm (42 in.) clearance distance from all around the product following NEC table 110.26 condition 2, 151-600V. Intellectual property of EVBOLT, Inc Page 7 of 54...

  • Page 11: Grounding And Safety Requirement

    National Electric Code, ANSI/NFPA 70. CAUTION: A cord extension set or second cable assembly shall not be used in addition to the cable assembly for connection of the EV to the EVSE. Intellectual property of EVBOLT, Inc Page 8 of 54...

  • Page 12: Service Wiring

    L2 or L3, and Neutral. Earth ground must be connected to neutral at only one point, usually at the breaker panel. 277V 277V Neutral 480V 277V 480V Three-Phase Wiring Connection DANGERS Be Aware of High Voltage! WARNING! Earth Connection is Essential! Intellectual property of EVBOLT, Inc Page 9 of 54...

  • Page 13: Unpack The Charger

    • Contact the supplier by mail or phone to address your findings. WARNING! Charger weight might be 1124 lbs. (510 kg). Charger with package might be 1322 lbs. (600 kg). Be careful during unpack process. Intellectual property of EVBOLT, Inc Page 10 of 54...
  • Page 14 STEP 1 Remove the surrounding boards STEP 2 Remove the carton and packing cushion and film Intellectual property of EVBOLT, Inc Page 11 of 54...
  • Page 15 Remove these 6 pcs of fixing M12 screws. STEP 4 To use lifting eye bolts to move the EVSE, please apply 6mm (1/4 inches) diameter steel wire rope to the four eye bolts as following picture. Intellectual property of EVBOLT, Inc Page 12 of 54...

  • Page 16: Recommended Tools For Installation And Inspection

    Multiple Meter 1000V Current Probe 400Amp RFID Authorized Card RFID No Valid Card Door Key Needle-Nose Plier Laptop or PC & CAT6 cable For Charger Configuration Wi-Fi /4G signal quality checker Recommended Intellectual property of EVBOLT, Inc Page 13 of 54...

  • Page 17: Installation Procedure

    (Φ0.63” (16 mm)) on the cement base as drawing below. AC Cable at least 500mm(19.69 inch) L Brscket Orifice Ethernet Cable at least 1800mm(71 inch) L Bracket Orifice 4XM12 Screw stick Intellectual property of EVBOLT, Inc Page 14 of 54...
  • Page 18 • The conductor cross sectional area of input power wires should be not less than 95mm² (212 kcmil). If internet is connected via Ethernet, at least 71” (1800mm) of the Ethernet cable must be exposed from the conduit. Intellectual property of EVBOLT, Inc Page 15 of 54...

  • Page 19: Two Methods Of Fixing The Charger

    Then fix the base cover (in the accessory pack) in charger base. METHOD 2 If use L-brackets to fix charger, secure L-brackets on the cement base by 6 pcs of M12 expansion bolts. Intellectual property of EVBOLT, Inc Page 16 of 54...

  • Page 20: Installing Cable

    180Kgf.cm/5-15 secs. Connect the PE wire (green with yellow) to grounding position of charger and torque number - 220Kgf.cm. Keep proper length of each wire then fasten cable grand. L1 L2 L3 Intellectual property of EVBOLT, Inc Page 17 of 54...
  • Page 21 Use adaptive flame retardants and electrical insulated foaming agent and far from conductive live parts at least 12mm or other method to seal the cable entry hole to assure the IP55 grade of the charger, and prevent insects enter the cabinet. Intellectual property of EVBOLT, Inc Page 18 of 54...

  • Page 22: Installation Inspection & Commissioning

    Current rating of NFB shall be higher than 300 Amp Input Electricity Capacity Input Electricity Configuration < 10 Ω Grounding Resistance Grounding System Input Voltage & Frequency Network Connection & Quality Wi-Fi, 4G > -65dBm Intellectual property of EVBOLT, Inc Page 19 of 54...

  • Page 23: Evse Check - Static (Non-Powered)

    Network Connection Quality Cooling Fans Operation & Noise Led Status Indication EVSE Setting Function of Engineer Mode Version of H.W. & F.W. Remote Control & Monitoring Backend Server Connection Wi-Fi, 4G > -65dBm Intellectual property of EVBOLT, Inc Page 20 of 54...

  • Page 24: Evse Check - Charging

    Reading of Engineer Mode Airflow & Noise of Cooling Fan Charging Record (log) Upload Remote Control & Monitoring 6.6.6 EVSE Check – Emergency stop check Item Status Remark Emergency stop & Recovery Intellectual property of EVBOLT, Inc Page 21 of 54...

