Sander Fresh-Skim 300 Instruction Manual

Instruction Manual
Fresh Water Protein Skimmer
Skimming System in connection with air pump and water pump
Range of application/ Mode of operation:
The Fresh Skim 300 is suitable for garden ponds or breeding basins up to 50 m³.
This highly efficient skimmer is operated in a bypass mode, e.g. not the whole content of the
pond (basin) will be let through the skimmer in one run. It should be placed so that it will be
fed directly from the relevant reservoir.
The skimmer must be installed in such a way that it can be fed constantly with approx. 8
m³/h water.
By pumping air through ceramic air stones, fine bubbles are produced, creating a foam
which will finally carry out protein and dirt particles into the foam beaker.
The water flow is created by a feed pump installed by the customer.
The foam beaker can take up a great amount of foam; for a continuous outflow connect the
foam with a drain. To prevent residual ozone from escaping a siphon has to be installed.
If you use ozone we recommend to control the redox potential (between 300-400mV) at the
water outlet of the skimmer.
