Befaco PERCALL V1 Assembly Manual

Advertisement

Quick Links

THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in our
workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
You will be soldering both boards at the same time. Keeping them in the panel together might help you through the build.
Check last pages of the Build for PCB pics to help you identify components.
HAVE FUN!
BAG A
RESISTORS
Qty Value
Code
31
100k
Brown, black, black, orange, brown
22
10k
Brown, black, black, red, brown
12
2k2
Red, red, black, brown, brown
11
1M
Brown, black, black, yellow, brown
9
1k
Brown, black, black, brown, brown
8
110k
Brown, brown, black, orange, brown
8
470k
Yellow, violet, black, orange,brown
6
330k
Orange, orange, black, orange, brown
5
2k
Red, black, black, brown, brown
4
20k
Red, black, black, red, brown
4
47k
Yellow, violet, black, red, brown
4
56k
Green, blue, black, red, brown
4
91k
White, brown, black, red, brown
1
560 Ohm
Green, blue, black, black, brown
1
9k1
White, brown, black, brown, brown
1
68k
Blue, gray, black, red, brown
1
240k
Red, yellow, black, orange, brown
1
680k
Blue, gray, black, orange, brown
Name on PCB
R4, R38, R41, R42, R43, R44, R46, R48, R49,
R54, R55, R68, R69, R70, R71, R105, R106,
R107, R108, R109, R110, R111, R112, R123,
R124, R125, R126, R144, R145, R146, R147
R1, R5, R6, R8, R10, R11, R14, R17, R18, R58,
R59, R76, R77, R78, R79, R100, R132, R133,
R134, R135, R136, R137
R19, R20, R21, R23, R25, R27, R29, R31, R117,
R118, R119, R120
R13, R26, R30, R33, R35, R53, R56, R72, R73,
R74, R75
R129, R131, R143, R148, R149, R150, R151,
R152, R153
R24, R28, R34, R37, R60, R61, R62, R63
R32, R36, R39, R40, R45, R47, R50, R51
R2, R3, R15, R16, R52, R57
R122, R139, R140, R141, R142
R64, R65, R66, R67
R121, R127, R128, R130
R113, R114, R115, R116
R101, R102, R103, R104
R12
R138
R22
R7
R9
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PERCALL V1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Befaco PERCALL V1

  • Page 1 Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting. If this is your first project, please read this article before you start assembling the kit: www.befaco.org/howto/ You will be soldering both boards at the same time. Keeping them in the panel together might help you through the build.
  • Page 2 DIODES Solder the diodes observing their polarity. The black or white line on the diode must match with the white line on the diode symbol on the PCB silkscreen. Value Name on PCB 11 1N4148 D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11 1N5817 (black) D12, D13 FERRITE...
  • Page 3: Power Connector

    ELECTROLYTIC CAPACITORS Values are written on the side of the capacitor. Mind their polarity (The long leg of the capacitor is the positive (+)). Value Code Name on PCB 10uF 10uF C21, C22, C23, C24, C31, C32 TRANSISTORS Be sure they are orientated correctly. The curved and flat sides of the silkscreen outline of the transistor on the PCB must match that of the transistor’s body.
  • Page 4 FEMALE PIN HEADERS Place the female pin headers on the control board over the silkscreen markings at positions and solder. Double check they all are perfectly straight. PINs Name on PCB SV101, SV102 SV100 Now it’s a good moment to split the boards apart. SPACER Secure the spacer onto the CONTROL PCB (through the two hole with silver outline) with the main body of the spacer on the component side, and the nut on the opposite.
  • Page 5: Front Panel

    POTENTIOMETERS Now place the potentiometer on the PCB but... don't solder them yet! Type Name on PCB Single (3pin) B100k VOL1, VOL2, VOL3, VOL4 SWITCHES Place the switches in their right places. don't solder them yet! Type Name on PCB Mini.
