EN Instruction manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NIB6 E14E Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bosch NIB6 E14E Series

Summary of Contents for Bosch NIB6 E14E Series

  • Page 1 All manuals and user guides at all-guides.com EN Instruction manual...
  • Page 2 All manuals and user guides at all-guides.com NIB6..E14E / NIB6..E14M Ø 18 Ø 18/28 Ø 14,5 Ø 14,5 Ø 18 Ø 21 Ø 14,5 Ø 21 Ø 18 Ø 14,5 Ø 18/28 Ø 14,5 Ø 18 200x140 Ø 21 Ø 14,5 200x140 Ø...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Table of contents Safety information ......Safety instructions .
  • Page 4 All manuals and user guides at all-guides.com Table of contents Basic settings ......Accessing the basic settings .

  • Page 5: Safety Information

    All manuals and user guides at all-guides.com Safety information Read these instructions carefully. Only after doing this will you be able to operate your appliance properly. Keep the operating and assembly instructions in a safe place. If the appliance is given to another person, ensure the appliance documentation is also included.
  • Page 6 All manuals and user guides at all-guides.com Cooking using a water bath Cooking using a water bath involves cooking food inside a pot which is in turn placed in another larger pan which contains water. In this way, the food is heated gently and constantly and it is the hot water, not the direct heat of the hotplate, which cooks the food.
  • Page 7 All manuals and user guides at all-guides.com Taking care of the cooling This hob is fitted with a fan in the lower section. Risk of malfunction! If a drawer is fitted beneath the hob you must not keep small objects or paper in it as, if they are picked up, they could damage the cooling fan or affect the cooling system.

  • Page 8: Causes Of Damage

    All manuals and user guides at all-guides.com Causes of damage Bases of pots and pans Rough pot and pan bases scratch the ceramic. Avoid boiling pots dry. This may cause damage. Hot pots and pans Never place hot pots or pans on the control panel, the display area or the surround.

  • Page 9: Environmental Protection

    All manuals and user guides at all-guides.com Environmental protection Environmentally-fri endly waste Unpack the appliance and dispose of the packaging by environmentally-friendly means. management This appliance complies with Directive WEEE 2002/96/CE on Waste Electrical and Electronic Equipment. This directive defines the framework for the recycling and reuse of used appliances throughout Europe.

  • Page 10: Induction Cooking

    All manuals and user guides at all-guides.com Induction cooking Advantages of induction cooking Induction cooking involves a radical change to the traditional method of heating, as the heat is generated directly in the pan. For this reason, it offers a number of advantages: Greater speed in cooking and frying;...
  • Page 11 All manuals and user guides at all-guides.com Checking pans using a To find out whether the pans are suitable, check that magnet they are attracted to a magnet. The manufacturer will usually indicate if their pans are suitable for induction cooking. Unsuitable pans Never use pans made from: standard, high quality steel...

  • Page 12: Getting To Know Your Appliance

    All manuals and user guides at all-guides.com Double or triple hotplate These areas can detect pans of different sizes. The area will automatically adapt, depending on the pan material and its properties, activating only a single area or an entire area and supplying the right level of power for best cooking results.

  • Page 13: The Hotplates

    All manuals and user guides at all-guides.com The hotplates Hotplate Switching on and off Single hotplate Ensure the pan is the right size. m Extended cooking The hotplate is switched on automatically by using a pan with a base zone which matches the size of the outer area.

  • Page 14: Programming The Hob

    All manuals and user guides at all-guides.com Programming the hob This section shows how to adjust a hotplate. The table gives the settings and cooking times for various dishes. Switching the hob on and off The hob is switched on and off using the controls. To switch on Turn the control clockwise to the required heat setting.

  • Page 15: Cooking Table

    All manuals and user guides at all-guides.com Selecting the heat setting: Turn the control clockwise to the required heat setting. The selected heat setting will light up on the display. Warning: The selected heat setting will flash if no pan is placed on the induction hotplate.
  • Page 16 All manuals and user guides at all-guides.com Slow cooking Duration of level slow cooking in minutes Boiling, steaming, sautéing Rice (with double the amount of water) 15 30 min Rice pudding 25 35 min Potatoes (unpeeled) 25 30 min Potatoes (peeled in salted water) 15 25 min Pasta 6 7*...

