- Page 1 INSTALLATION MANUAL...
-
Page 2: Installation Instructions
HARDWARE AND TOOLS ( Tools not included) Power Drill Mallet Tape Measure Safety Goggles Drill Bits Pencil Level HARDWARE LISTS ITEM IMAGE NAME Mounting Screw Wall Anchor Shelf Support Shelf INSTALLATIONINSTRUCTIONS Please read carefully and save these instructions. Don't discard any of the packaging until you are sure that you have all of the parts and the fitings. IMPORTANT 1. - Page 3 SURFACE MOUNT INSTRUCTION Step 1 Step 2 Measure and mark the back mounting holes on the wall. Draw horizontal line connecting the marked location. Unpack the metal cabinet and prepare The line should be level. tools needed. Adjust to level if necessary. Step 3 Drill holes,and put in the plastic expansion bolt.
- Page 4 Step 4 Attach the cabinet to the wall with mountin screws from the hardware pack. THE CABINET CAN BE FLIPPED FOR REVERSE INSTALLATION AND THE DOOR COULD OPEN EITHER LEFT OR RIGHT SIDE. 1: Determine the appropriate shelf location; Step 5 2: Insert the shelf support into both sides of the cabinet;...
- Page 5 16 in.(W) x 24 in.(H) x 5 in.(D) 13-7/8 in.(W) x 18 in.(H) x 3-1/2 in.(D) 20 in.(W) x 28 in.(H) x 5 in.(D) 17-5/8 in.(W) x 22 in.(H) x 3-1/2 in.(D) 24 in.(W) x 30 in.(H) x 5 in.(D) 21-7/8 in.(W) x 24 in.(H) x 3-1/2 in.(D) Step 1...
- Page 6 Step 2 Wall Opening THE CABINET CAN BE FLIPPED FOR REVERSE INSTALLATION AND THE DOOR COULD OPEN EITHER LEFT OR RIGHT SIDE. Step 3 1: Determine the appropriate shelf location; 2: Insert the shelf support into both sides of the cabinet; 3: Attach the shelf onto the shelf support .
- Page 7 SKU# A - Width Metal01-1624 B - Height C - Depth Metal02-2028 Metal03-2430 Unit: Inch Note: All dimensions & specifications are approximate and subject to change without notice. Customer Service: For any questions or queries regarding our products, please contact our support team：...
