ONEIROI - ASSEMBLY GUIDE – Rev. July. 2024
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in our
workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
You will be soldering both boards at the same time. Keeping them in the panel together might help you through the build.
Check the last pages of the Build for PCB pics to help you identify components.
HAVE FUN!
RESISTORS
Color code can be difficult to identify, so we strongly recommend using a multimeter.
Qty
Value
Code
39
100k
Brown, black, black, orange, brown
19
100 R
Brown, black, black, black, brown
15
1k
Brown, black, black, brown, brown
8
22k
Red, red, black, red, brown
8
4k7
Yellow, violet, black, brown, brown
6
20k
Red, black, black, red, brown
6
470R
Yellow, violet, black, black, brown
5
10k
Brown, black, black, red, brown
4
33k
Orange, orange, black, red, brown
4
12k
Brown, red, black, red, brown
3
1M
Brown, black, black, yellow, brown
2
820k
Gray, red, black, orange, brown
2
390k
Orange, white, black, orange, brown R124, R125
2
191k
Brown, white, brown, orange, brown R66, R67
2
15k
Brown, green, black, red, brown
2
22R
Red, red, black, gold, brown
Name on PCB
R1, R2, R3, R4, R26, R28, R29, R31, R33, R34, R35, R51, R53, R56,
R57, R58, R63, R69, R70, R72, R73, R74, R75, R76, R77, R78, R79,
R80, R81, R82, R86, R87, R89, R90, R103, R105, R107, R119, R126
R40, R41, R42, R43, R44, R45, R48, R49, R64, R65, R92, R95, R97,
R98, R99, R100, R108, R120, R127
R15, R21, R36, R37, R38, R39, R46, R47, R54, R55, R91, R93, R94,
R96, R112
R25, R27, R30, R32, R50, R52, R59, R62
R11, R12, R14, R17, R18, R19, R22, R23
R13, R16, R20, R24, R109, R110
R101, R102, R104, R106, R113, R123
R6, R8, R10, R117, R118
R83, R84, R85, R88
R60, R61, R68, R71
R5, R7, R9
R115, R116
R121, R122
R111, R114
1