  • Page 25: Operation Process

    Operating Procedure (ONLINE) For commercial purposes, this product can be connected to internet via Wi-Fi or 4G LTE. This is the case for Public and Semi-Public chargers. The chargers can be accessed using EVBOLT Application or WebApp. 7.2.1 EVBOLT iOS/Android Application...

  • Page 26: Operating Procedure (Offline)

    Unit and currency if billing function is enabled • Ethernet Backend Status Connection Dis-Connection • Wi-Fi Status Connection Dis-Connection • 3G/4G Status Connection Dis-Connection • OCPP Backend Status Home page Connection Dis-Connection Intellectual property of EVBOLT, Inc Page 23 of 54...

  • Page 27: User Authorization

    User authorization Method: RFID, QR code and mobile APP. • Unauthorized method(s) will be darker on the screen if the method is disable. Home page User authorizing User authorized. Authorization failed Intellectual property of EVBOLT, Inc Page 24 of 54...

  • Page 28: Plug In Charging Connector

    Preparing page as below illustrated. Information of Selected Charging Connector Connector Select Button Press right button to select the charger connector that the user would like to use. Preparing page Intellectual property of EVBOLT, Inc Page 25 of 54...

  • Page 29: In Charging

    Press right button to select the charger connector that the user would like to stop. • User also can tap the RFID to stop charging. Tap RFID card or push stop button to stop Intellectual property of EVBOLT, Inc Page 26 of 54...

  • Page 30: Charging Terminated

    • When problems occur with this charger or the charging process a status code will display on screen as below illustrated. Please follow the troubleshooting table to solve the problem. Status Code Intellectual property of EVBOLT, Inc Page 27 of 54...

