ROWAN ELECTRIC APPLIANCE Z3908-BLACK Instruction Manual

Hide thumbs

Advertisement

Table of Contents

INSTRUCTION MANUAL
ICE MAKER
Item No: Z3908-BLACK
Model No: ICM1262A
Thank you for purchasing this product! If you have any questions about the product, such
as missing parts, damaged products, product assembling, or operation, please contact us
via Amazon Message or customer service number: 213-4467172 or 661-4358826.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z3908-BLACK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ROWAN ELECTRIC APPLIANCE Z3908-BLACK

Summary of Contents for ROWAN ELECTRIC APPLIANCE Z3908-BLACK

  • Page 1 INSTRUCTION MANUAL ICE MAKER Item No: Z3908-BLACK Model No: ICM1262A Thank you for purchasing this product! If you have any questions about the product, such as missing parts, damaged products, product assembling, or operation, please contact us via Amazon Message or customer service number: 213-4467172 or 661-4358826.

  • Page 3: Important Notices

    IMPORTANT NOTICES When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following: 1. Read all instructions before using. 2. Remove all packing material and carefully check your ice maker to ensure it is in good condition and that there is no damage to the ice maker or power cord and plug.
  • Page 4 –bed and breakfast type environments; 6. –Warning: Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. –Warning: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. –Warning: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 5  Avoid opening flames and sources of ignition.  Thoroughly ventilate the room in which the appliance is situated. 7. Before using the Ice maker for the first time, please wait for 2 hours after positioning it, and keep the transparent lid open for at least 2 hours.

  • Page 6: Specifications

    21. Regarding the information pertaining to the use of the appliance, please refer to the paragraphs below. SPECIFICATIONS Item no: Z3908-BLACK Model no: ICM1262A Voltage:120V/60Hz Power Consumption: 120 W Daily Ice Output: 12kg/24 hours Ice Storage Capacity: 1.0L/600g...
  • Page 7 DESCRIPTION Top Lid Transparent lid Evaporator Micro switch support Ice shovel board Ice collecting tray 10. Rear housing Water tank 11. Air vent Control panel 12. Ice scoop Front housing...
  • Page 8 FEATURE  Quick ice-making  Prompt when the ice is full and the water is insufficient  Transparent bullet ice  8 pcs ice can be made in nine minutes 1. During transportation, do not tilt the machine more than 45 degrees, do not reverse the machine.

  • Page 9: Control Panel Operation

    CONTROL PANEL OPERATION LARGE: large ice indicator light SMALL: small ice indicator light ADD WATER: water shortage alarm ICE FULL: ice full alarm START/STOP: START/STOP button ICE SIZE SELECTION BUTTON 1. Plug in power, the machine is in standby mode, and the large ice indicator light flashes green.
  • Page 10 START/STOP button for 3 seconds, the machine enters the cleaning function, and the four lights flash alternately. Do not disconnect the power supply during cleaning. After cleaning, the machine will automatically enter the standby mode. 4. ADD WATER: water shortage alarm: when the light is on, it means water shortage in the water tank.
  • Page 11 CLEANING & USE GUIDANCE 1. Clean the inner liner, ice collecting tray, water tank and ice shovel frequently. When cleaning, unplug the unit and remove the ice cubes. Use a diluted solution of water and vinegar to clean the inside and the outside surface of the Ice maker. Rinse thoroughly before use.

  • Page 12: Troubleshooting

    Ice collecting tray Filter cover TROUBLESHOOTING Please note, if a power failure occurs due to the disconnection of the power cord, or the power button has been pushed off during an ice-making cycle, small ice chips may form and lodge in the automatic shovel causing it to jam.
  • Page 13 PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS The compressor works Stop the ice maker and do not The voltage is lower than abnormally restart it until the voltage is recommended one. with a buzzing noise. normal. 1. . Add some water until 1.
  • Page 14 1. If the power cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard. 2. Fill it with potable water only. 3. It is normal for the compressor and condenser surface to reach temperatures between 158°F(70°C) and 194°F(90°C) during operation and surrounding areas may be very hot.
  • Page 15 213-4467172 661-4358826 (8:30am - 5:30pm P .S.T.) SE REQUIERE PRUEBA DE COMPRA CON FECHA PARA SERVICIO BAJO GARANTÍA. Address: ROWAN ELECTRIC APPLIANCE LLC 28407 Ascent Way, Santa Clarita, CA 91350 Phone: 213-4467172 or 661-4358826...

This manual is also suitable for:

Icm1262a
