- Page 1 G2 PRO FIBER LASER MANUAL ＊ Notes: Adjust the height of the stand to ensure the focal length is 211mm/261mm (211mm for the 110-field lens and 261mm for the 150-field lens). Each machine may have a slight deviation. Please refer to the red dot focusing...
- Page 2 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Mobile/PC Apps & Manual Download Download the Mobile/PC Apps and G2 PRO manual via: https://www.gweikecloud.com/pages/gweikecloud-documentation. www.gweikecloud.com/pages/gweikecloud-documentation If you encounter problems during the use of the machine, please contact the after-sales service team first. After-sales service...
- Page 3 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Gweike G2 & G2 PRO Facebook Group https://www.facebook.com/groups/gweikecloudg2fiberlaserengraver Youtube Channel https://www.youtube.com/@gweikecloud4178 We will share the knowledge of machine use and maintenance on YouTube and Facebook from time to time.
- Page 4 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Mobile APP Connection PC APP Connection Make sure the device has been installed, Make sure the device has been installed, connect the power supply, open the APP connect the power supply, use the USB (GLaser).
- Page 5 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE LightBurn Supported Currently, the Lightburn public Beta 1.7 version supports G2 machines. Please go to the Lightburn download page through the gweikecloud website to ensure that you download the correct version.
-
Page 6: Table Of Contents
CATALOGUE 01. List Of Standard/Optional Product Accessories 02. Buttons And Indicators Instructions 03. Installation Instructions 04. Daily Cleaning & Maintenance 05. Product Specification 06. Usage Safety Guide 07. Precautions 08. Disclaimer... -
Page 7: List Of Standard/Optional Product Accessories
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /List Of Standard/Optional Product Accessories List Of Standard Product Accessories Main Engine Lifting Stand Locating Plate x 2 Tool Box Laser Source Goggles L-shaped Connecting Workbench USB Cable USB Flash Disk Plate Power Cord Focal Length Pointer Measuring Ruler... -
Page 8: Buttons And Indicators Instructions
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Buttons And Indicators Instructions 16 15 Laser source handle Locating plate Field lens Indicator Indicator light Laser source Rotary axis interface Fixed knob Ruler Stop Electric lift / Batch Adjusting knob processing button Handle Laser power AC power interface Reset button... -
Page 9: Installation Instructions
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Installation Instructions Install the lifting stand Install and secure the main engine... - Page 10 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Installation Instructions Install the pointer Use double-sided tape to stick the pointer to the L-shaped support plate, as shown in the figure.
- Page 11 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Installation Instructions Connect the cables As shown in the figure below, connect the corresponding cables: Power cable Lifting Stand cable (electric model only) Safety Shield cable USB cable (if using a computer to control the machine) Safety Shield cable Lifting Stand cable USB cable...
- Page 12 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Tips Lens Cover: Take It Off When Working STOP and LASER POWER...
- Page 13 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Focalizing Focal Length Ruler Dual Red Light Positioning When the bottom of the pointer points to 0, the Adjust the knob on the upper end of the lifting distance between 0 and the workbench is the stand so that the two red lights converge into focal length of this machine.
- Page 14 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Engraving Bevel Engraving The fixing nut and angle adjusting nut can be loosened to adjust the main engine to a suitable angle. Focus to the surface of the object 211mm/261mm...
- Page 15 PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE Engraving Handheld Engraving Hold the handle of the main engine directly, and aim at the surface of the object to be engraved for engraving. Handle position Handle position Focal length 211mm/261mm Protection cover height=Focal length 211mm/261mm...
-
Page 16: Daily Cleaning & Maintenance
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Daily Cleaning & Maintenance Clean It With Cotton Swab + Alcohol Wipe ( Note: The device can only be used after the alcohol has evaporated ) Cover The Lens With The Lid To Avoid Dust When Not Using... -
Page 17: Product Specification
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Product Specification TECHNICAL PARAMETERS Laser head: 222.4*82.4*132.5mm Bracket:250*200*322mm Size Laser source: 284.6*296.8*79mm Weight 7.8kg 1064nm Laser Wave Length 20W/30W/50W Output power Engraving area 110mm*110mm/150mm*150mm Aluminum alloy anodizing Exterior USB cable and WiFi wireless transmission Document transfer PLT/SVG/DXF/AI/BMP/JPG/JPEG/PNG and other common formats Supported Document Formats... -
Page 18: Usage Safety Guide
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Usage Safety Guide Before installing the fiber laser, please check that the equipment is in good condition and the laser lens is clean and free of contamination. Installation specification: Before starting to operate the fiber laser, please refer to the instruction manual to fix the laser head (use accessories or supports with fixing functions such as safety shield, electric lift stand and third axis to avoid breaking the support- ing object due to unstable placement) Please be sure to supply power to the device according to the power and power type (24V 11A adapter) indicated in the instruc-... -
Page 19: Precautions
PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE /Precautions Please read the [Safety Guide] in detail, and remember all the contents to standardize the operation. This product does not contain any user-replaceable components. No matter what the scene is, please do not attempt to disassemble the marking machine or troubleshoot the problem. - Page 20 Gweike Technology Co., Ltd. Address:13A, Building D, Big Data Industrial Base, Xinluo Street, Gaoxin District, Jinan, Shandong, China Email: info@gweikecloud.com Tel: +86-18769772322...
