- Page 1 INSTALLATION GUIDE FX61E2 FX101E2 FX82E2 FX122E2 PROFESSIONALS REQUIRED • ELECTRICIAN • PLUMBING – ALL DOCUMENTS / COMPONENTS INSIDE OVEN COPPER PLUMBING ONLY Revised August 2023...
-
Page 3: Table Of Contents
TABLE OF CONTENTS: Page English: Specifications: • GBS FX61E2 • GBS FX101E2 • GBS FX82E2 • GBS FX122E2 Positioning Oven Connection Diagram • GBS FX61E2 • GBS FX101E2 • GBS FX82E2 • GBS FX122E2 Water Connection Electrical Connection Access PCB’s and Fuses... -
Page 5: Gbs Fx61E2
240 V, 10.4 kW, 25 A, 60 Hz, 3 ph* 115kg Weight Net: 127kg Crated Weight: Capacity: G/N containers: 6 1/1 *Special Order GBS America Page 5 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 6: Gbs Fx101E2
480 V, 17.9 kW, 21.6 A, 60 Hz, 3 ph* 155kg Weight Net: 167kg Crated Weight: Capacity: G/N containers: 10 1/1 *Special Order GBS America Page 6 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 7: Gbs Fx82E2
480 V, 20.7 kW, 24.9 A, 60 Hz, 3 ph* 228 kg Weight Net: 248 kg Crated Weight: Capacity: G/N containers: 8 2/1 16 1/1 *Special Order GBS America Page 7 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 8: Gbs Fx122E2
480 V, 26 kW, 31.3 A, 60 Hz, 3 ph* 260kg Weight Net: 280kg Crated Weight: Capacity: G/N containers: 12 2/1 ; 24 1/1 GBS America Page 8 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 9: Positioning
Positioning: Left Side Clearance: 19.7 inches Right: 4 inches Back: 4 inches GBS America Page 9 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 10: Oven Connection Diagram
OVEN CONNECTION DIAGRAM (GBS FX61E2) Page 10 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 11: Gbs Fx101E2
OVEN CONNECTION DIAGRAM (GBS FX101E2) Page 11 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 12: Gbs Fx82E2
OVEN CONNECTION DIAGRAM (GBS FX82E2) Page 12 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 13: Gbs Fx122E2
OVEN CONNECTION DIAGRAM (GBS FX122E2) Page 13 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 14: Water Connection
Manganese < 0,05 mg/l (*) The value refers to the amount of water needed for steam production inside the cooking chamber. Page 14 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 15: Electrical Connection
Temperature of use: 75°C (167°F). 3. Replace the panel (A) and retighten the scre ws when the operation is complete. IDM-39617701600.tif Page 15 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... - Page 16 6. Replace the panel (A) and screw the screws back into place. 7. Turn the water supply tap (B) back off when the operation is complete. Page 16 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
-
Page 17: Access Pcb's And Fuses
HOW TO ACCESS PCB’s and FUSES REMOVE SCREWS and/or BOLTS BOLTS LOCATED BENEATH PANEL GENTLY LIFT PANEL SWING OPEN Page 17 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 18: Reverse Osmosis Water Filter Installation
*if water conditions exceed those specified in the Installation Manual more frequent sediment pre- filter changes may be warranted. GBS always suggests that the operator have the water tested to determine the proper frequency of sediment pre-filter changes. - Page 19 • ENSURE POLY TUBING DOES NOT COME INTO CONTACT WITH ANY HEAT SOURCE – LOCATED ON THE LEFT HAND UNDERSIDE OF THE OVEN Page 19 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914...
- Page 20 For continued protection against fire and electric shock, replace with same type and rating of fuse. Use supply wires suitable for 75°C (167°F). L) NAME PLATE M) Warning: Type and Rate of Fuse N) Warning: Type and Rating of Fuse Page 20 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
-
Page 21: Electrical System Diagram
ELECTRICAL SYSTEM DIAGRAM (FX 61 E2 208V3 / 240V3) Page 21 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 22: Gbs Fx101E2
ELECTRICAL SYSTEM DIAGRAM (FX 101-82 E2 208V3 / 240V3) Page 22 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 23: Gbs Fx82E2
ELECTRICAL SYSTEM DIAGRAM (FX122 E2 208V3 / 240V3 - A) Page 23 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 24: Gbs Fx122E2
ELECTRICAL SYSTEM DIAGRAM (FX122 E2 208V3 / 240V3 - B) Page 24 GBS America 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
