Lafferty 950701-SS Installation & Operation Instructions

REQUIREMENTS
Ready-to-Use Chemical Solution
Compressed Air
Minimum Air Supply Line
OPTIONS
Square Jug Rack Conversion
Specify Round or Square Jug Racks at time of order
For Lighter Fog Use Metering Tips (4 Sets)
Metering Tips-Color Coded (10
Smallest)
5 Gallon Pail
Pail, 5 Gallon Round W/ Suction Stem
Optional Check Valves to Keep Tubes Primed
Check Valve, Chemical, SS, EPDM,
1/4"
OVERVIEW
The Portable 5 Gallon 305 4-Way Stainless Steel Fogger is a damp mist sprayer that uses compressed air (29.5 CFM @ 80 PSI) and venturi action to draw ready-to-
use chemical solution from a user-supplied chemical pail on the stainless steel cart and project it up to 25 feet in 4 directions. The adjustable output sprays mist (fog)
into the air to cover exposed surfaces and penetrate hard-to-reach areas. This unit features stainless steel fogger bodies, a telescoping mast, and can also be used
as a 2-Way fogger.
Lafferty Equipment Manufacturing, LLC • 5614 Oak Grove Road • North Little Rock, Arkansas 72118
Lafferty Equipment Manufacturing, LLC
Installation & Operation Instructions
Model # 950701-SS · Portable 5 Gallon 305 4-Way SS Fogger
up to 29.5 CFM @ 80 PSI
1/2"
# 443794
# 709105
# 491324
www.laffertyequipment.com
501-851-2820
W A R N I N G ! R E A D A L L
I N S T R U C T I O N S B E F O R E
U S I N G E Q U I P M E N T !
