Instruction Manual
Safety, Operation,
Maintenance
600W Impact Drill
Model:HP600-A
IMPORTANT
Please read the entire instruction
manual carefully before operating
this tool. Please pay particular
attention to all safety rules and
cautions.
Due to continuous improvement the product pictured may differ slightly in appearance.
1
Specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP600-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai HP600-A

  • Page 1 Instruction Manual Safety, Operation, Maintenance 600W Impact Drill Model:HP600-A IMPORTANT Please read the entire instruction manual carefully before operating this tool. Please pay particular attention to all safety rules and cautions. Due to continuous improvement the product pictured may differ slightly in appearance.
  • Page 2: Table Of Contents

    Contents Page I. Environment Protection II. Check the tool before use III. Specifications IV. Noise and vibration data V. Descriptions of symbols VI. Safety instructions - General safety rules VII. Additional safety rules for impact drills VIII. Functions of the tool IX.
  • Page 3: Safety Instructions General Safety Rules

    SAFETY INSTRUCTIONS General Safety Rules WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and /or serious injury. The term “power tool” in all warnings listed below refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool.
  • Page 4: Additional Safety Rules For Impact Drills

    d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation.
  • Page 5: Know Your Tool

    Know your power tool Before using the tool, familiarise yourself with the operating features read the entire instruction manual paying particular attention to the safety rules and operating procedures. Identification Figure 1 Keyless chuck 3. Selection lever Depth stop 4. Rotation lever 5.
  • Page 6: Maintenance

    Drilling operation (fig. 5) Drilling Wood Figure 5 1. For drilling into wood, ensure the selection switch is set to the regular drilling position (to the right). 2. When drilling into soft wood, the drill should be operated at its maximum speed. 3.
  • Page 7 Caution: Always turn the sander off and remove the power plug from the socket before performing inspections or maintenance on this tool. Carbon Brushes (fig. 5) Figure 6 The carbon bushes are an integral component in the efficient running of the motor. These are consumable spare parts that must be replaced when they are worn to 4mm.