  • Page 17: Childproof Lock

    All manuals and user guides at all-guides.com Slow cooking Duration of level slow cooking in minutes Frying** (150 g 200 g per portion in 1 2 l of oil) Frozen food, e.g. chips, chicken nuggets fry in batches Frozen croquettes Dumplings Meat, e.g.

  • Page 18: Switching The Permanent Childproof Lock On And Off

    All manuals and user guides at all-guides.com Please note: The childproof lock may be accidentally switched on and off if: water is spilt when cleaning, food is spilt Ñ or objects are resting on the symbol. Switching the permanent childproof lock on Use this function to permanently activate the and off childproof lock.

  • Page 19: The Powerboost Function

    All manuals and user guides at all-guides.com The Powerboost Function Use this function to heat up the contents of the pan faster than by using the heat setting j. This function allows you to increase the maximum power level of the hotplate in use. Restrictions when using the All the hotplates have this function.

  • Page 20: How To Deactivate It

    All manuals and user guides at all-guides.com How to deactivate it symbol. The letter n will no longer be Press the boost± displayed and the previously selected heat setting lights up. The Powerboost function has been deactivated. In certain circumstances, the Powerboost function may be deactivated automatically to protect the internal electronic components of the hob.

  • Page 21: Basic Settings

    All manuals and user guides at all-guides.com Basic settings The hob offers various basic settings. Some of these settings can be modified. k childproof lock deactivated* Permanent childproof lock b childproof lock activated The hob is automatically locked once switched off. k majority of beeps deactivated Deactivating the beep b some beeps deactivated...

  • Page 22: Care And Cleaning

    All manuals and user guides at all-guides.com Selecting the required Press the Ñ symbol until the indicator for the setting required function is displayed. Then select the required setting using the boost ± symbols on the lower left-hand hotplate and the symbol on the lower right-hand hotplate.

  • Page 23: Hob Surround

    All manuals and user guides at all-guides.com Never use: Abrasive products Aggressive cleaning products, such as stain removers and oven sprays Sponges which may scratch High-pressure cleaners or steam cleaners Remove stubborn dirt with a glass scraper. Glass scrapers Remove the guard from the scraper Clean the surface of the cooking hob with the blade.

  • Page 24: Fixing Malfunctions

    All manuals and user guides at all-guides.com Fixing malfunctions Malfunctions are generally caused by minor faults. Before contacting the Technical Assistance Service, ensure you have read the following recommendations and warnings. Display Malfunction Measure none The electric power supply Use other electrical appliances to check if there has been has been interrupted.

  • Page 25: Normal Noises Heard During Appliance Operation

    All manuals and user guides at all-guides.com Display Malfunction Measure Incorrect supply voltage, Please contact the local electricity board. outside normal operating limits {c/{d The hotplate has Wait until the electronic system has cooled down overheated and has sufficiently before switching the hob back on. switched off in order to protect the hob Do not rest hot pans on the control panel.

  • Page 26: After Sales Service

    All manuals and user guides at all-guides.com Noise from the fan To run the electronic system properly, the cooking hob must operate at a controlled temperature. To do this, the cooking hob is fitted with a fan which comes on after each temperature detected using different power levels.
  • Page 27 All manuals and user guides at all-guides.com DE http://www.bosch hausgeraete.de GB http://www.boschappliances.co.uk http://www.bosch electromenager.com NL http://www.bosch huishoudelijke apparaten.ni http://www.bosch kodinkoneet.com DK http://www.bosch hvidevarer.com http://www.bosch ed.com http://www.bosch.pt BE http://www.electro.bosch.be AU http://www.bosch.com.au http://www.bosch hausgeraete.at BR http://www.boschelectrodomesticos.com.br GR http://www.bosch home.gr http://www.bosch appliances.com 9000435611 (1W0D3F) 01-8905...

This manual is also suitable for:

Nib6 e14m series
