Laurel 1600
TV Stand
INSTRUCTION MANUAL
Please read these instructions carefully and retain them for future reference.
FD-TS-12-42

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Laurel 1600 FD-TS-12-42 and is the answer not in the manual?

Questions and answers

Related Manuals for EVERFURN Laurel 1600 FD-TS-12-42

Summary of Contents for EVERFURN Laurel 1600 FD-TS-12-42

  • Page 1 Laurel 1600 TV Stand INSTRUCTION MANUAL Please read these instructions carefully and retain them for future reference. FD-TS-12-42...

  • Page 2: Package Contents

    HIGHLIGHTS • Engineered Wood • x2 Cupboards PACKAGE CONTENTS " • Everfurn Laurel TV Stand • Assembly Parts • Instruction Manual SPECIFICATIONS • Depth: 400 mm • Height: 400 mm • Width: 1600 mm • Surface Material: Paper Lamination • Top Board Thickness:...

  • Page 3: Identifying Parts

    IDENTIFYING PARTS 16MM 40MM PLASTIC POWER PVC LEG (H150MM) CSK CAP PVC SHELF DOWEL SCREW BLACK ALLEN KEY NAIL " M6X40 MINIFIX 5654 SUPPORT HINGES 8X25 M3.5X16 1X16 1X52 8 SETS 1X34 Hardware A. 8X25 Plastic Dowel x16 F. PVC Shelf Support x4 B.
  • Page 4 INSTRUCTIONS FOR USE ASSEMBLY INSTRUCTIONS Important Note: When tightening any fasteners, ensure not to tighten them more than 90% tightness to prevent damage to the product or the fastener. Step 1: 1. Attach the 8X25 Plastic Dowels x16 (A) to the Outer Right Stand Panel (4), Inner Right Stand Panel (2), Inner Left Stand Panel (3), and Outer Left Stand Panel (5).
  • Page 5 ASSEMBLY INSTRUCTIONS (Continued) Step 4: 1. Attach the 5/8" Door Hinges (J) onto the Cupboard Doors (9) using the M3.5X16mm CB Screws (B) • Use a Phillips screwdriver (Not included) to assist with this step. Step 5: 1. Attach the Outer Right Stand Panel (4), Inner Right Stand Panel (2), Inner Left Stand Panel (3), and Outer Left Stand Panel (5) to the Bottom Stand...
  • Page 6 ASSEMBLY INSTRUCTIONS (Continued) Step 8: 1. Attach the Rear Stand Panel (7) with the 6/8” Power Nails x34 (H). • Use a hammer (Not included) to assist with this step. Step 9: 1. Slide in the Shelf Panel (8) between the Inner Right Stand Panel (2), and Inner Left Stand Panel (3).

  • Page 7: Safety Precautions

    CLEANING AND CARE INSTRUCTIONS - GENERAL • Cleaning: Wipe down the product’s surface using a thickly folded damp cloth. • Do not use harsh or abrasive cleaning chemicals or materials on the product; doing so may damage or scratch the surface finish. •...

  • Page 8: Environmentally-Friendly Disposal

    ENVIRONMENTALLY FRIENDLY DISPOSAL IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT. • At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service.

  • Page 9: Warranty

    WARRANTY The Everfurn Laurel TV Stand includes a standard 12-month limited warranty against manufacturing defects and faults. Should the product be unboxed with any faulty parts, poor finishing, visible damage, or failure to perform due to a manufacturing defect or poor workmanship, please return it with your proof of purchase (till slip or invoice) to the store of purchase for an exchange, or repair, depending on the store’s returns policy.
