Summary of Contents for Morel IR-MBZ42
- Page 1 Installation Guide Mercedes Benz IR-MBZ42 IR-MBZ42-CTR IR-MBZ4INT IR-MBZ4INT-CTR MBZSUB82-1L MBZSUB82-2L...
- Page 2 Thank you for choosing Morel for your car audio speaker solution. Morel prides itself on engineering and producing the best high-fidelity speaker systems. We hope you enjoy your Integration Reference speakers for years to come. If you have any questions, please contact your Morel dealer or Morel support at: www.morelhifi.com...
- Page 3 Components Component System MBZSUB82-1L Midwoofer Cable Splitter Midwoofer Tweeter Connecting Cable MBZ002 MBZ003 MBZ004 (optional) (optional) (optional) Integra System MBZSUB82-2L Integra Coax Connecting Cable MBZ002 MBZ003 MBZ004 (optional) (optional) (optional)
- Page 4 Component Woofer and Coax Adapter Assembly Assembly Overview Configuration A Configuration B CLICK MBZ003 MBZ002 Configuration C Scan for vehicle-specific compatibility information MBZ004...
-
Page 5: Speaker Connection
Speaker Connection IR-MBZ42 / IR-MBZ42-CTR Component System Tweeter IN Cable Splitter Factory Wire Connector Connecting Cable Midwoofer IN IR-MBZ4INT / IR-MBZ4INT-CTR Integra System Factory Wire Connecting Connector Cable Integra IN... -
Page 6: Speaker Installation
Speaker Installation 4" Configuration A 4" Configuration B Tweeter CLICK... -
Page 7: Subwoofer Installation
Subwoofer Installation MBZSUB82-1L MBZSUB82-2L... -
Page 8: Specifications
CROSSOVERS TWEETER Crossover Point 2700Hz/12dB (highpass) * Morel operates a policy of continuous products design improvement, consequently specifications are subject to alteration without prior notice Morel, Ness Ziona, 70400 Israel. Morel America, Chandler, AZ, USA Tel: +972-8-9301161 Toll free number:1-877-667-3511...