  • Page 31: Troubleshooting

    GB output relay driving fault 011017 AC connector temperature sensor broken 011018 CHAdeMO connector temperature sensor broken 011019 CCS connector temperature sensor broken 011020 GB connector temperature sensor broken 011021 Wi-Fi module broken Intellectual property of EVBOLT, Inc Page 28 of 54...
  • Page 32 System L3 input UVP 012206 PSU L1 input OVP 012207 PSU L2 input OVP 012208 PSU L3 input OVP 012209 PSU L1 input UVP 012210 PSU L2 input UVP 012211 PSU L3 input UVP Intellectual property of EVBOLT, Inc Page 29 of 54...
  • Page 33 012236 GB GFD trip 012237 SPD trip 012238 Main power breaker trip 012239 Aux. power breaker trip 012240 PSU communication fail 012241 Wi-Fi module communication fail 012242 3G/4G module communication fail Intellectual property of EVBOLT, Inc Page 30 of 54...
  • Page 34 012268 PSU Protection Alarm 012269 PSU Fan Failure Alarm 012270 PSU Input UVP 012271 PSU Input OVP 012272 PSU Walk in State 012273 PSU Power Limited State 012274 PSU Id Repeat Intellectual property of EVBOLT, Inc Page 31 of 54...
  • Page 35 System AC L3 output OCP 012301 System AC L2 output Circuit Short 012302 System AC L3 output Circuit Short 012303 CCS liquid chiller water level warning 012304 Disconnected from power cabinet 012305 Meter communication timeout Intellectual property of EVBOLT, Inc Page 32 of 54...
  • Page 36 Normal stop charging by user 013601 Charging Time's up 013602 Replace system air filter 013603 Reach to CHAdeMO max. plugging times 013604 Reach to CCS max. plugging times 013605 Reach to GB max. plugging times Intellectual property of EVBOLT, Inc Page 33 of 54...
  • Page 37 4G disabled (separated charger only) 013629 Reserved 013630 Reserved 013631 Reserved 023700 CHAdeMO EV communication Fail 023701 CCS EV communication Fail 023702 GB EV communication Fail 023703 AC: pilot fault 023704 CHAdeMO: battery malfunction Intellectual property of EVBOLT, Inc Page 34 of 54...
  • Page 38 CHAdeMO: isolation result fail 023732 CHAdeMO: mother board miss link 023733 CHAdeMO: output voltage more than limit 023734 CHAdeMO: req current more than limit 023735 CHAdeMO: re capability BMS eqr current exceed Intellectual property of EVBOLT, Inc Page 35 of 54...
  • Page 39 023752 CCS_EVCC_EVErrorCode_FAILED_reserved_by_ISO_3 023753 CCS_EVCC_EVErrorCode_FAILED_reserved_by_OEM_1 023754 CCS_EVCC_EVErrorCode_FAILED_reserved_by_OEM_2 023755 CCS_EVCC_EVErrorCode_FAILED_reserved_by_OEM_3 023756 CCS_EVCC_EVErrorCode_FAILED_reserved_by_OEM_4 023757 CCS_EVCC_EVErrorCode_FAILED_reserved_by_OEM_5 023758 CCS_SECC_ResponseCode_FAILED_SequenceError 023759 CCS_SECC_ResponseCode_FAILED_SignatureError 023760 CCS_SECC_ResponseCode_FAILED_UnknownSession 023761 CCS_SECC_ResponseCode_FAILED_ServiceIDInvalid 023762 CCS_SECC_ResponseCode_FAILED_Payment SelectionInvalid 023763 CCS_SECC_ResponseCode_FAILED_IdentificationSelectionInvalid 023764 CCS_SECC_ResponseCode_FAILED_ServiceSelectionInvalid 023765 CCS_SECC_ResponseCode_FAILED_CertificateExpired 023766 CCS_SECC_ResponseCode_FAILED_CertificateNotYetValid Intellectual property of EVBOLT, Inc Page 36 of 54...
  • Page 40 CCS_SECC_ResponseCode_FAILED_ContactorError 023783 CCS_SECC_ResponseCode_FAILED_CertificateNotAllowedAtThisEVSE 023784 CCS_SECC_ResponseCode_FAILED_GAChargeStop 023785 CCS_SECC_ResponseCode_FAILED_AlignmentError 023786 CCS_SECC_ResponseCode_FAILED_ACDError 023787 CCS_SECC_ResponseCode_FAILED_AssociationError 023788 CCS_SECC_ResponseCode_FAILED_EVSEChargeAbort 023789 CCS_SECC_ResponseCode_FAILED_NoSupportedApp-Protocol 023790 CCS_SECC_ResponseCode_FAILED_ContractNotAccepted 023791 CCS_SECC_ResponseCode_FAILED_MOUnknown 023792 CCS_SECC_ResponseCode_FAILED_OEM_Prov_CertificateRevoke 023793 CCS_SECC_ResponseCode_FAILED_OEM_SubCA1_CertificateRevoked 023794 CCS_SECC_ResponseCode_FAILED_OEM_SubCA2_CertificateRevoked 023795 CCS_SECC_ResponseCode_FAILED_OEM_RootCA_CertificateRevoked 023796 CCS_SECC_ResponseCode_FAILED_MO_Prov_CertificateRevoked 023797 CCS_SECC_ResponseCode_FAILED_MO_SubCA1_CertificateRevoked Intellectual property of EVBOLT, Inc Page 37 of 54...
  • Page 41 CCS_SECC_TIMEOUT_SLAC_TP_EVSE_avg_atten_calc 023814 CCS_SECC_TIMEOUT_SLAC_CM_ATTEN_CHAR_RSP 023815 CCS_SECC_TIMEOUT_SLAC_CM_VALIDATE_REQ_1ST__CM_SLAC_MATCH_REQ 023816 CCS_SECC_TIMEOUT_SLAC_TT_EVSE_assoc_session 023817 CCS_SECC_TIMEOUT_SLAC_TT_EVSE_vald_toggle 023818 CCS_SECC_TIMEOUT_SLAC_CM_MNBC_SOUND_IND 023819 CCS_SECC_TIMEOUT_SLAC_CM_VALIDATE_REQ_2ND__CM_SLAC_MATCH_REQ 023820 CCS_SECC_TIMEOUT_SLAC_reserved_3 023821 CCS_SECC_TIMEOUT_SLAC_reserved_4 023822 CCS_SECC_TIMEOUT_SLAC_reserved_5 023823 CCS_SECC_TIMEOUT_SLACC_SDP_UDP_TT_match_join 023824 CCS_SECC_TIMEOUT_SLACC_SDP_TCP_TT_match_join 023825 CCS_SECC_TIMEOUT_SLACC_SDP_TP_amp_map_exchange 023826 CCS_SECC_TIMEOUT_SLACC_SDP_TP_link_ready_notification 023827 CCS_SECC_TIMEOUT_SLACC_SDP_reserved_1 023828 CCS_SECC_TIMEOUT_SLACC_SDP_reserved_2 Intellectual property of EVBOLT, Inc Page 38 of 54...
