- Page 1 INSTALLATION GUIDE FX61G2 FX101G2 FX82G2 FX122G2 PROFESSIONALS REQUIRED: ATTENTION : GAS FITTER GAS REGULATOR MUST BE INSTALLED ON OVEN – ALL DOCUMENTS / COMPONENTS INSIDE • PLUMBING OVEN ELECTRICIAN • COPPER PLUMBING ONLY Rev: Jan 2015...
- Page 2 Page 2...
-
Page 3: Table Of Contents
English: Specifications: • FX61G2 • FX101G2 • FX82G2 • FX122G2 Positioning Oven Connection Diagram • GBS FX61G2 • GBS FX101G2 • GBS FX82G2 • GBS FX122G2 Water Connection Electrical Connection Check Gas Pressure Access PCB’s and Fuses Reverse Osmosis Water Filter Installation... - Page 4 MODEL NO: GBS FX61G2 Oven Dimensions: 920 x 776 x 1455.6 (mm) 36.25 x 30.57 x 51.37 (in.) Cooking Chamber Dimensions: 645 x 650 x 510 (mm) 25.41 x 25.61 x 29.73 (in.) Crated Dimensions: 1010 x 965 x 1016 (mm) 39.8 x 38 x 40 (in.)
-
Page 5: Gbs Fx101G2
MODEL NO: GBS FX101G2 Oven Dimensions: 920 x 776 x 1700.6 (mm) 36.25 x 30.57 x 66.96 (in.) Cooking Chamber Dimensions: 645 x 650 x 755 (mm) 25.41 x 25.61 x 29.75 (in.) Crated Dimensions: 1010 x 965 x 1256 (mm) 39.77 x 38 x 49.45 (in.) -
Page 6: Gbs Fx82G2
MODEL NO: GBS FX82G2 Oven Dimensions: 1178.2 x 965 x 1516.6 (mm) 46.4 x 38 x 59.7 (in.) Cooking Chamber Dimensions: 890 x 825 x 665 (mm) 35.07 x 32.51 x 26.2 (in.) Crated Dimensions: 1180 x 1316 x 1648 (mm) 46.45 x 51.82 x 64.9 (in.) -
Page 7: Gbs Fx122G2
MODEL NO: GBS FX122G2 Oven Dimensions: 1178 x 965 x 1776.6 (mm) 46.4 x 38 x 69.94 (in.) Cooking Chamber Dimensions: 90 x 825 x 925 (mm) 35.07 x 32.51 x 36.45 (in.) Crated Dimensions: 1320 x1180 x1900 (mm) 51.97 x 46.45 x 74.80 (in.) Electrical Supply: 120 V, 960 W, 11.5 A, 60 Hz, 1 ph... - Page 8 Positioning: 19.7 inches (50 cm) Left side clearance 4 inches (10 cm) Right : 4 inches (10 cm) Back : GBS America Page 8 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
- Page 9 OVEN CONNECTION DIAGRAM (GBS FX61G2) GBS America Page 9 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
- Page 10 OVEN CONNECTION DIAGRAM (GBS FX101G2) GBS America Page 10 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
- Page 11 OVEN CONNECTION DIAGRAM (GBS FX82G2) GBS America Page 11 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
- Page 12 OVEN CONNECTION DIAGRAM (GBS FX122G2) GBS America Page 12 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
-
Page 13: Water Connection
< 0.05 mg/l Manganese < 0,05 mg/l (*) The value refers to the amount of water needed for steam production inside the cooking chamber. GBS America Page 13 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914... -
Page 14: Electrical Connection
Temperature of use: ≥ 75°C (167°F). Replace the panel (A) and retighten the scre ws when the operation is complete. GBS America Page 14 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... - Page 15 ELECTRICAL CONNECTION – FX GAS OVENS LIVE WIRE POSITION NEUTRAL WIRE POSITION 3 WIRE CONNECTION GROUND WIRE POSITON IN A 3 WIRE CONNECTION – THE BLACK WIRE IS USUALLY THE LIVE WIRE, THE WHITE WIRE IS USUALLY THE NEUTRAL AND THE GREEN WIRE IS USUALLY THE GROUND. IMPORTANT THESE OVENS ARE VERY SENSITIVE SO THE WIRE CONNECTION MUST BE CORRECT. YOU MUST CHECK THE 3 WIRE CONNECTION CABLE TO DETERMINE WHICH WIRE IS THE LIVE AND WHICH WIRE IS THE NEUTRAL. THIS IS DONE BY USING YOUR MULTI‐METER. TOUCH ONE OF THE LEADS TO THE BLACK WIRE AND THE OTHER LEAD TO A GROUND POSITION ON THE OVEN. IF YOU GET 120V, THE BLACK WIRE IS THE ‘LIVE’ WIRE. IF THE READING IS ‘0’, THE BLACK WIRE IS THE NEUTRAL WIRE. GBS America Page 15 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
- Page 16 5. Retighten the ring nut (C). 6. Replace the panel (A) and screw the screws back into place. 7. Turn the water supply tap (B) back off when the operation is complete. GBS America Page 16 95 Merrick Way, Coral Gables FL 33134, United States...
-
Page 17: Check Gas Pressure
Pressure in kPa (Inches Water Column) Gas type rated minim maxim Natural gas 1.74 (7") 0.87 (3.5") 2.61 (10.5") Propane 2.74 (11") 1.99 (8") 3.23 (13") GBS America Page 17 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 18: Access Pcb's And Fuses
HOW TO ACCESS PCB’s and FUSES REMOVE SCREWS and/or BOLTS BOLTS LOCATED BENEATH PANEL GENTLY LIFT PANEL SWING OPEN GBS America Page 18 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 19: Reverse Osmosis Water Filter Installation
*if water conditions exceed those specified in the Installation Manual more frequent sediment pre-filter changes may be warranted. GBS always suggests that the operator have the water tested to determine the proper frequency of sediment pre-filter changes. IMPORTANT: •... - Page 20 • MAKE SURE THAT NO POLY TUBING IS RUN UNDERNEATH THE OVEN • ENSURE POLY TUBING DOES NOT COME INTO CONTACT WITH ANY HEAT SOURCE – LOCATED ON THE LEFT HAND UNDERSIDE OF THE OVEN GBS America Page 20 95 Merrick Way, Coral Gables FL 33134, United States...
-
Page 21: Safety And Information Signs
Use supply wires suitable for 75°C (167°F). L) NAME PLATE M) Warning: Type and rating of fuse N) Warning: Type and rating of fuse GBS America Page 21 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com... -
Page 22: Electrical System Diagram
ELECTRICAL SYSTEM DIAGRAM (GBS FX 61-101-82-122 G2_120V 1N) GBS America Page 22 95 Merrick Way, Coral Gables FL 33134, United States Tel: 888-402-1242 Fax: 905-829-9914 Website: www.gbsamerica.com...