  • Page 42 CCS_SECC_TIMEOUT_V2G_Sequence_Time 023845 CCS_SECC_TIMEOUT_V2G_ReadyToCharge_Performance_Time 023846 CCS_SECC_TIMEOUT_V2G_CommunicationSetup_Performance_Time 023847 CCS_SECC_TIMEOUT_V2G_CableCheck_Performance_Time 023848 CCS_SECC_TIMEOUT_V2G_CPState_Detection_Time 023849 CCS_SECC_TIMEOUT_V2G_CPOscillator_Retain_Time 023850 CCS_SECC_TIMEOUT_V2G_PreCharge_Performace_Time 023851 CCS_SECC_TIMEOUT_V2G_reserved_2 023852 CCS_SECC_TIMEOUT_V2G_reserved_3 023853 CCS_SECC_TIMEOUT_V2G_reserved_4 023854 CCS_SECC_TIMEOUT_V2G_reserved_5 023855 CCS_CAN_TIMEOUT_TP_GET_EV_TARGET_INFO 023856 CCS_CAN_TIMEOUT_TT_GET_EV_TARGET_INFO 023857 CCS_CAN_TIMEOUT_TP_GET_EV_BATTERY_INFO 023858 CCS_CAN_TIMEOUT_TT_GET_EV_BATTERY_INFO 023859 CCS_CAN_TIMEOUT_TP_EV_STOP_EVENT Intellectual property of EVBOLT, Inc Page 39 of 54...
  • Page 43 CCS_CAN_TIMEOUT_TP_CONNECTOR_INFO 023876 CCS_CAN_TIMEOUT_TT_CONNECTOR_INFO 023877 CCS_CAN_TIMEOUT_TT_RTC_INFO 023878 CCS_CAN_TIMEOUT_TP_RTC_INFO 023879 CCS_CAN_TIMEOUT_TP_EVSE_PRECHARGE_INFO 023880 CCS_CAN_TIMEOUT_TT_EVSE_PRECHARGE_INFO 023881 CCS_CAN_TIMEOUT_MSG_Sequence 023882 CCS_CAN_MSG_Unrecognized_CMD_ID 023883 CCS_SECC_DIN_Msg_Decode_Error 023884 CCS_SECC_DIN_Msg_Encode_Error 023885 CCS_SECC_ISO1_Msg_Decode_Error 023886 CCS_SECC_ISO1_Msg_Encode_Error 023887 CCS_SECC_ISO2_Msg_Decode_Error 023888 CCS_SECC_ISO2_Msg_Encode_Error 023889 CCS_SECC_CP_State_Error 023890 CCS_SECC_Unexpected_60V_Before_Charing_Error Intellectual property of EVBOLT, Inc Page 40 of 54...
  • Page 44 GBT_BMS_PRESENT_VOLTAGE_FAULT 023906 GBT_BMS_VOLTAGE_OVER_RANGE 023907 GBT_BSM_CHARGE_ALLOW_00_10MIN_COUUNTDONE 023908 GBT_WAIT_GROUNDFAULT_TIMEOUT 023909 GBT_ADC_MORE_THAN_10V 023910 GBT_ADC_MORE_THAN_60V 023911 GBT_CHARGER_GET_NORMAL_STOP_CMD 023912 GBT_CHARGER_GET_EMERGENCY_STOP_CMD 023913 GBT_ISOLATION_RESULT_FAIL 023914 GBT_MOTHER_BOARD_MISS_LINK 023915 GBT_OUTPUT_VOLTAGE_MORE_THAN_LIMIT 023916 GBT_REQ_CURRENT_MORE_THAN_LIMIT 023917 GBT_OUTPUT_VOLTAGE_MORE_THAN_10_PERCENT 023918 GBT_OUTPUT_VOLTAGE_DIFF_BCS_5_PERCENT 023919 GBT_STOP_ADC_MORE_THAN_10V 023920 Reserved Intellectual property of EVBOLT, Inc Page 41 of 54...
  • Page 45 GBT_CEM_BSM_TIMEOUT 023937 GBT_CEM_BST_TIMEOUT 023938 GBT_CEM_BSD_TIMEOUT 023939 GBT_CEM_BEM_OTHER_TIMEOUT 023940 GBT_BEM_CRM_TIMEOUT 023941 GBT_BEM_CRMAA_TIMEOUT 023942 GBT_BEM_CTS_CML_TIMEOUT 023943 GBT_BEM_CRO_TIMEOUT 023944 GBT_BEM_CCS_TIMEOUT 023945 GBT_BEM_CST_TIMEOUT 023946 GBT_BEM_CSD_TIMEOUT 023947 GBT_BEM_BEM_OTHER_TIMEOUT 023948 Reserved 023949 Reserved 023950 GBT_BST_SOC_GOAL 023951 GBT_BST_TOTAL_VOLTAGE_GOAL Intellectual property of EVBOLT, Inc Page 42 of 54...
  • Page 46 023968 Reserved 023969 Reserved 023970 GBT_BSM_CELL_OVER_VOLTAGE 023971 GBT_BSM_CELL_UNDER_VOLTAGE 023972 GBT_BSM_OVER_SOC 023973 GBT_BSM_UNDER_SOC 023974 GBT_BSM_CURRENT 023975 GBT_BSM_TEMPERATURE 023976 GBT_BSM_ISOLATE 023977 GBT_BSM_OUTPUT_CONNECTOR 023978 023979 EV full charging 023980 ERROR_CODE_CHADEMO_BMS_CHARGE_ALLOW_ERROR 023981 ERROR_CODE_CHADEMO_OUTPUT_VOLTAGE_MORE_THAN_10_PERCENT 023982 ERROR_CODE_CHADEMO_ADC_LESS_THAN_10V Intellectual property of EVBOLT, Inc Page 43 of 54...
  • Page 47 041034 Shutter fault 041035 Ble module broken 041036 Rotary switch fault 042200 System L1 input OVP 042201 System L2 input OVP 042202 System L3 input OVP 042203 System L1 input UVP Intellectual property of EVBOLT, Inc Page 44 of 54...
  • Page 48 3G/4G module communication fail 042244 Bluetooth module communication fail 042246 Aux. power module communication fail 042247 Relay control board/smart box communication fail 042251 Emergency stop 042252 Door open 042253 System fan decay Intellectual property of EVBOLT, Inc Page 45 of 54...
  • Page 49 Self-test Failed due to AC Contact failure 042286 Self-test Failed due to communication of PSU failure 042287 Self-test Failed due to Model name is none match 042291 Self-test Failed due to communication of GBT board failure Intellectual property of EVBOLT, Inc Page 46 of 54...
  • Page 50 System task is lost 042327 DC input OVP 042328 DC input UVP 043600 Normal stop charging by user 043601 Charging Time's up 043602 Replace system air filter 043607 CSU firmware update fail Intellectual property of EVBOLT, Inc Page 47 of 54...
  • Page 51 Internet through Wi-Fi 043624 disconnected from Internet through 3G/4G 043625 disconnected from AP through Wi-Fi 043626 disconnected from APN through 3G/4G 043627 Wi-Fi disabled (separated charger only) 043628 4G disabled (separated charger only) Intellectual property of EVBOLT, Inc Page 48 of 54...

  • Page 52: Maintenance

    WARNING: Danger of electrical shock or injury. Turn OFF power at the panelboard or load center before working on the equipment or removing any component. Do not remove circuit protective devices or any other component until the power is turned OFF. Intellectual property of EVBOLT, Inc Page 49 of 54...
  • Page 53 • Please provide the EVSE information including serial number, model name, status code, failure behavior and timing, and also connect the EVSE to the Internet before remote diagnostics and upgrading Intellectual property of EVBOLT, Inc Page 50 of 54...
  • Page 54 Hex cap 119~158 137~182 13.43~17.85 110~145 10.77~14.21 3/8-16 Hex cap 205~274 237~316 23.24~30.99 190~253 18.63~24.82 7/16-14 Hex cap 338~451 390~521 38.24~51.09 312~416 30.59~40.79 1/2-13 Hex cap 515~686 595~792 58.35~77.66 476~634 46.68~62.17 Intellectual property of EVBOLT, Inc Page 51 of 54...

  • Page 55: Replacement Kits And Accessories

    Control & Supervisory Unit (CSU3.0) Surge Protection Device (SPD) DC Fan Air Filters Door Key Gland(M50) User Manual Relay board Fan board LED board 4G/Wi-Fi board DC Relay AC Contactor NFB & RCD Intellectual property of EVBOLT, Inc Page 52 of 54...

  • Page 56: Limited Product Warranty

    In order to receive the remedy, set for above, you must contact Supplier during the warranty period and provide the model number, series number, proof of purchase, and date of purchase. This warranty does not cover the damages caused by adapter usage accident or by other unauthorized operation/service. Intellectual property of EVBOLT, Inc Page 53 of 54...

  • Page 57: Packing List

    Item Description Remark EVSE User Manual EVSE Approved Certificate OQC Report RFID Card Door Key M4x8 Screw Base Cover Cable Management Optional Bracket set for payment system Optional M5x12 Screw Optional Intellectual property of EVBOLT, Inc Page 54 of 54...
  • Page 58 © 2022 EVBOLT INC. All Rights Reserved. Intellectual property of EVBOLT, Inc...
